VM-1000

TTL MACRO FLASH SET

User Manual

2 | Introduction

Thank you for choosing Bolt.

The Bolt VM-1000 is a full-featured wireless macro

ﬂash for your Nikon, Canon, or Sony camera. This

advanced digital ﬂash system puts creative control

in your hands with a broad range of automatic and

manual features. It can be used to illuminate close-up

subjects with multi-ﬂash setups and ﬂexible wireless

communication.

Enjoy automatic TTL settings with the ability to use

up to three groups and sixteen channels without

interference. Change auto ﬂash compensation values

or set ﬂash power manually. With the included Macro

Flash Ring, you can use up to four VM-1010 ﬂash units.

You’ll be able to experiment with light and customize

lighting settings to illuminate close-up subjects.

Table of Contents

Precautions 3 ..........................................................

Contents 5 ...............................................................

Overview 6 ..............................................................

Battery Installation 12 .............................................

Transceiver and Flash Setup 14 ..............................

VM-1010 Flash Settings and Controls 20 ................

VM-1020 Transceiver Settings and Controls 22 ......

Speciﬁcations 32 .....................................................

Troubleshooting 34 .................................................

Firmware Upgrade 35 .............................................

FCC Compliance 35 .................................................

Precautions | 3

Precautions

⚠ ⚡

• Before using this product, please thoroughly read the

following safety notices to ensure safe use and help

prevent damage to your ﬂash or injury to yourself and

others.

• Do not ﬁre the ﬂash at close range directly into the eyes

of people or animals. This can cause damage to the

retina and may even lead to blindness.

• To avoid overheating and damaging your ﬂash unit,

please wait for at least ten minutes after twenty-ﬁve

continuous ﬂashes at full power.

• Do not disassemble or attempt to repair this product

yourself. There are high-voltage components inside that

can produce a hazardous electric shock.

• Keep this product and its batteries out of the reach of

children.

• Use only the power sources speciﬁed in this manual.

• Always switch the ﬂash o before changing the batteries.

• Always install batteries of the same type, brand, and

age. Do not combine dierent types or brands, or old

and new batteries. This can cause the batteries to leak,

overheat, or explode. Install the batteries in the proper

orientation, according to the indicator in the battery

chamber. Installing batteries in the reverse orientation

may cause them to leak, overheat, or explode.

• Do not clean this product with agents containing

corrosive or ﬂammable substances such as paint thinner,

benzene, or nail-polish remover.
