Please read this manual before connection and use.
R
R
R
R
R
TF-DVD5050
Important Safety Instruction
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert
the user to the presence of uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
Dangerous high voltage is present inside the enclosure. Do not open the cabinet.
CAUTION: To prevent electric shock, match wide blade plug to wide slot, and fully insert.
CAUTION: This Digital Video Disc Player employs a laser System. To prevent direct exposure to the
laser beam, do not try to open the enclosure. When open and the interlocks are defeated,
visible laser radiation is present.
Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure. DO NOT STARE INTO BEAM.
FCC NOTICE: This equipment has been tested and found to comply with the limits for a digital device. Pursuant with Class B
the These limits are designed to provide reasonable protection against harmful interference FCC Rules,Part 15.
in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in
accordance with the instruction may cause harmful interference to radio communication.
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS Page
SAFETY INFORMATION
TABLE OF CONTENTS
UNPACKING.............................................................................................................................................................1
NOTE ON DISC........................................................................................................................................................2
VIEWS OF THE MAIN UNIT...................................................................................................................................3-4
VIEWS OF THE REMOTE CONTROL.....................................................................................................................5
CONNECTIONS(Connecting to a TV)......................................................................................................................6
CONNECTIONS(Connecting to an amplifier ...........................................................................................................6
equipped with a Dolby Pro
Logic Surround)
CONNECTIONS(Connecting to a HeadphonePower ..........................................................................................................7
Connections (to AC Adapter)Power
Connections (to DC Car Cord)
CONNECTIONS(Power Connections to Battery Pack).........................................................................................................8
FUNCTION BUTTONS...........................................................................................................................................9-14
SETUP MENU.......................................................................................................................................................15-17
CUSTOM SETUP....................................................................................................................................................17
TROUBLE SHOOTING...........................................................................................................................................18
SPECIFICATIONS...................................................................................................................................................19
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: SHOCK HAZARD-DO NOT OPEN
AVIS: RISOUE DE CHOC ELECTRIQUE-NE PAS OUVRIR
Safety Precautions
CAUTION: Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
Please study this manual carefully and always keep it available. There are, however, some installa-
tion and operation precautions which you should be aware of.
(1). Read these instructions.
(2). Keep these instructions.
(3). Heed all warnings.
(4). Follow all instructions.
(5). Do not use this apparatus near water.
(6). Clean only with dry cloth.
(7). Do not block any ventilation openings-Maintain well ventilated conditions around the product. Do not put
product on bed, sofa or anything that blocks ventilation. Install in accordance with the manufacturer's
instructions.
(8). Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
(9). Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
(10). Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus. Power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
(11). Only use attachments or accessories specified by the manufacturer. Do not use attachments not
recommended by the product manufacturer as they may cause hazards.
(12). Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
(13). Unplug this apparatus during lightning storms or when unused for long periods of time. Unplug it from
the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due
to lightning and power line surges.
(14). Power sources-this product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your product dealer
or local power company. For products intended to operate from battery power, or other sources, refer
to the operating instructions.
(15). Overloading-do not overload wall outlets, extension cords, or integral convenience receptacles as this
can result in a risk of fire or electric shock.
1.000SCALE
Note on Disc
Care of Disc
Disc Requirement
Video disc contains high-density compressed data that needs proper handling.
Hold the disc with fingers. Hold the disc's outer edge and/or the center spindle hole.
Do not touch the disc surface.
Do not bend or press the disc. Do not expose the disc to direct sunlight or heating sources.
Store discs in cabinet vertically, and in dry condition. Prevent exposure to :
Direct sunlight
Heat or exhaust from a heating device.
Extreme humidity.
Clean the disc surface with a soft, dry cleaning cloth. Wipe the disc surface gently and radically from center
toward the outer edge.Do not apply thinner, alcohol , chemical solvent, or sprays when cleaning. Such
cleaning fluids will permanently damage the disc surface.
In addition, this unit can play back a CD-R, or CD-RW that contains audio titles or MP3 files.You cannot playback discs
other than those listed above.(CD-ROM, CD-Extra, CD-G, and CD-l discs can not be played on this DVD player.)
The DVD player can play back the following discs.
Disc mark Contents Disc size Maximum playback time
DVD video
discs
Audio+Video
(moving picture)
CD Audio
12cm
12cm/8cm
133 min (SS-SL)
242 min (SS-DL)
266 min (DS-SL)
484 min (DS-DL)
74min/20min
.1. .2.
Unpacking
Please make sure the following items are included with your DVD player. If any items are
missing, contact your dealer.
Remote Control
Battery
AC/DC Adapter Power Cord
RCA Cable Headphones
DC Car Cord
Left View Top View Right View
Bottom View
Using Stand
Views of the Main Unit
Views of the Main Unit
.3. .4.
Main Unit
MP3
JPEG Still high resolution 600min
Audio 12cm 600min
Speaker Speaker
Power ON
Indicator
MODE
Press MODE button once to enter setup menu.
Refer to "setup menu" section for detail.
Press it twice, below picture appears :
Press it the third time, below picture appears :
Press it for the fourth time, below picture appears :
LCD On/Off
Press to turn on/off the LCD display
Speaker
Two speakers produce stereo sound.
Power Switch
Press to turn on/off the unit.
Video Out -- Connect to external TV screen by the supplied RCA cables.
Audio Out -- Connect to external speaker system by the supplied RCA cables
Coaxial Out -- Connect to external speaker system by the coaxial cable (not supplied).
Headphone Jack -- connect to the supplied headphone. As the headphone is plugged in, the speakers' output
will be OFF.
Volume Control -- Adjust to the desired volume level.
Hold Switch
Prevent any unwanted function changes
in PLAY or STOP mode
Remote Sensor
Receiving remote control signal for
operation.
Display
Present high-resolution pictures.
DC 9V IN
Connect to the supplied AC Adapter/DC Car
Cord for power supply.
Battery LED Indicator
It lights red when charging the battery.
It lights green when the battery is fully charged.
Stand Lock
Retracktable Stand
Display
Play/Pause
Stop
Open Switch
Enter/
Cursor
Button
NEXT/F.F/LEF
PREV/F.B/RIGHT
Mode Button
LCD
On/Off
Remote
Sensor
Up
ENTER
ENTER
ENTER
ENTERENTER
Headphone
Jack
Power
Switch
Hold
Switch
Battery
Door
DC IN Jack
Video Out
Audio Out
Coaxial Out
Headphone
Jack
Volume Control
Battery LED
indicator
a) Lift up the stand from its groove.
b) Erect the unit by supporting it against the stand.
c) A slopewise viewing position is realized.
Stand is such a retractable support that you can get different extent of deviation by adjusting it.
a) Push the lock button upward to release the stand.
b) Draw the stand out and then fix it in position by cliking down the lock button.
c) Stand up the unit .
1.000SCALE
1.000
1.000
1.000
1.0001.000
SCALE
SCALE
SCALE
SCALE SCALE
1.000
1.000
1.000
1.0001.000
SCALE
SCALE
SCALE
SCALE SCALE
1.000
1.000
1.000
1.0001.000
SCALE
SCALE
SCALE
SCALE SCALE
LOCK UNLOCK
1.000
1.000
1.000
1.0001.000
SCALE
SCALE
SCALE
SCALE SCALE
1.000
1.000
1.000
1.0001.000
SCALE
SCALE
SCALE
SCALE SCALE
1
1
1
1
1
.
.
.
.
.
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
S
S
S
S
S
C
C
C
C
CA
A
A
A
A
L
L
L
L
L
E
E
E
E
E
S
S
S
S
S
C
C
C
C
C
A
A
A
A
A
L
L
L
L
L
E
E
E
E
E
1
1
1
1
1
.
.
.
.
.
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
(a) (b) (c)
(a) (b) (c)
Left /Top/Right View
Press the left/right direction
button to adjust contrast ratio.
Press the left/right direction
button to adjust Brightness
Press the left/right direction
button to adjust color saturation
StepClear
Mute
N/P
TF-DVD5050
1.000SC A LE
.5. .6.
StepClear
Mute
Title
Power
Menu
Enter
Direction buttons
Mute
Numeric buttons
Repeat A-B
Repeat
Audio
SubTitle Angle
Program
PBC
Slow
Step
FF/FB
PREV/NEXT Skip
Zoom
Stop
Play/Pause
Setup
N/P
Display
Views of the Remote Control
Remote Control
Battery Installation
Connections
Connecting to a TV set (TV or monitor with audio/video input)
NOTE:
1. Refer to the owner's manual of your TV as well.
2. Before connecting the DVD player to a TV set, be sure to turn the power off
and unplug both units from the wall outlet.
Audio/Video cable(Supplied)
To AUDIO OUT
To VIDEO OUT
To AUDIO/VIDEO
input
Clear
NOTE The buttons of same descriptions on the main unit/remote control are of same functions.
Refer to the diagram. Open the battery compartment of the
remote control. Insert batteries, and then close the compart-
ment.
To use the remote control, point it at the remote sensor of
the unit and operate in the range of 5 meters and at angle
of 60 degrees.
Generally, the batteries last for about one year. Replace the
batteries if the remote control does not work.
Do not spill water on the remote control.
Do not use remote control for other equipments at the same
time.
Remove the batteries if the remote control will not be in use
for a long period of time.
NOTE
WARNING:
The battery used in this device may present a fire or chemical burn hazard if mistreated.
Do not recharge, disassemble, incinerate, or heat the batteries about 1000C (2120F).
Use of another battery may present a risk of fire or explosion. Dispose of used batteries.
Do not dispose of fire.
Keep batteries out of children's reach.
Connecting to an amplifier equipped with a Dolby Pro Logic Surround
Amplifier equipped with a Dolby Pro Logic Surround
To Coaxial Input
To Coaxial OUT Coaxial cable (not supplied)
When connecting the equipment to a receiver equipped with
Dolby Digital, refer to the owner's manual.
N/P
TF-DVD5050
Connections
.7. .8.
Connections
Power Connections (to Battery Pack)
Connecting to a Headphone Be sure that your unit is at low volume level before
connecting the headphone.
Increase the volume gradually for your
comfortable listening.
CAUTION:
Hearing experts advise against the constant use
of personal stereos played at high volume.
Constant high volume use can lead to hearing loss.
If you experience ringing in the ears or hearing loss,
discontinue use and seek medical advise.
Power Connections (to AC Adapter)
**Do not connect the power cord until all other connections have been made.
AC adapter:
This AC adapter operates on
100-240V~~50/60Hz 2A Min
DC OUT: 9V
DC current: 2.0A Min
To Headphone jack
Headphone
To DC in jack
AC100-240V
Power is supplied through the provided appropriative power adapter, one end of which is connected
to the DC IN jack on the main unit, another to wall outlet with AC100-240V.
Note:
a. If you have difficulty inserting the plug, turn it over and reinsert it.
b. If the unit will not be in use for long periods of time, disconnect the plug from the outlet.
c. In order to prolong the operation life, the intervals of continuous power on should be not less
than 30s.
Note:
The battery can be recharged about 300 times without obvious performance drop.
The unit will not operate on battery power when the AC power cord is plugged into the AC socket.
Low Battery Detection: The unit will stop automatically and turn to STANDBY mode when voltage
reaches too low.Power Connections (to DC Car Cord)
To the DC 9V In of main unit
To the DC Jack of Car
Plug the DC Car Cord to the DC in Jack for power supply.
Note:
a. Please do not plug it to the battery recharge jack.
b. The DC Car Cord is only for in car use.
Insert Battery
For initial use, we recommend it be charged for at least 4 hours.
a/ Push the battery door to arrow direction to open it
b/ insert the battery and then close the door by hand.
Charge Battery
To charge the battery, just leave it in its compartment and then power on the unit by AC adaptor.
Battery LED indicator lights red while battery is under charging and it will turn to green after the battery
is fully charged.
1.000
1.000
1.000
1.0001.00 0
SCALE
SCALE
SCALE
SCALE SCALE
(a) (b)
1.000
1.000
1.000
1.0001.00 0
SCALE
SCALE
SCALE
SCALE SCALE
Battery LED Indicator
Produktspecifikationer
| Varumärke: | Coby |
| Kategori: | Bärbar DVD-spelare |
| Modell: | TF-DVD5050 |
Behöver du hjälp?
Om du behöver hjälp med Coby TF-DVD5050 ställ en fråga nedan och andra användare kommer att svara dig
Bärbar DVD-spelare Coby Manualer
18 September 2024
18 September 2024
18 September 2024
18 September 2024
17 September 2024
17 September 2024
17 September 2024
17 September 2024
17 September 2024
17 September 2024
Bärbar DVD-spelare Manualer
- Bärbar DVD-spelare Sony
- Bärbar DVD-spelare Samsung
- Bärbar DVD-spelare LG
- Bärbar DVD-spelare AEG
- Bärbar DVD-spelare Philips
- Bärbar DVD-spelare Panasonic
- Bärbar DVD-spelare Kenwood
- Bärbar DVD-spelare Toshiba
- Bärbar DVD-spelare Akai
- Bärbar DVD-spelare Apeman
- Bärbar DVD-spelare Lexibook
- Bärbar DVD-spelare Brandt
- Bärbar DVD-spelare Lenco
- Bärbar DVD-spelare Pyle
- Bärbar DVD-spelare Caliber
- Bärbar DVD-spelare Hyundai
- Bärbar DVD-spelare RCA
- Bärbar DVD-spelare Clatronic
- Bärbar DVD-spelare Sencor
- Bärbar DVD-spelare Overmax
- Bärbar DVD-spelare Polaroid
- Bärbar DVD-spelare Salora
- Bärbar DVD-spelare Denver
- Bärbar DVD-spelare Sunstech
- Bärbar DVD-spelare GoGEN
- Bärbar DVD-spelare Marquant
- Bärbar DVD-spelare Proline
- Bärbar DVD-spelare Muse
- Bärbar DVD-spelare Audiovox
- Bärbar DVD-spelare Insignia
- Bärbar DVD-spelare Naxa
- Bärbar DVD-spelare Nextbase
- Bärbar DVD-spelare Mpman
- Bärbar DVD-spelare Trevi
- Bärbar DVD-spelare Logicom
- Bärbar DVD-spelare Ematic
- Bärbar DVD-spelare Nevir
- Bärbar DVD-spelare Durabrand
- Bärbar DVD-spelare Iluv
- Bärbar DVD-spelare Xoro
- Bärbar DVD-spelare Woxter
- Bärbar DVD-spelare Tesco-Technika
- Bärbar DVD-spelare Bluetech
- Bärbar DVD-spelare Reflexion
- Bärbar DVD-spelare Lenoxx
- Bärbar DVD-spelare GoVideo
- Bärbar DVD-spelare Belson
- Bärbar DVD-spelare Yakumo
- Bärbar DVD-spelare Voxx
- Bärbar DVD-spelare Majestic
- Bärbar DVD-spelare Best Buy
Nyaste Bärbar DVD-spelare Manualer
20 Oktober 2024
16 Oktober 2024
15 Oktober 2024
14 Oktober 2024
7 Oktober 2024
6 Oktober 2024
4 Oktober 2024
3 Oktober 2024
30 September 2024
27 September 2024
