Sida 1/2
PHONE (800) 267-5486 FAX: (800) 267-5489 WEB: WWW.AMPLI.COM EMAIL: INFO@AMPLI.COM
PARTS DESCRIPTION
1 Wireless Antenna - adjustable
2 On/Off Switch & Power indicator light
3 Wireless Mic Volume & Indicator Light
4 Wired Microphone Jack with Volume
Control
5 Audio input jack w/ volume control
6 Treble/Base Control
7 Jack Out for Recording
8 Reverb/Echo control
9 Speaker 6.5-in
10 Wireless Handheld Mic or Lapel Mic
with Transmitter
11 Power Cord & Audio Input Cable
12 Handle
OPERATING INSTRUCTIONS
1. Readytospeakoutofthebox!
a. ACpower–Beforeuse,pleasemakesurethevoltageof
powersupplyisthesameasthatindicatedontheunit.
 Ifdifferent,itwillcausedamagetotheunit.
b. DCpower–suppliedfromtheDCinputjack.Thevoltage
shouldbe12V-15V
c. Battery–IncludedSLA(sealedleadacid)rechargeablebat-
tery.
2. Beforeswitchingtheuniton,adjustthemastervolume,treble,
bassandecho(reverb)controlstominimum,thenturnuniton.
Adjustlevelsaccordingly.
3. Iffeedbackoccursturndownthetrebletonecontrol.Iffeedback
stillexists,turnmastervolumedown.
4. Ifvolumeisgettinglower,receivingdistanceisshortenedor
soundisnotnormal,changethebatteries.
5. Thewirelessmicrophoneandwiredmicrophonecanbeused
together.
6. CDINcanconnectwiththeportableRadio,CDplayer,VCR
playerorMP3Playerandothersoundsources.
7. RECOUTcanconnectwitharecordertohaveon-siterecording
ofyourpresentationORwiththeoutputjackofalargeramplifier
toenlargethecoverage.Youcanalsoplugintoahousesystem.
PHONE (800) 267-5486 FAX: (800) 267-5489 WEB: WWW.AMPLI.COM EMAIL: INFO@AMPLI.COM
PARTS DESCRIPTION
14 Carrying Case
15 Rechargeable Battery
16 Compartment for AC cord
17 AC Input
18 Fuse
19 Camera Tripod Mount
20 Optional Alkaline Battery Compartment
21 DC Input Jack
22 Charge LED Indicator
23 Power Supply Label
8. Whennotusingthesystem,remembertoturnofftheON/OFFswitchof
themicrophoneandturnofftheswitchontheamplifierinordertoavoid
wastingpower.
9. Donotusedifferentbrandsofbatteriestogetherormixoldandnewbat-
teriestogether.Alwayschangeall8batteriesatthesametime.
10.Removetheoptional8-Dcellbatterieswhentheamplifierwillnotbeused
forlongperiodsoftime,sincetheycanleakanddamagetheunit.Ourwar-
rantydoesnotcoverdamagecausedbyleakingbatteries.
11.Don’topenthechassis.
12.Don’tgetunitwet.
13.Don’tuseanyvolatilechemicalsonunit.
If you have any questions please call 1-800-267-5486 Monday to
Friday 8 am to 6 pm CST.
Specs:
OperatingRange:64to128ft(20-
40m)
ReceivingMode:VHF
S/NRadio:60dB
DynamicRange:80dB
Power:30Watts
Impedance:600Ohm
AmplifierBattery:BuiltinSLA
rechargeableoroptional8D-cells
TransmitterBattery:9V
FrequencyRange:100-15,000Hz
VHFFMBand
1Unbalanced6.3mmjackinputfor
microphone
1unbalanced6.3mmjackforCD
1unbalanced6.3mmjackoutfor
REC
Dimensions:11.25-in.Hx9-in.Wx
6.5-in.D
Weight:7.5lbs.withoutbatteries
Updated9/10/2010
