AUDIO PORTABLE BUDDY (APB)
PORTABLE PUBLIC ADDRESS SYSTEM
MODEL S222/SW222
MODEL S222 INCLUDES: MODEL SW222 INCLUDES:
• Carrying case with shoulder strap • Carrying case with shoulder strap
• Built in Multimedia Stereo Amplifier and speaker
• Built in Multimedia Stereo Amplifier and speaker
• Professional Hand Held microphone with 15’ cord • Built in Wireless Microphone System with lapel
microphone
SET UP:
INSTALL POWER SUPPLY
The Battery pack is standard. Optional Power Supplies may be substituted: Model S1460, International AC
Adapter/Recharger (110/220V, 50/60Hz). Model S1462, 12 Volt DC adapter (automotive cigarette lighter plug-
in). Model S1465, NiCad Battery Pack.
TO INSTALL OR REPLACE BATTERIES
Open carrying case cover. Lift out battery holder from case. Insert 10 new Alkaline “D” cell batteries, be sure to
observe polarity, or replace with Model S1465 NiCad battery pack. Carefully replace battery pack.
Do not mix battery types or attempt to recharge alkaline batteries - equipment damage, safety hazard or fire
could result.
TO OPERATE:
Plug hand held microphone into DYNAMIC microphone jack. Turn amplifier on (large rocker switch located on
the amplifier panel). The red light will show that power is available. Rotate MIC VOLUME control knob to
obtain desired loudness level throughout the coverage area.
SW222 – Turn amplifier on (large rocker switch located on amplifier panel) and turn internal wireless receiver on
(top right of chassis). Attach lapel microphone to wireless transmitter and turn transmitter on (uses 9 volt battery).
Insure transmitter and receiver are both on same frequency (A or B). Rotate MIC VOLUME control knob to
obtain desired loudness level.
ON-OFF
When power switch is in the ON position, the red light will be on.
DC IN
Connection for optional power adapter:
• S1460 International AC Adapter/Recharger (110/220V, 50/60Hz)
• S1462 12 Volt DC (automotive cigarette lighter) Adapter
LAMP
Connection for 12 to15V DC accessory
MONO-STEREO
Combines the separate left and right AUX LINE IN channels. This combined signal will be amplified and appear
on both the LEFT and RIGHT channels of the SPEAKER and LINEOUT OUTPUTS.
VOLUME
Rotate clockwise to increase amplification.
MICROPHONE INPUTS
There are three microphone inputs, which can be used simultaneously:
DYNAMIC - for standard dynamic cartridge microphones
CONDENSER - for electret or condenser microphones which require phantom power
(Supplied from the amplifier)
WIRELESS - accepts line-level output from wireless microphone receiver if using an S222
AUXILIARY
To add pre-recorded music or sound effects during your presentation, just plug your CD player, tape player or
computer sound card into the LINE IN jack. Separate VOLUME and TONE control knobs let you balance the
program source with the live microphones. If using an external wireless receiver, for best sound quality it should
be connected to the LINE IN jack.
OUTPUT
To tape record your speech or program, connect the on the amplifier to the input on a tape recorder. LINE OUT
SPEAKERS
Two separately amplified speaker jacks (4-8 ohms) allows you to use internal speaker and extension speaker for
additional sound power or true stereo output. Unit speaker is wired internally. Plug external speaker into right
speaker jack for stereo. Note: when using a stereo AUX source with a single speaker, only one of the stereo
channels will be heard, switch stereo/mono switch to mono for both channels to be heard. However, all MIC
inputs are heard equally on both channels.
PROBLEM SOLVING
FEEDBACK is the howl or screech often heard in sound reinforcement systems. It is caused by sound from the
loudspeaker returning to the microphone. AmpliVox systems utilize proven acoustical principles to minimize
this; however, there is no way to completely eliminate feedback under conditions of high amplification. If
feedback occurs check the following:
1. User’s hand covering the head of the microphone. [Hold microphone under head slots.]
2. Sounds can easily re-enter microphone. Keep loudspeaker turned toward audience. Note: sound can be
reflected from a hard surface back through the microphone. [Turn speaker.]
3. User holding microphone in a reflecting position. [Turn microphone.]
4. Volume setting too high. [Reduce microphone channel volume; compensate by speaking louder or closer to
the microphone.]
NO SOUND
Make sure amplifier POWER switch is turned on and red LED is lit. If switch is on and LED is not lit, check to
see that batteries are properly connected and at full charge. If using optional power adapter, check to see that front
panel connector is properly seated, and verify that the power source is live.
IF YOU HAVE ANY QUESTION OR PROBLEMS PLEASE CALL OUR CUSTOMER SERVICE
DEPARTMENT AT 1-800-267-5486
