Dual 10 Under Seat Subwoofer Enclosure
F FORD Trucksor
2015+ F 150- Super Crew
2017+ F 250 / F 350 Super Duty-- Crew Cab
INSTALLATION GUIDE
NOTE! Read this installation guide thoroughly before disassembling or modifying the
vehicle. Installation of this product requires technical skill, experience and specialized
tools. If in doubt, it’s recommended to have it professionally installed by an authorized
Stinger AudioControl or Dealer.
TXFF15D10
A video installation guide is available at:
2
INSTALLATION NOTES
INCLUDED HARDWARE
RECOMMENDED TOOLS
M6 FLANGED HEX HEAD BOLT (2)
75mm / 2.95in Length ENCLOSURE MOUNTING BRACKETS (2) QUICK-PLUG SPEAKER CONNECTOR (1)
Ratchet
13mm Socket
10mm Wrench
Wire Strippers
Optional:
Wire Crimper
Solder/Solder Gun
The TXFF15D10 is designed to mount under the rear seat of FORD Super Crew Trucks
Some installation steps are more easily completed with a second person.
Speaker wire is required.
Final enclosure impedance: 2ohms.
Recommended amplifier rating: 400-1, 00 watts @ 2ohms.2
1 2 3
D = Driver P = Passenger
3
INSTALLATION
Step 2
Step 1
Lift up the Rear seat to expose the 4
front seat mounting bolts.
Use a 13mm socket to loosen the 4 hex
bolts enough to allow the brackets to
slide under the seat brackets.
Use a large athead screw driver and slide
it under the seat frame. Take the driver side
enclosure mounting bracket and slide under
the seat bracket.
Push the bracket toward the back of the
vehicle, leaving enough space to allow a
wrench to t between the space.
Follow the same instructions above for
installing the passenger side enclosure
mounting bracket.
Once both brackets are installed, tighten the
4 13mm Hex bolts.
Seat Bolts
Leave Space
for Wrench
Flathead Screwdriver
Enclosure Mounting
Bracket
