Advanced Secure DisplayPort™ KVM

User Manual

F1DN102P Advanced Secure 2-Port DisplayPort KVM

F1DN104P Advanced Secure 4-Port DisplayPort KVM

F1DN104W Advanced Secure 4-Port DisplayPort Dual-Head KVM

F1DN104Q Advanced Secure 4-Port Quad-Head KVM

Document Number 8820-01343 Rev. A00

Belkin® Advanced Secure DisplayPort KVM

TABLE OF CONTENTS

SECTIONSTable of Cont e nts 12345678SECTIONS 12345678Table of Cont e nts

Operating the KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Common Access Card (CAC) Configuration and Operation . . . 18

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Reporting Belkin Product Security Vulnerability . . . . . . . . . 25

Introduct ion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Other Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Equipment Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Unit Display Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Pre-Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connection and Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Color Code Chip Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Belkin® Advanced Secure DisplayPort KVM

INTRODUCTION

SECTIONSTable of Cont e nts 12345678SECTIONSTable of Cont e nts 12345678

BACK TO TABLE OF CONTENTS >

Thank you for purchasing this Belkin Secure DisplayPort KVM. This

Switch is designed for use in secure environment installations. The

Switch offers safe centralized control, which prevents unintended data

transfer between computers running at different security levels. The

Switch provides the highest security safeguards and features that meet

today’s Information Assurance (IA) computing requirements.

Belkin Advanced Secure DisplayPort KVM is especially challenging in

terms of security as DisplayPort is a very robust protocol by nature,

which is capable of transferring various types of information, such as

USB and Ethernet other than display. Belkin has developed this unique

Secure KVM switch with the highest possible security in mind, assuring

no leakage of information between connected computers through any

channels including DP dedicated channels.

This User Manual provides all the details you’ll need to install and

operate your new Switch, in addition to expert troubleshooting advice—

in the unlikely event of a problem.

Package Contents

• Belkin Advanced Secure DisplayPort KVM

• 12V 1.5A DC Power Supply (F1DN102P, F1DN104P)

• 12V 3A DC Power Supply (F1DN104W, F1DN104Q)

• Interchangeable Port Color Chips

• Port-Naming Labels

• User Manual

Important: This product is equipped with an always-on active

anti-tamper system. Any attempt to open the enclosure may

activate the anti-tamper system and render the unit permanently

inoperable. If the unit’s enclosure appears disrupted or if all the

port LEDs flash continuously, please call Belkin Technical Support

toll-free at (800) 282-2355.

Reporting Belkin Product Security Vulnerability

If you are aware of potential security vulnerability while installing or

operating this product, we encourage you to contact us immediately

at the following email address:

gov_security@belkin.com

Please note: Belkin Secure KVMs cannot be upgraded, serviced or

fixed.
