Sida 1/26

USER MANUAL

WIFI-SPEAKER

AWF310, AWF320, AWF330 & AWF340

ENG

This manual contains important notes and instructions for use. Before using the product,

please read the manual carefully. Please keep the manual after reading for future use.

Important information

Please read and understand all the instructions before using the product. Damage caused by failure to

comply with the instructions will not be covered by the warranty.

Risk of electric shock or re

• Do not let the product and accessories get in contact with rain or water.

• do not put any liquid containers, such as for example vases, next to the product.

• If the liquid ows inside the product, please immediately shut down the product and contactcustomer service cen-

ter.

• Do not place the products and accessories near re or other heat sources, including direct sunlight.

• In the case of lightning and thunder, the product should be shut down and unplugged from powersource.

Beware of short-circuited or re

• Before the product is connected to a power supply socket, please ensure that the voltage of power supply and

products on the back or bottom printing values match.

• If the voltage is dierent, do not connect the product to the power socket.

Beware of damage to the product

• Do not put this product or any other objects on the power line.

• If the temperature is under 5 ° C when this product is delivered or stored, please open the product packaging and

waiting for it to reach room temperature before use.

Be careful of overheating

• Be sure to set aside at least 4 inches of space around the product for ventilation.

Cleaning product

• Only use a micro ber cleaning cloth to clean the product.

Environmental protection

• The product is made by recyclable and high quality materials.

• Do not dispose the product together with other waste.

• Please follow the local conditions about collecting electronic, electrical products and battery set.

• The correct disposal of these products will help to avoid a potentially negative impact on the environment and

human health.

• This product contains a battery that cannot be disposed as the general waste.

• Please follow the local recommendations about collecting battery

• The correct disposal of the battery helps to avoid a potentially negative impact on the environment and human

health.

Battery (AWF310 & AWF320)

• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine,re or similar.

Adapter

• Only use the power supply that comes with the speaker, or equivalent type. The MAINS plug or an appliance

coupler is used as the disconnect device, the disconnect device shall remain readily operable

ENG

Packing List

1. Speaker Unit

2. User Manual

3. 3.5mm Audio Cable

4. Adapter 18V/1A, 24V/1.5A or 24V/2A

5. Spotify Connect Startguide

6. AC Cable (Only for AWF340)

Operations Guide

This product has 5 keys:

• Power on/o

• Play/Pause

• Wi-Fi

• Vol+/Next

• Vol-/Previous

The function of keys:

1. Power on/o: long press for power on/o.

2. Vol+/Next and Vol-/Previous:

3. Play/Pause:

4. Wi-Fi button:

Wi-Fi speaker web settings

1. When you turn on the speaker, WiFi will automatically start.

2. After PC or smart phone connects the product through Wi-Fi (The default SSID is AWF***_XXXX, XXXX is a random

number), Customer access the site: http://10.10.10.254 and enter the setting page. There are two tabs:

Wi-Fi and Setting.

3. Wi-Fi tab: To setup the connection between Wi-Fi speaker and APP. Customer use a PC/MAC or smart phone to

access internet through Wi-Fi speaker after connected.

Wi-Fi

Vol-/Previous Vol+/Next

Play/Pause

Power on/o

Indicator

State Long/Short Press Double Click

Wi-Fi mode Vol+,Vol- Next / Previous

Line-in mode Vol+,Vol- NA

Bluetooth mode Vol+,Vol- Next / Previous

USB Charging mode / /

State Short Press

Wi-Fi mode & Music Playing Play / Pause

Bluetooth mode & Music Playing Play / Pause

Line-in mode & Music Playing Mute

USB Charging mode /

State Long Press

Wi-Fi mode Connect the slave speaker to main speaker

Bluetooth mode Disconnect Bluetooth

State Short Press

Wi-Fi mode Switch to Bluetooth mode

Bluetooth mode Switch to Line-in mode

Line-in mode Switch to USB charging mode

USB Charging mode Switch to Wi-Fi mode

ENG
