Sida 1/2

This device complies with part 15 of the

FCC Rules. Operation is subject to the

following two conditions (1) This device

may not cause harmful interference

and (2) this device must accept any

interference received, including

interference that may cause undesired

operation.

Contains FCC ID: ZJPARS15BC06X

Contains IC ID: 9668A-ARS15BC06X

RF Exposure Warning

This equipment must be installed and

operated in accordance with provided

instructions and the antenna(s) used

for this transmitter must be installed to

provide a separation distance of at least

20 cm from all persons and must not be

co-located or operating in conjunction

with any other antenna or transmitter.

End-users and installers must be provide

with antenna installation instructions

and transmitter operating conditions

for satisfying RF exposure compliance.

Industry Canada

Regulatory Information

This device complies with Industry

Canada license-exempt RSS standard(s).

Operation is subject to the following

two conditions: (1) this device may not

cause interference, and (2) this device

must accept any interference, including

interference that may cause undesired

operation of the device.

The user is cautioned that this device

should be used only as speciﬁ ed within

this manual to meet RF exposure

shall be placed on the apparatus.

• Always leave sufﬁ cient space around

the product for ventilation. Do

not place product in or on a bed,

rug, in a bookcase or cabinet that

may prevent air ﬂ ow through vent

openings.

• Do not place lighted candles,

cigarettes, cigars, etc. on the

product.

• Care should be taken so that objects

do not fall into the product.

• Do not attempt to disassemble

the cabinet. This product does

not contain customer serviceable

components.

• The marking information is located

at the bottom of apparatus.

• To be completely disconnect the

power input, the AC/DC adaptor

of apparatus shall be disconnected

from the mains.

• AC/DC adaptor is a disconnect

device. The AC/DC adaptor should

not be obstructed OR should be

easily accessed during intended use.

• The ventilation should not be

impeded by covering the ventilation

openings with items such as

newspaper, table-cloths, curtains etc.

• No naked ﬂ ame sources such as

lighted candled should be placed on

the apparatus.

• Attention should be drawn to the

environmental aspects of battery

disposal.

• The use of apparatus in moderate

climates.

• Use only with the

cart, stand, tripod,

bracket, or table

speciﬁ ed by the

manufacturer,

or sold with the

apparatus. When a cart is used,

use caution when moving the cart/

apparatus combination to avoid

injury from tip-over.

• Unplug this apparatus during

lightning storms or when unused

for long periods of time.

• Refer all servicing to qualiﬁ ed

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such

as power-supply cord or plug is

damaged, liquid has been spilled

or objects have fallen into the

apparatus, the apparatus has been

exposed to rain or moisture, does

not operate normally, or has been

dropped.

ADDITIONAL SAFETY INFORMATION

• The AC/DC adaptor supplied with

this product is intended to be

correctly oriented in a vertical or

ﬂ oor mount position.

• Do not use unauthorized chargers

or power adapters. Use only

chargers that came with your

product or that is listed in the user’s

guide.

• Apparatus shall not be exposed to

dripping or splashing and no objects

ﬁ lled with liquids, such as vases,

user manual

guide de l’utilisateur

EN/F

It is important to read this user manual prior to using your new product for the ﬁ rst time.

Nous vous recommandons de lire ce manuel avant d’utiliser votre nouveau produit

pour la première fois.

ARS15

v1.0 (1.0.1.0) (EN/F) IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE

Some of the following information may

not apply to your particular product;

however, as with any electronic product,

precautions should be observed during

handling and use.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near

water.

• Clean only with dry cloth.

• Do not block any ventilation

openings. Install in accordance with

the manufacturer’s instructions.

• Do not install near any heat sources

such as radiators, heat registers,

stoves, or other apparatus (including

ampliﬁ ers) that produce heat.

• Protect the power cord from being

walked on or pinched particularly at

plugs, convenience receptacles, and

the point where they exit from the

apparatus.

• Only use attachments/accessories

speciﬁ ed by the manufacturer.

]

Portable Cart Warning

FCC Information

Note: This equipment has been tested

and found to comply with the limits

for a Class B digital device, pursuant

to Part 15 of FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference

in a residential installation. This

equipment generates, uses, and can

radiate radio frequency energy and, if

not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee

that interference will not occur in a

particular installation. If this equipment

does cause harmful interference to

radio or television reception, which

can be determined by turning the

equipment off and on, the user is

encouraged to try to correct the

interference by one or more of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an

outlet on a circuit different from

that to which the receiver is

connected.

• Consult the dealer or an

experienced radio/TV technician for

help.

Changes or modiﬁ cations not expressly

approved by Audiovox could void

the user’s authority to operate the

equipment.

Congratulations on purchasing your

ARS15 wireless technology Bluetooth

stereo ampliﬁ ed speaker! This

product can provide you hours of

music enjoyment by allowing you to

wirelessly stream audio content from

your mobile device such as a mobile

phone or tablet or computer. No longer

do you need to have your mobile phone

tethered to your audio system. You

can roam around the house or ofﬁ ce

while texting, or gaming, or using some

other functions of your mobile phone,

while still listening to the great music

played back through your ARS15 stereo

speakers. You can also charge your

mobile devices through the USB port,

or even listen to other portable audio

sources such as mp3 players through the

auxiliary line input.*

* The mobile device must support Bluetooth

version 2.1 + EDR and A2DP (Advanced Audio

Distribution Proﬁ le). Not all mobile devices can

support multitasking such as listening to music

and texting at the same time. Not all mobile

phones will be compatible with the charging

ports.

Content of the box

• Main unit

• AC/DC Adaptor

• 4 in 1 charging cable

Front view

– Turn on/off the ARS15

PAIR – Enter Pairing mode or Searching

mode; start/pause music playback

SOURCE – Switch between Bluetooth

wireless mode and AUX IN

VOL-/VOL+ – Adjust volume

Green LED – Turns on when AUX IN is

activated

Pairing Reconnecting

Any device that you wish to Bluetooth

have streaming audio to your ARS15

must ﬁ rst be PAIRED to the ARS15. The

process is simple, and in most cases the

PAIRING process needs to be done only

once.

Pairing your wireless Bluetooth

technology enabled products with

the ARS15:

1. Activate the Bluetooth wireless

mode on your Bluetooth device.

Refer to the device user manual for

more details.

2. Press to turn on the ARS15. The

red LED will light.

3. Press and hold the PAIR button on

the ARS15 to enter Pairing mode.

The red LED and blue LED will ﬂ ash

alternatively.

4. You should be able to see “AR

ARS15” on the device list in the

Bluetooth settings menu on your

Bluetooth device where you can

complete the pairing operation.

Note in some cases you may be

prompted to enter a passkey. The

passkey is “0000”.

5. A conﬁ rmation screen will appear

on your device once Bluetooth

the ARS15 and the device are

successfully paired. The blue LED

In the previous section you saw how

to make that ﬁ rst connection between

your device and the ARS15. Bluetooth

However, since most people don’t leave

their mobile phone at home all the

time, or perhaps the mobile phone is

turned off from time to time, it will be

necessary to reconnect your previously

paired device when you wish Bluetooth

to stream music again. There are a few

different ways in which reconnections

are made, and fortunately they are all

very simple.

Searching mode

When the ARS15 is in SEARCHING

MODE (which is indicated by a steady

ﬂ ashing of the Blue LED), the ARS15 is

attempting to automatically connect to

the most recently connected Bluetooth

device. SEARCHING MODE typically

occurs when the ARS15 is ﬁ rst turned

on, or if the device goes Bluetooth

out of the range. See the section on

Bluetooth wireless technology range.

Once this most recent device is back

within range, the re-connection should

be automatic. However, it may be

necessary to initiate the audio playback

on the device. Note that the Bluetooth

Searching mode will revert to Bluetooth

Standby Mode (see next section) if no

re-connection is made within 3 minutes.

• Some Bluetooth devices

will automatically start

streaming audio when

connected.

• The ARS15 can store settings

for up to 8 Bluetooth

devices which simpliﬁ es the

connection process for these

devices without the need for

re-pairing every time.

• The term “ device” Bluetooth

is used frequently in these

instructions. So what is a

“Bluetooth device”? The

answer is simple. This would

be any mobile phone or

mobile tablet or netbook

or computer which has at

least both of the following

capabilities:

a) Is equipped with Bluetooth

wireless technology:

Bluetooth version 2.1 + EDR

and A2DP.

b) Can playback audio content

such as mp3 ﬁ les, etc.

Right view

USB jacks that charge your

tablet devices or cell phones.

See USB jack section for

more information.

requirements. Use of this device in a

manner inconsistent with this manual

could lead to excessive RF exposure

condition.

This Class B digital apparatus

complies with Canadian ICES-003.

Cet appareil numérique de la classe

B est conforme à la norme NMB-003

du Canada.

Electrical power

information

AC/DC adaptor:

Input: 100-240 V AC 50/60 Hz, 1.0 A

Output: 5 V DC, 3 A

Speciﬁ cation

Bluetooth® wireless technology:

Bluetooth v2.1 + EDR, A2DP / AVRCP

proﬁ le

Audio output power (10%THD) :

2W x 2

Acoustic Research is a registered

trademark of Audiovox Electronics

Corporation.

The ® word mark and logos Bluetooth

are registered trademarks owned by

Bluetooth SIG, Inc. and any use of

such marks by Audiovox Electronics

Corporation is under license. Other

trademarks and trade names are those

of their respective owners.

iPad is a trademark of Apple Inc.,

registered in the U.S. and other

countries.

Before you begin General controls

General controls

Rear view

Connect to the power adapter

Plugging in for power

Connect the supplied power adapter to

the ARS15’s Power jack, and connect the

other end to a convenient wall outlet.

will continuously light to indicate

successful connection.

You can manually break the Bluetooth

wireless connection by a press and hold

of the PAIR button.

111 Congressional Blvd., Suite 350

Carmel, IN 46032

Trademark(s) ® Registered

Printed in China

Illustrations contained within this

publication are for representation only

and subject to change.

The descriptions and characteristics

given in this document are given as

a general indication and not as a

guarantee. In order to provide the

highest quality product possible,

we reserve the right to make any

improvement or modiﬁ cation without

prior notice.

Visit http://store.audiovox.com to find the

best accessories for your products.

Warranty information

Troubleshooting tips

Auxiliary sourceUSB charging

Reconnecting Music playback

1. To select auxiliary mode, connect

your auxiliary source (e.g. mp3

player) to the AUX input jack at the

back of the ARS15 with an audio

cable (not supplied).

2. Press SOURCE button to listen

to AUX. The green LED will turn

on. Control all other playback

operations from your auxiliary

player.

When your device is Bluetooth

connected with the ARS15, the blue LED

lights. Press PAIR to play/pause music on

your device. Press to adjust VOL-/VOL+

the volume.

Synchronization of

Volume Control

Follow these steps to synchronize the

volume control between your Bluetooth

device and your ARS15.

1. First, it is recommended to PAUSE

your music source during this

process.

2. Adjust the volume control on your

Bluetooth device to maximum.

3. Then adjust the volume control on

your ARS15 to maximum.

4. At this point, your ARS15 volume

control will properly track the

volume control on your Bluetooth

device.

5. Turn down the volume on your

Bluetooth device to a mid level, and

then hit PLAY to enjoy your music.

Use the USB jacks on the right of the

ARS15 to charge your tablet or cell

phones.

If you are using a tablet device:

You may ﬁ nd it necessary to use the

provided 4 in 1 charging cable to

connect your tablet device to the USB

jack on the left. Your tablet device

should start charging. The ARS15

supports iPad® charging.

If you are using a cell phone:

You may ﬁ nd it necessary to use the

provided 4 in 1 charging cable to

connect your cell phone to either one of

the USB jacks.

• You can always enter

Pairing mode by pressing

and holding PAIR while

in either SEARCHING MODE or

BLUETOOTH STANDBY MODE.

• If during SEARCHING MODE

(Blue LED is ﬂ ashing steadily),

you wish to quickly connect

any other device Bluetooth

(including those previously

paired), simply press/hold the

PAIR button to enter PAIRING

mode, and proceed to PAIR

the Bluetooth device (see

PAIRING section).

• Generally when the user

disables wirelessthe Bluetooth

connection on a connected

Bluetooth device the ARS15

will enter Standby Bluetooth

mode which means that the

ARS15 would be available

for other previously paired

Bluetooth devices to connect

(See Standby Bluetooth

Mode section for more

information). However, in

some cases, the disabling of

Bluetooth wireless connection

on the connected Bluetooth

device may not result in the

ARS15 immediately entering

Bluetooth Standby mode, and

may enter Searching Mode.

(See Searching Mode section

for more information)

12 Month Limited Warranty

Applies to AR Dock Products

AUDIOVOX ACCESSORIES CORP. (the

Company) warrants to the original retail

purchaser of this product that should

this product or any part thereof, under

normal use and conditions, be proven

defective in material or workmanship

within 12 months from the date of

original purchase, such defect(s) will be

repaired or replaced with reconditioned

product (at the Company’s option)

without charge for parts and repair

labor.

To obtain repair or replacement

within the terms of this Warranty, the

product is to be delivered with proof

of warranty coverage (e.g. dated bill

of sale), speciﬁ cation of defect(s),

transportation prepaid, to the Company

at the address shown below.

This Warranty does not extend to the

elimination of externally generated

static or noise, to correction of

antenna problems, loss/interruptions of

broadcast or internet service, to costs

incurred for installation, removal or

reinstallation of product, to corruptions

caused by computer viruses, spyware or

other malware, to loss of media, ﬁ les,

data or content, or to damage to tapes,

discs, removable memory devices or

cards, speakers, accessories, computers,

computer peripherals, other media

Q: Cannot turn on the ARS15 when

charging.

A: The ARS15 will shut down to protect

itself from damage when charging

is overloaded. To resume operation,

disconnect the USB connection and

turn on the ARS15 again.

Q: Streaming stops and the Power

LED turns off when plugging in

device to the USB jack.

A: The ARS15 will shut down to protect

itself from damage when charging

is overloaded. To resume operation,

disconnect the USB connection and

turn on the ARS15 again.

Q: No sound or sound is very low.

A: Make sure the wireless Bluetooth

connection is correct and playback

has been successfully started. Check

the volume level of the ARS15

and your device. (See Bluetooth

Music Playback section for more

information)

players, home networks or vehicle

electrical systems.

This Warranty does not apply to any

product or part thereof which, in the

opinion of the Company, has suffered

or been damaged through alteration,

improper installation, mishandling,

misuse, neglect, accident, or by removal

or defacement of the factory serial

number/bar code label(s). THE EXTENT

OF THE COMPANY’S LIABILITY UNDER

THIS WARRANTY IS LIMITED TO THE

REPAIR OR REPLACEMENT PROVIDED

ABOVE AND, IN NO EVENT, SHALL THE

COMPANY’S LIABILITY EXCEED THE

PURCHASE PRICE PAID BY PURCHASER

FOR THE PRODUCT.

This Warranty is in lieu of all other

express warranties or liabilities. ANY

IMPLIED WARRANTIES, INCLUDING

ANY IMPLIED WARRANTY OF

MERCHANTABILITY, SHALL BE LIMITED

TO THE DURATION OF THIS WRITTEN

WARRANTY. ANY ACTION FOR BREACH

OF ANY WARRANTY HEREUNDER

INCLUDING ANY IMPLIED WARRANTY

OF MERCHANTABILITY MUST BE

BROUGHT WITHIN A PERIOD OF 24

MONTHS FROM DATE OF ORIGINAL

PURCHASE. IN NO CASE SHALL THE

COMPANY BE LIABLE FOR ANY

CONSEQUENTIAL OR INCIDENTAL

DAMAGES FOR BREACH OF THIS OR

ANY OTHER WARRANTY. No person or

representative is authorized to assume

for the Company any liability other than

expressed herein in connection with the

sale of this product.

Some states do not allow limitations on

how long an implied warranty lasts or

the exclusion or limitation of incidental

or consequential damage so the above

limitations or exclusions may not apply

to you. This Warranty gives you speciﬁ c

legal rights and you may also have

other rights which vary from state to

state.

Recommendations before returning

your product for a warranty claim:

• Properly pack your unit. Include

any remotes, memory cards, cables,

etc. which were originally provided

with the product. However DO NOT

return any removable batteries,

even if batteries were included

with the original purchase. We

recommend using the original

carton and packing materials. Ship

to the address shown below.

• Note that product will be returned

with factory default settings.

Consumer will be responsible to

restore any personal preference

settings.

Audiovox Electronics Corp.

Attn: Service Department.

150 Marcus Blvd.

Hauppauge N.Y. 11788

1-800-645-4994

For Canada Customers, please ship to:

Audiovox Return Centre

c/o Genco

6685 Kennedy Road,

Unit#3, Door 16,

Mississuaga, Ontario

L5T 3A5

• You may use both USB

jacks at the same time.

• Charging function may

not be supported for all

phones, tablets or electronic

devices.

• The adapters provided may not

work with all devices.

• The provided 4 in 1 charging

cable works with some models

from

• Blackberry

• Nokia

• Samsung

• HTC cell phones only.

Use the appropriate USB cable

provided with your cell phone

or tablet if your brand is not

listed above.

• Charging function is always

enabled as long as the

AC/DC adapter is plugged in

and connected.

• Note that it may be

necessary to resynchronize

the volume control if the

Bluetooth device goes out

of range or if a new Bluetooth

device is paired.

• You can always enter

Pairing mode by pressing

and holding PAIR while in

either SEARCHING MODE or

BLUETOOTH STANDBY MODE.

For charging tablet devices.

This jack may also be used

for charging other mobile

devices.

Bluetooth Standby mode

If the most recently connected

Bluetooth device can not be found

within three minutes during Searching

Mode, then the ARS15 will revert to

BLUETOOTH STANDBY MODE. The

Blue LED will ﬂ ash slowly while in

this STANDBY MODE. BLUETOOTH

While in this mode, the ARS15 will

accept connection from any previously

paired devices (up to 8 Bluetooth

devices). Simply initiate the connection

to the ARS15 on your device. Bluetooth

See your device for more Bluetooth

information.

Also note that you can re-enter

SEARCHING mode by a single press of

the PAIR button.

Bluetooth range

The wireless technology Bluetooth

generally can operate within a range

of 35 feet or more. However results

may vary based on other factors such

as room layout, wall material, weather

conditions, etc. Also, note that when a

mobile device goes out of range, the

ARS15 will enter Searching mode and

will attempt to automatically reconnect

to the mobile device when that mobile

device comes back into range. (See

Searching Mode section for more

information)

Connection indicators

Status

Pairing mode

Bluetooth

connection

made

Searching

mode (auto-

connect to the

most recent

connected

device)

Bluetooth

Standby mode

(available for

connection from

any previously

paired device)

Power off

mode

Blue LED Red LED

(Bluetooth (Power

connection indicator)

indicator)

Flash alternatively

On On

Flash On

Flash slowly On

Off Off

Bluetooth connection and power

indicators:

Q: My paired device can Bluetooth

not reconnect to the ARS15.

A: Press and hold PAIR to enter Pairing

mode again. A reconnection may

fail due to :

• The pairing information has been

deleted from your device.Bluetooth

• You may have exceeded the

allowable number of paired devices

for the ARS15. Only 8 Bluetooth

devices may have their pairing

credentials stored at one time.

Simply follow the above instructions

for Pairing to have a device paired

again. However remember that the

ARS15 can only store credentials

for 8 devices. Therefore the earliest

paired device will be removed from

that list of 8 to make room for the

device you wish to Pair.

Produktspecifikationer

Varumärke:	Audiovox
Kategori:	Vagga/dockningsstation
Modell:	ARS15

Behöver du hjälp?

Om du behöver hjälp med Audiovox ARS15 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Vagga/dockningsstation Audiovox Manualer

Audiovox RC66i Bruksanvisning

18 September 2024

Audiovox RC60i Bruksanvisning

18 September 2024

Audiovox ARS15 Bruksanvisning

18 September 2024

Vagga/dockningsstation Manualer

Nyaste Vagga/dockningsstation Manualer

Pyle PHST92IBK Bruksanvisning

20 Oktober 2024

Roberts R100 Bruksanvisning

19 Oktober 2024

Yamaha ISX-800 Bruksanvisning

18 Oktober 2024

Polk BOOM Bit Bruksanvisning

16 Oktober 2024

Vorago KSP-600 Bruksanvisning

8 Oktober 2024

IDance Mini Blaster 2L Bruksanvisning

7 Oktober 2024

Pyle PWPBT05BL Bruksanvisning

5 Oktober 2024

Ewent EW7018 Bruksanvisning

5 Oktober 2024

Jam Splash Bruksanvisning

5 Oktober 2024

Denver BTG-615 Bruksanvisning

5 Oktober 2024
