POWERNODE
WIRELESS STREAMING AMPLIFIER
OWNER’S MANUAL
Included Accessories
Thank you for purchasing your POWERNODE. It is a network music streaming amplifier that conveniently
bring the enjoyment of hi-resolution audio to everyday life. Simply add a pair of loudspeakers to create the
ultimate two-channel system, which can also be grouped with other Bluesound players to create
multi-room listening experiences.
JUST ADD SPEAKERS. The POWERNODE is the amp reinvented, the streaming amplifier that merges
several traditional components into one and unlocks a world of high-fidelity streaming. Source, control,
and amplification come packed into the compact and minimalist POWERNODE, allowing you to stream
your music from dozens of sources to your favorite speakers effortlessly.
HI-RES MUSIC. EVERYWHERE. One or many rooms, the POWERNODE is a versatile workhorse for any
listening set-up. Just add speakers for a traditional two-channel audiophile-grade listening system. Add
the wireless PULSE SUB+ to create an enhanced 2.1 experience, plus a pair of PULSE FLEX 2i speakers
as rear channel additions to create a Dolby surround sound wireless home theater. Or sprinkle other
Bluesound players around your home for a whole-home, multi-room audio solution.
PLAYS WELL WITH OTHERS. The POWERNODE is equipped with an array of digital and analog inputs,
including HDMI eARC, dual-band Wi-Fi, Gigabit Ethernet, Apple AirPlay 2, aptX HD Bluetooth, digital
optical, 3.5mm auxiliary, and USB. Stream music through your POWERNODE from dozens of internet
radio stations and premium music services, or connect your Bluetooth devices, CD Players, Apple devices,
network or local hard drives, or your TV for a serious upgrade to your TV audio.
This Owner’s Manual will provide you with a more detailed overview of your POWERNODE and its
features. It also includes some troubleshooting tips and tricks and networking best practices. The Quick
Setup Guide included with your POWERNODE will help you get it on the network and ready to listen to
your music.
If you need more help or information please visit support.bluesound.com or send us an
email at support@bluesound.com
WELCOME TO #LIVINGHIFI
2
2x Mini Jack to Toslink Adaptor
120V AC Power Cord
230 V AC Power Cord
Ethernet Cable
STATUS INDICATOR Below is a table of the LED blink codes and their corresponding descriptions
4
LED BLINK CODE DESCRIPTION
Short blue flash, then red Powering up, rebooting the unit
Solid green Hotspot Mode
Flashing green Connecting to Network
White pulse Software update available
Solid red Upgrade Mode
Alternate flashing red and green Upgrading
Flashing blue Mute Mode
Solid white Indexing
Solid blue Connected to Network – ready to use with BluOS App
Flashing red Factory Reset in process
Solid purple Hotspot Mode timed out
4
PLAY/PAUSE BUTTON This button has multiple functions – a visual indicator of network connectivity and a PLAY/PAUSE
button. For a full listing of LED Blink Codes, please see #4 – Blink Codes. For an ungrouped Player, press the button to
Play and Pause the stream. If listening to an internet radio stream, the Pause- function will work for 30 seconds. At this
point, the buffer is full and the stream will Stop. When a Player is grouped, pressing the PLAY/PAUSE button will Mute
that Player while other Players continue the stream. The Player’s LED will flash blue when muted. This button is also
used for Factory Reset functions. See steps for Factory Reset later in this manual.
HEADPHONE JACK A 3.5mm headphone jack is located on the front of the POWERNODE.
OPTICAL/ANALOG IN 1 Using a 3.5mm Stereo Audio Cable (not provided), connect one end to the Analog In of the
POWERNODE and the other end to the corresponding analog output of other compatible devices. The source will show as
an Analog Input 1 in the BluOS App. Using the 3.5mm Mini Jack to Toslink adaptor (included with the POWERNODE), a
digital optical source can also be added. This will appear as Optical Input 1 in the BluOS App.
SUBW (SUBWOOFER) OUT A subwoofer can be connected directly to the POWERNODE. Connect SUBW OUT to a
powered (“active”) subwoofer. By default, a crossover is applied at 80Hz meaning audio below 80Hz is transmitted
through the SUBW OUT. Alternatively, you can connect the NODE to a Bluesound PULSE SUB+ over the network.
7
8
5
6
1PRESETS The POWERNODE has 5 programmable preset buttons. These presets are configured using the presets
menu in the BluOS App.
VOLUME SLIDER/TAP Use the LED slider to vary volume level. Tap the • buttons at either end of the slider to vary the
volume level in 1db intervals, or tap the slider in the direction you wish to adjust to vary the level by 3db intervals. These
volume tap methods allow you to fine-tune your volume setting.
PREVIOUS TRACK/NEXT TRACK These buttons can be used to go back to the previous track or skip to the next track in
your current play queue.
2
3
