www.avsl.com 122.380UK User Manual
Bluetooth® Receiver Wallplate
and Backbox
Item ref: 122.380UK
User Manual
A Bluetooth receiver conveniently housed in a standard 1gang plastic wallplate which allows connection of
Bluetooth enabled devices such as smartphones, tablets, iPods etc. Ide for use in classrooms, boardrooms, al
kitchens or home studies, the unit comes supplied with a UK power supply and a 50mm back-box for easy
installation.
Technical Specifications and Features
Bluetooth version
5.0
Bluetooth range
Up to m (in clear line of sight) 10
Audio input
Bluetooth or stereo line level (3.5mm jack)
Audio output
Stereo 3.5mm jack or 3-pin screw terminal
Power in
5VDC/1A via UK PSU (supplied) or 2-pin screw terminal
Dimensions
87 x 87 x 35 (wallplate only)
Weight
48g
Bluetooth Pairing Instructions
• For first time pairing to a new device press and hold the Pairing button for around seconds until the , 5
BT status light on the unit flashes quickly.
• Open the Bluetooth device list on your smart device and select the pairing name Music BT “ ”
• When the device is connected the BT status light on the unit stays illuminated.,
• The pairing timeout limit is 90 seconds. If pairing has time out, press d hold Pairing button d an the
again for 1 second to re-enter pairing mode.
• To the unit on and off, press and hold the Pairing button again for around 3 seconds. turn
• When you turn the unit on any previously connected smart devices will automatically repair provided,
they are with the 10m transmission range and set as discoverable. in
• NOTE: the unit can only be connected to one smart device at any time and will automatically repair
with the closest device.
Bluetooth LED Status
• Pairing mode: Fast flash (approx. 1 every second)
• Discoverable mode: Slow flash (approx. 1 every 5 seconds)
• Paired mode: LED on
In the box
• Bluetooth receiver wallplate
• 50mm Standard backbox
• UK Power supply
• 2pcs Fixing screws
• user guide
www.avsl.com 122.380UK User Manual
Connection Diagram
Warning
• For reasons of electrical safety, this device must never be immersed in water, expose to damp conditions d
or excessive force.
• Please do not use this device if you find that it is damaged in any way.
• Do not attempt to repair this device or take it apart under any circumstances, as this will invalidate your
warranty.
• Only use the recommended power supply ovided and if connecting to mains power internally consult a pr
qualified electrician to carry out the installation.
• Do not locate this devi close to a source of heat or expose to high temperatures. ce
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at
the end of its useful life. The goods must be disposed of according to your local council guidelines.
Hereby, AVSL Group Ltd. declares that the radio equipment type 122.380 complies with Directive 2014/53 U : UK /E
The full text of the EU declaration of conformity for 122.380UK is available at the following internet address:
http://www.avsl.com/assets/exportdoc/1/2/122380UK%20CE.pdf
Errors and omissions excepted.
Copyright© 2021 AVSL Group Ltd Unit 2 Bridgewater Park, AVSL (Europe) , Unit 3D North Point House, , Ltd
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
