Sida 1/20
Portable Pourover Coffee Brewers
Operator Manual
CPO-1P
CPO-1P-E
CPO-2P
CPO-2P-E
CPO-2CP
CPO-3P
CPO-3P-E
CPO-3CP
CPO-3RP
CPO-3RP-E
CPO-3RCP
CPO-4RP
CPO-4RP-E
CPO-5RP
CPO-5RP-E
CPO-SAPP
CPO-SAPP-E
©2015 GMCW
Printed in Thailand
0715 Form # BW-328-01
Part # 390-00038
GMCW
4003 Collins Lane, Louisville, KY 40245 USA
Phone: 502.425.4776 Toll Free: 800.695.4500
Fax: 502.425.4664
Web: gmcw.com Email: info@gmcw.com
Model CPO-3P
Specifications...........................2
Safety Information..................3
General Information...............4
Installation...............................4
Operation ................................4
Cleaning & Maintenance........5
Troubleshooting Guide...........7
Parts Diagram and List ...........8
Wiring Diagram.....................17
Thank you for purchasing this quality coffee brewer. For your safety and the safety of others, read all
warnings and the operator’s manual before installing or using the product. Properly instruct all operators.
Keep training records. For future reference, record serial number here:
Table of Contents
GMCW provides the industry’s BEST
warranty. Visit gmcw.com for warranty
terms and conditions.
Specifications
2 Grindmaster®Portable Pourover Coffee Brewers
Model CPO-3P
Model Part No. Certifications No. of Warmers Electrical Product Dimensions
(H x W x D)
CPO-1P-15A (0002-10001) NSF Sanitation;
NSFus Electrical
1 bottom 120V / 15A / 1500W / 1 Ph 17.5” x 8.12” x 18.35”
CPO-2P-15A (0002-20001) NSF Sanitation;
NSFus Electrical
2 total:
1 top, 1 bottom
120V / 15A / 1600W / 1 Ph 18.5” x 8.12” x 18.35”
CPO-2CP-20A (0002-20003) NSF Sanitation;
NSFus Electrical
2 total:
1 top, 1 bottom
120V / 20A / 1600W / 1 Ph 18.5” x 8.12” x 18.35”
CPO-3P-15A (0002-30001) NSF Sanitation;
NSFus Electrical
3 total:
2 top, 1 bottom
120V / 15A / 1700W / 1 Ph 18.5” x 8.12” x 18.35”
CPO-3CP-20A (0002-30003) NSF Sanitation;
NSFus Electrical
3 total:
2 top, 1 bottom
120V / 20A / 1700W / 1 Ph 18.5” x 8.12” x 18.35”
CPO-3RP-15A (0002-30005) NSF Sanitation;
NSFus Electrical
3 total: 1 right top,
1 bottom, 1 right bottom
120V / 15A / 1700W / 1 Ph 17.5” x 16.2” x 18.35”
CPO-3RCP-20A (0002-30007) NSF Sanitation;
NSFus Electrical
3 total: 1 right top,
1 bottom, 1 right bottom
120V / 20A / 1700W / 1 Ph 17.5” x 16.2” x 18.35”
CPO-4RP-20A (0002-40001) NSF Sanitation;
NSFus Electrical
4 total: 1 top, 1 right top,
1 bottom, 1 right bottom
120V / 20A / 1900W / 1 Ph 18.5” x 16.2” x 18.35”
CPO-5RP-20A (0002-50001) NSF Sanitation;
NSFus Electrical
5 total: 2 top, 1 right top
1 bottom, 1 right bottom
120V / 20A / 1900W / 1 Ph 18.5” x 16.2” x 18.35”
CPO-SAPP (0002-00003) NSF Sanitation;
NSFus Electrical
No warmers -
brews into airpot
120V / 15A / 1400W / 1 Ph 25” x 8.12” x 18.35”
CPO-1P-E (0002-10004) 1 bottom 240V / 16A / 2600W / 1 Ph 17.5” x 8.12” x 18.35”
CPO-2P-E (0002-20004) 2 total:
1 top, 1 bottom
240V / 16A / 2700W / 1 Ph 18.5” x 8.12” x 18.35”
CPO-3P-E (0002-30008) 3 total:
2 top, 1 bottom
240V / 16A / 2800W / 1 Ph 18.5” x 8.12” x 18.35”
CPO-3RP-E (0002-30009) 3 total: 1 right top,
1 bottom, 1 right bottom
240V / 16A / 2800W / 1 Ph 17.5” x 16.2” x 18.35”
CPO-4RP-E (0002-40002) 4 total: 1 top, 1 right top,
1 bottom, 1 right bottom
240V / 16A / 2900W / 1 Ph 18.5” x 16.2” x 18.35”
CPO-5RP-E (0002-50002) 5 total: 2 top, 1 right top
1 bottom, 1 right bottom
240V / 16A / 3000W / 1 Ph 18.5” x 16.2” x 18.35”
CPO-SAPP-E (0002-00006) No warmers -
brews into airpot
240V / 16A / 2500W / 1 Ph 25” x 8.12” x 18.35”
Portable Pourover Coffee Brewers Grindmaster®3
Safety Information
Important Safety Information
This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
For your safety and the safety of others, read all warnings and the operator’s manual before installing or using
the product.
DANGER: This term warns the user of imminent hazard that will result in serious injury or death.
WARNING: This term refers to a potential hazard or unsafe practice, which could result in serious injury or death.
CAUTION: This term refers to a potential hazard or unsafe practice, which could result in minor or moderate
injury.
NOTICE: This term refers to information that needs special attention or must be fully understood.
The brewer must only be connected to a dedicated, grounded electrical circuit (refer to serial tag on machine•
for voltage and amperage requirements).
To prevent the possibility of electrocution, burns, or other injuries and to prevent damage to your brewer,•
do not immerse in water or any cleaning liquids.
Do not operate a damaged brewer. Inspect the power supply cord and water supply often. If cord or plug is•
damaged or worn, do not use your brewer. Disconnect the electrical power.
Turn off and unplug the brewer before cleaning or maintenance. Allow brewer to cool before cleaning or•
maintaining.
Disconnect power if the machine functions abnormally and notify qualified service personnel for repairs.•
Do not permit non-qualified service personnel to attempt repairs. No user serviceable components inside•
the brewer. Do not disassemble the brewer.
FAILURE TO COMPLY RISKS PERSONAL INJURY, SHOCK HAZARD, FIRE, OR DAMAGE TO EQUIPMENT.
WARNING
Risk of burns. The brewer uses 185°F - 200°F water that, if not properly handled, could cause burns. Do not•
permit children to use this appliance unless there is direct adult supervision. Keep away from pets and other
animals.
For indoor use only. Do not install or use outdoors, in moving equipment, or watercraft.•
Use the product for its intended purpose only. Any other usage is inappropriate and may be dangerous. The•
manufacturer assumes no responsibility for injury, loss, or damage resulting from improper machine use.
Hot surfaces may cause burns. Do not touch the brewer while in operation.•
To prevent scalding by hot water, do not remove the brew basket while in operation. •
To prevent scalding by hot water, do not move or tilt the brewer. Moving or tilting the brewer could result•
in water spilling from the reservoir.
CAUTION
A qualified professional should perform maintenance and repairs.
Installation, maintenance, or repairs by unqualified personnel may damage the brewer and void the
manufacturer’s warranty.
This equipment must be installed in accordance with the appropriate national and local codes of the country
and/or region in which the appliance is installed.
Contact the manufacturer to report any malfunction of or damage to the brewer.
When turning the machine off for an extended period, be sure to evacuate the water inside the piping
completely, otherwise the water inside the machine could freeze and lead to damage or cause mold to appear.
NOTICE
