1. Introduction .................................................. 1

2. Features .................................................. 1

3. Package Contents .................................................. 1

4. Specications .................................................. 2

5. Panel Descriptions .................................................. 2

5.1 Front Panel .................................................. 2

5.2 Rear Panel .................................................. 3

6. Remote Control .................................................. 4

7.RS232 Serial Interface .................................................. 5

7.1. Connect a PC or Control System .................................................. 5

7.2. RS232 .................................................. 5

7.3. Protocol Commands .................................................. 5

8. RS232 Serial Commands .................................................. 6

8.1. Power Off Mode .................................................. 6

8.2. Front Panel Lock .................................................. 6

8.3. Unit Reset .................................................. 6

9. Typical Application .................................................. 7

10. Installation .................................................. 8

11. Safety Information .................................................. 9

12. Warranty .................................................. 10

13. Atlona Product Registration .................................................. 11

Atlona Technologies’ AT-COMP-64M is one of the most innovative Component Matrix switchers

with Stereo Audio on the market. The AT-COMP-64M has 6 individual Component Video (RCA)

inputs with Stereo Audio and 4 individual outputs. Because it is a matrix switch, any input can

rout to any output; and the same input can rout to all outputs or any other combination. Boast-e e

ing high speed Video Bandwidth of 325MHz, Maximum 380Mhz, this unit is ideal for connecting

sources including: (VCRs, Camcorders, Video Game Consoles, DVDs, Satellite Receivers, Set

Top Boxes, etc.) to desired displays such as: (HDTV, LCDs, Plasma Monitors, Video Projectors,

etc.) Selection of inputs can be achieved manually through the Front Panel, an Infrared Remote

Control unit or RS232 control. witch with awless and crystal-clear distribution of all S High Res.

HDTV video formats up to 1080p as well as audio signals. With these attributes, the AT-COMP-

64M is a great matrix switch capable of handling High Denition Television applications.

• 6 inputs to 4 outputs Component Video (Matrix Switcher)

• Supported Signals:

Component Video: YPBPR

Audio : Stereo Audio (A R /A L ) udio ight udio eft

• Support RS 232 interface

• Control Through IR remote control and Manually via Front Panel Buttons

• Video Bandwidth: 325MB

• Resolutions: 480p, 576p, 720p, 1080i, 1080p

• Included 19 inch Ear mounts

• Power supply DC12Volt, Universal Type Switch 100~230VAC, 50/60Hz

• AT-COMP-64M Matrix Switcher x 1.

• Instruction Manual x 1

• IR Remote Controller

• RS 232 Drive CD x 1

• Universal AC Adaptor : 12V DC

• 19in. Rack Mount ears ( pair ) x 1
