WARNING

For safe driving, driver should not watch the monitor or operate the device.

Do not drop the device.

Do not spill any liquid on the device.

Don’t try to repair or modify the device yourself, it will void the guarantee and can cause injury

Connecting the device should be trusted to an expert technician. Please refer to the connecting

diagram.

Make sure the device is switched off when starting the engine. Otherwise it may result in

battery damage or failure of starting up the engine

TECHNICAL SPECIFICATIONS

Screen size: 7 inch

Pixel resolution: 480 x 234

Brightness: 200cd/m2

Contrast: 300:1

Viewing angle: 120º

Operating supply: 11~15V (Typical: DC 12V)

Power consumption: 12W

Standby Power Consumption: 1W

IR Headphone output:

CH A: 2.8Mhz/2.3Mhz

CH B: 3.8Mhz/3.2Mhz

Storage temp. -20ºC ~ +60ºC

Video output level: 1Vp-p, 75 (composite)Ω

Video input level: 1Vp-p, 75 (composite)Ω

Audio input level: 300mV / 47KΩ

Dimensions: 275(W)x205(H)x115(D)mm

Weight: 1.80kg

Playback formats: DVD/ CD/ VCD/ DVCD/ MP3/ WMA/ DivX

Remote control

ø 14mm

Use the supplied assembling stick to modify

the distance, before installation!

MHM 272DVD QUICKSTARTGUIDE

GB • F • D • I • E • P • SW • PL • GR • CZ/SK • NL

MHM 272DVD INSTALLATION

MHM 272DVD SETUP

DVD SET UP MENU

Press setup button on the remote control at DVD mode and DVD SETUP menu will appear.

You can move or select the menu by pressing , , ENTER button.

GENERAL SETUP PAGE

• TV Display

- Normal TV Pan ScanNormal / Ps:

- Normal TV Letter BoxNormal / Lb:

- Wide Screen TV Wide:

• Angle Mark

- Show on the current screen angleOn:

- Off: Show off the angle

• OSD Lang

- To set the on-screen display language in EnglishEnglish:

- To set the on-screen display language in ChineseChinese:

• Last memory

- On: Use the last memory function, record and play the loaded position of the disc

before closing/opening

Current mode change or Power On/Off, does not record.

- Last memory function off.Off:

VIDEO QUALITY PAGE

• Use to adjust brightnessBrightness:

• Use to adjust contrastContrast:

• Use to adjust tintHue:

• Use to adjust saturationSaturation:

PASSWORD SETUP PAGE

• Password

- Change: Change the password

PREFERENCE PAGE

• TV Type: Set TV Standard

• Audio: Preferrred Audio Language

• Subtitle: Preferred Subtitle Language

• Disc Menu: Preferred Menu Language

• Parental: Set Parental Control

• Default: Load Factory Setting

DVD PLAY MENU

Press DISC INFO button of remote control, PLAY menu will appear.

Press , button to select Title/Chapter/Subtitle/Angle/Tt Time/Ch Time/Repeat/Time Disp,

operate with , .

OPERATING INSTRUCTIONS

Monitor menu

Press CONSOLE button of remote control, Picture menu will appear.

Press , button to select BRIGHTNESS/CONTRAST/COLOR, Press , to adjust

BRIGHTNESS/CONTRAST/COLOR; Press , button and select RESET to reset the device.

Other functions

Use the power ON/OFF to turn the device on or off.

Press PBC to return to the main menu or title menu while playing DVD disc.

Shows the main film content, accompanying feature content, additional feature content or
