Sida 1/26
2
FB 52 AUS
FB 52 IX AUS
Multifunction Oven
Instructions for installation and use
2
Congratulations on choosing an Ariston appliance, which you will find is dependable and easy to use. We recommend
that you read the instructions in this owner’s manual carefully before use for the best performance and to extend the life
of your appliance, as it will provide you with all the instructions you require to ensure its safe installation, use and
maintenance. Always keep this owner’s manual close to hand since you may need to refer to it in the future. Thank you.
Close-up view
A. Control Panel
B. Cooking mode selection knob
C. Cooking temperature selection knob
E. Oven indicator light (only available on certain models)
- When lit, it indicates the ovens is heating up to the
temperature set.
F. Dripping Pan or Baking Sheet
G. Oven Rack
H. Guides for sliding the racks or dripping pan in and
out
I. End Cooking Time Knob (only available on certain
models)
BC
E
I
G
A
F
H
3
How to use your oven
This multi-function oven combines the advantages of tra-
ditional convection ovens with those of the more modern
fan assisted models in a single appliance.
It is an extremely versatile appliance that allows you to
choose easily and safely between 5 different cooking
modes. The various features offered by the oven are se-
lected by means of selector knob “B” and thermostat “ ”C
situated on the control panel.
Notice: The first time you use your appliance, we recom-
mend that you set the thermostat to the highest setting
and leave the oven on for about half an hour with nothing
in it, with the oven door shut. Then, open the oven door
and let the room air. The odour that is often detected dur-
ing this initial use is due to the evaporation of substances
used to protect the oven during storage and until it is in-
stalled.
Notice: Place the dripping pan provided on the bottom
shelf of the oven to prevent any sauce and/or grease from
dripping onto the bottom of the oven only when grilling
food or when using the rotisserie (only available on cer-
tain models). For all other types of cooking, never use the
bottom shelf and never place anything on the bottom of
the oven when it is in operation because this could dam-
age the enamel. Always place your cookware (dishes, alu-
minium foil, etc. etc.) on the grid provided with the appli-
ance inserted especially along the oven guides
Notice: to use the oven in manual mode (not using the
end cooking time programmer), the 9 symbol must be
aligned with the reference mark on the control panel.
Convection Mode a
Position of thermostat knob “C”: between 60°C and .Max
On this setting, the top and bottom heating elements come
on. This is the classic, traditional type of oven which has
been perfected, with exceptional heat distribution and re-
duced energy consumption. The convection oven is still
unequalled when it comes to cooking dishes made up of
several ingredients, e.g. cabbage with ribs, Spanish style
cod, Ancona style stockfish, tender veal strips with rice,
etc. Excellent results are achieved when preparing veal
or beef-based dishes as well (braised meats, stew, gou-
lash, wild game, ham etc.) which need to cook slowly and
require basting or the addition of liquid. It nonetheless re-
mains the best system for baking cakes as well as fruit
and cooking using covered casserole dishes for oven bak-
ing. When cooking in convection mode, only use one drip-
ping pan or cooking rack at a time, otherwise the heat
distribution will be uneven. Using the different rack heights
available, you can balance the amount of heat between
the top and the bottom of the oven. Select from among
the various rack heights based on whether the dish needs
more or less heat from the top.
Fan Assisted Mode b
Position of thermostat knob “C”: Between 60°C and .Max
The heating elements, as well as the fan, will come on.
Since the heat remains constant and uniform throughout
the oven, the air cooks and browns food uniformly over its
entire surface. With this mode, you can also cook various
dishes at the same time, as long as their respective cook-
ing temperatures are the same. A maximum of 2 racks
can be used at the same time, following the instructions in
the section entitled: “Cooking On More Than One Rack”.
This fan assisted mode is particularly recommended for
dishes requiring a gratin finish or for those requiring con-
siderably prolonged cooking times, such as for example:
lasagne, pasta bakes, roast chicken and potatoes, etc…
Moreover, the excellent heat distribution makes it possi-
ble to use lower temperatures when cooking roasts. This
results in less loss of juices, meat which is more tender
and a decrease in the loss of weight for the roast. The fan
assisted mode is especially suited for cooking fish, which
can be prepared with the addition of a limited amount of
condiments, thus maintaining their flavour and appear-
ance.
Desserts: the fan assisted mode is also perfect for baking
leavened cakes.
Moreover, this mode can also be used to thaw quickly
white or red meat and bread by setting the temperature to
80 °C. To thaw more delicate foods, set the thermostat to
60°C or use only the cold air circulation feature by setting
the thermostat to 0°C.
“Top” oven c
Position of thermostat knob “ ”: Between °C and .C 60 Max
The top heating element comes on.
This mode can be used to brown food at the end of cook-
ing.
Grill d
Position of thermostat knob “C”: Max
The top central heating element comes on.
The extremely high and direct temperature of the grill
makes it possible to brown the surface of meats and roasts
while locking in the juices to keep them tender. The grill is
also highly recommended for dishes that require a high
temperature on the surface: beef steaks, veal, rib steak,
filets, hamburgers etc...
Some grilling examples are included in the “Practical Cook-
ing Advice” paragraph.
Fan Assisted Grill e
Position of thermostat knob “ ”: between C 60°C and 200°C.
The top central heating element and the fan come on. This
combination of features increases the effectiveness of the
unidirectional thermal radiation of the heating elements
through forced circulation of the air throughout the oven.
This helps prevent food from burning on the surface, al-
lowing the heat to penetrate right into the food. Excellent
results are achieved with kebabs made with meats and
vegetables, sausages, ribs, lamb chops, chicken in a spicy
sauce, quail, pork chops, etc.
This mode is also ideal for cooking fish steaks, like sword-
fish, tuna, grouper, stuffed cuttlefish etc.
End Cooking Time Knob (I) (only available on certain
models)
Some models are equipped with a timer program to control
when the oven shuts off during cooking. To use this feature,
you must wind the “I” knob one full turn in the clockwise
direction 4 ; Then, turn the knob in the counter-clockwise
direction 5, to set the time by matching up the indicator
