Sida 1/3
MATTERS OF SAFETY FIRST
WARNING
■
●
■
●
■
●
■
●
●
■
●
SPECIFICATIONS
SOUND PRESSORE LEVEL FREQUENCY RESPONSE
●
■
●
●
●
●
●
■
●
●
■
●
■
●
●
●
●
BEFORE USE
●
●
●
●
●
●
●
●
●
Based on security, before the correct use of this product, please carefully read through the instructions again.
After reading, please keep it for future reference.
The rated impedance of this speaker system is 8 . It must be connected to a amplifier which accepts this type of load (miminum and maximum
impedances accepted by the amplifier are generally indicated near the loudspeaker outlets: for example "4 -16 " or "6 -16 ").
Any connection or switching on or off of part of the audio system (CD player, tuner etc.) must be carried out after switching off the amplifier or
at least with the loudspeaker outlets disconnected (if the amplifier allows). Interference caused by these operations will otherwise reach the
speaker and may damage the treble loudspeaker units.
When boosting particular frequencies using a graphic equaliser or bass and treble correctors, make sure that you do not increase the amplif-
ier volume excessively, as the speaker will be overloaded more quickly.
Ω
Ω Ω ΩΩ
Do not force a low-power amplifier to produce a high level of sound as harmonic distortion increases rapidly in this situation and may pose
a danger to the treble speaker units.
The maximum input power of these speakers is 1000 W (at peak). Higher levels of input power may cause dam age to the speaker system and so
take every precaution to keep the power down to the specification.
Avoid touching the diaphragms and suspensions of speakers units as they are fragile.
●
INSTALLING THE SPEAKERS
Avoid installing the speakers in a location exposed to direct sunlight and high levels of humidity.Avoid also locations in the vicinity of stoves
and other sources of heat.
For optimum sound reproduction of high frequencies, the treble speaker units must be at the same height as the listener's ears.
●
For low frequencies, it is possible to increase the level of bass sounds by positioning the speakers close to a wall (the maximum incre-
ase being obtained for a position in a corner of the listening room).
Do not install your speakers overhead on the ceiling or wall.
A carrying handle is provided on the both side of the speaker (when horiz-
ontal). Use this if you need to move the speaker short distances.
This speaker system is not magnetically shielded. However, depending on the installation location, color distortion may occur if the speaker
system is intalled extremely close to the screen of a television set. If this happens, turn off the television, then turn it on again after 15 to 30
minutes. If the problem persists, place the speaker system away from the television set.
CONNECT TO AMPLIFIER
There are two connection terminals on the rear side of the speaker:SCREW type and SPEAKON type.
Use whichever is convenient.
Be careful not to short the two pins of the free speaker terminal. Doing so could damage the speaker and/or your amplifier.
SCREW type CONNECTIONS
1. Switch off the powerof your amplifier.
2. Connect the speaker cables to the input terminals on the back of the speaker.
For input terminal polarity, red is positive (+) and black is negative (–).
3. Connect the other ends of the cables to the amplifier’s speaker output terminals (for details, refer to your amplifier’s instruction manual).
After connecting the plugs, pull lightly on the cables to make sure that the ends of the cables are securely connected to the terminals.
Poor connections can create noise and interruptions in the sound.
If the cables’ wires happen to be pushed out of the terminals, allowing the wires to come into contact with each other, it places an excessive
additional load on the amplifier. This may cause the amplifier to stop functioning, and may even damage the amplifier.
－ －+ +
Turn the thumbscrew anti-clockwise,
the speaker cord is inserted well into the hole
Turn the thumbscrew clokwise
To connect the speaker to your amplifier you will need a suitable speaker cord terminated in a Neutrik Speakon speaker connector [NL4MP].
Only the 2+ and 2– pins should be connected. These connect to the positive (+) and negative (–) speaker terminals respectively on the amp-
lifier.Neutrik [NL4FX] and [NL4FC] Speakon speaker cord canbe used for the connection. Please refer to Neutrik for more informatio.
●Connect the speaker cables to the amplifier’s speaker output terminals:
Speakon 2+ +amplifier
Speakon 2- amplifier -
®
－ －+ +
< MATTERS OF SAFETY FIRST > is to prevent harm to you or others, property loss, to a variety of pattern identification.
The identification and significance of pattern, please fully understand before you continue reading.
If ignore this logo, misuse, may cause serious injury or even death.
If ignore this logo, misuse, may cause damage of the goods or injuries.
PATTERN REPRESENTATION OF CASES
Mark is told to pay attention to the content ( with a warning ). Pattern of the intermediate drawing attention
to concrete content
( this description refers to the attention of electric shock ).
Mark is to inform the prohibited acts. Pattern of intermediate describe specific content prohibited.
(left picture it means no decomposition ).
Mark is inform compulsive behavior, content. Pattern of the intermediate drawing indicates the specific content
( this description refers to the power plug from the socket ).
FAULT STATE DO NOT CONTINUE TO USE
In case, continue to use the emergence of smoke, odor, noise and other abnormal condition, will cause fire,
electric shock, amplifier fault.Immediately turn off the amplifier, must pull out the power plug from the socket.
Confirmation until stopped smoking, to rely on sales shop.
DO NOT TRANSFORMATION
Don't alter or decomposition of the products. May result in fire, electric shock.
DON NOT PUT IN THE POSITION OF WATER
This product can not be water, do not get wet. Water, wet may result in fire, electric shock.In the rainy day,
snow day, coast, water use should be paid special attention to the.
CANNOT BE WATER CONTAINERS ARE PLACED
Don't use a vase, potted plant, glass, cosmetics, pharmaceuticals, container with water and small metal ite-
ms in the product.The water spill, into the inside of the machine will cause fire, electric shock.
In case of the machine, water, immediately turn off the amplifier, unplug the power plug from the socket, an-
d then contact the sales shop.Continue to use, will cause fire, electric shock.
DON NOT BE FOREIGN BODY INTO THE INTERIOR
In case, foreign body into the machine, turn off the amplifier power, unplug the power plug from the socket,
and then contact the sales shop.Continue to use, will cause fire, electric shock.
Type
Floor-standing type, bass-reflex
Speaker units 38 cm Cone Type Woofer x1
Nominal Impedance
8Ω
Frequency response 40Hz 4,000Hz～
Sound pressure level 95dB/W/m
Input power
Maximum input power 1000W
Rated input power 600W
Dimensions W410 x H545 x D545mm
Mass 30kg
ACCESSORIES Owner’s manual x1
Registration card x1
APPEARANCE DRAWING
……………………………
…………………………
…………………………………………
……………………………
………………………………
…………………………………
……………………………………
………………………………………
…
……………………
………………………………………………………
………………………
Can not be placed in the shaking of the table upper unstable place. Falling down, falling down can lead to
injuries.
INSTALLING
Move the product, do not hand grasping the iron net, the speaker unit. May cause injury.
Moving the product, turn off the amplifier, unplug the power plug from the socket, remove the speaker cable
and mobile.Or will lead to cable damage, cause fire, electric shock.
The product is placed on TV, audio equipment, do not move the product. Articles collapse cause injury.
This product can not be placed over 10kg weight and ratio of large size items.
The imbalance will make the goods fall, fall and hurt.
CAN NOT SET IN THE FOLLOWING AREAS
Can not be placed in the food processing machine, humidifier, steam soot place. May result in fire, electric
shock.
Can not be placed in damp, dusty places. May result in fire, electric shock.
ON CONNECTION
The machine and other audio equipment, television sets and other machine connection, please read
carefully the instructions of each machine,Switch off the power supply, follow the instructions.
NOTE AT WHEN USING
Switch on the power set the volume to a minimum. All of a sudden loud noise can cause hearing impairment.
Don't use long time voice distortion under the state. The speaker fever will cause fire
Please don't sit on or suspended in the loudspeaker. Special attention should be paid to the child. Collapse, da-
mage can result in injury.
Cash card, disk with magnetic products do not close. The speaker magnetic will affect the products, the use of
data Disappear.
Position(straight ahead from the woofer)
SPL (dB)
02 002001 K02K01K5K2K1005
07
08
09
001
06
011
Impedance ( )Ω
02 002001 K02K01K5K2K1005
8
61
23
46
4
CAUTION
●
●
ROTATED THE BADGE
The badge of the products can be rotated.
Nameplates rotation when pulled out be careful not to use excessive force in order to avoid badge or iron mesh deformation.
●
●
MAINTENANCE OF CABINET
When the cabinets are dirty, clean off the dirt with a soft cloth.
If the dirt is engrained, moisten a soft cloth in cold or lukewarm water, wring it out, and then wipe off the dirt. Never use thinners or alcohol
since these substances can impair the finish of the cabinet.Also, avoid usinginsecticide and other sprays near the speakers.
SUBWOOFER SYSTEM
CSW-600(SE)
OWNER’S MANUAL
THANK YOU VERY MUCH FOR PURCHASING THIS SPEAKERS SYSTEM.
READ THE INSTRUCTION MANUAL CAREFULLY BEFFOR USING THIS SPEAKERS SYSTEM SO THAT YOU CAN OPERATE IT PROPERLY.
AFTER YOU HAVE FINISHED,PUT THIS MANUAL AWAY IN A SAFE PLACE FOR FUTURE REFERENCE.
WARNING
SPEAKER’S INPUT TERMINALS AMPLIFIER’S OUTPUT TERMINALS
SPEAKON type CONNECTIONS
1. Switch off the powerof your amplifier.
2. Connect the speaker cables to the speaker connector on the back of the speaker.
For input terminal polarity, red is positive (+) and black is negative (–).
3. Connect the other ends of the cables to the amplifier’s speaker output terminals (for details, refer to your amplifier’s instruction manual).
Plug thespeaker cord connector into the speaker’s input terminal,
turn clockwise to lock it in place
Squeeze the lever on the speaker connector with your thumb, then
twist the whole connector counterclockwise and pull out.
SPEAKER’S INPUT TERMINALS AMPLIFIER’S OUTPUT TERMINALS
…
…
…
………
STANDARD FREQUENCY RESPONSE
IMPEDANCE FREQUENCY RESPONSE
The specifications and design of this product are subject to change without notice, in the interests of improvements.
CAUTION
