Pro AV/IT HDBaseT™ 4K60 18G HDMI Extender
Kit with USB, Audio, LAN, RS232 up to 330ft
VER 2.1
CHE-HDBT255U
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents
1. Introduction............................................................................................
2. Features..................................................................................................
3. Package Contents................................................................................
4. Specifications........................................................................................
5. Operation Controls and Functions......................................................
5.1 Transmitter Panel.............................................................................
5.2 Receiver Panel................................................................................
5.3 Audio Signal Output Switching......................................................
5.4 IR Pin Definition................................................................................
6. Application Example............................................................................
1
1
2
2
4
4
5
7
7
8
1. Introduction
2. Features
☆ HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
☆ Support 18Gbps video bandwidth
☆ Video resolution is up to 4k2k@60Hz YUV 4:4:4
☆ The maximum transmission distance is 328ft / 100 meters via a single
CAT6a/7 cable
☆ Support ARC (Audio Return Channel) function
☆ With bi-directional IR, RS-232 and CEC pass-through
☆ Support USB KVM function
☆ HDR, HDR10+, Dolby Vision and HLG function supported
☆ Su wer pport PoC (Po over Cable) function
☆ Compact design for easy and flexible installation
1 / 8
This 18Gbps HDMI Extender can extend high definition video / audio signal,
RS-232, bi-directional IR and internet signal, at the distance of up to 328ft /
100 meters between transmitter and receiver via a single CAT6a/7 cable and
support resolution up to 4K2K@60Hz 4:4:4. The Transmitter supports ARC
function and local audio extract. In addition, the extender is equipped with
bi-directional IR pass-through whi ay control. It ch allows for source and displ
also supports USB KVM and PoC function .
The extender offers the most convenient solution for HDMI extension via a
single CAT cable with long distance capability, and is the perfect solution for
any application.
