INSTRUCTIONS on INSTALLATION & USE for W200FW and W220VW

Creda recommends, for your own safety and to ensure you get the best possible results from your Washing

Machine, you read through this booklet and follow these steps thoroughly.

Choose a location for your washing

machine where possible on a solid floor,

with the electrical sockets and water

supply taps easily accessible.

Allow sufficient space: 600mm width,

600m depth and 900mm height.

DO NOT install in a bath or shower

room.

Dispose of packaging material in a safe

place and remove any labels.

Please read through thoroughly to

ensure you understand each stage

before you begin.

Read the rest of these instructions to get the best from your appliance, remember to fill in your guarantee registration.

Keep this Book in a safe place for quick reference.

STEP 1 STEP 2

A wash chart is provided to help you to

select your required programme.

Examples given for the maximum

washing load weight for different fabric

types.

STEP 4

WARNING: This appliance must be earthed.

Remember you will be charged for a service call if a

problem with your washing machine is caused by

incorrect installation or misuse.

Electrical Guide Installation Guide

Programme Selector Dial

Read through this section to familiarise

yourself with the different

compartments within the dispenser

drawer.

STEP 3 Dispenser Drawer

NOTE: Always follow manufacturer’s dosage

recommendations.

All available optional wash features are

explained within this section - These

allow you to adjust your selected wash

programme to suit your needs.

STEP 6 Options Guide

How to start your selected programme

and how to stop or change the

programme if so required.

STEP 5 Using your Machine

NOTE: Progress indicator lights show what stage in

the programme cycle has been reached.

We recommend the Persil range of

detergent products.

STEP 8 Troubleshooting

A picture guide provides a clear

explanation how to set a wash

programme.

DO NOT overload the washing machine.

STEP 7 A Typical Wash Programme

NOTE: Creda recommend, on completion of your

programme, that you switch off both the

electricity and water supply to the appliance.

Please refer to the Troubleshooting

section if you have any problems when

using your washing machine.

There may be nothing wrong!

NOTE: In addition to the temperature of the

incoming water, the selection of optional wash

features will affect the programme times.

READ BEFORE

CONTACTING

SERVICE!

Merloni Elettrodomestici UK Ltd, Morley Way, Peterborough, PE2 9JB.

PRINTED BY SIMLEX .FOUR ASHES, WOLVERHAMPTON. 09/2004 - 195046949.00

Creda guarantee After Sales Service

“Satisfaction guaranteed or your money back”

We give you a unique ‘satisfaction guaranteed’ promise - valid

for 90 days - after you have purchased your Creda appliance.

If there is a technical problem simply call Creda Repair service

or visit our web-site at www.theservic enec tre.co.uk and where

necessary, we will arrange for an engineer to call.

If the technical problem is not resolved under this guarantee,

we will replace your machine or, if you prefer, give you

your money back.

All Creda appliances carry a fully inclusive 12 month parts and

labour guarantee.

Guarantee terms and conditions

Your guarantee is only applicable in the United

Kingdom or Republic of Ireland and is subject to the

following provisions that your appliance:

●Has been installed and used correctly in accordance with

this instruction booklet.

●Has been used solely for domestic purposes and is located

on domestic premises (ie. not for commercial or trade

use).

●Has been properly connected to a suitable electrical

supply voltage as stated on the appliance rating plate.

●Has not been subject to misuse,accident, modified or

repaired by anyone other than one of our own service

engineers.

For pre purchase information on any other Creda

product,

call: 08701 54 64 74 or visit: www.creda.co.uk

Recycling & Disposal

Information

As part of Creda’s continued commitment to helping the environment,

we reserve the right to use quality recycled components to keep down

customer costs and minimise material wastage.

Please dispose of packaging and old appliances carefully.

To minimise risk of injury to children, remove the door, plug and cut

mains cable off flush with the appliance. Dispose of these parts

separately to ensure that the appliance can no longer be plugged into

a mains socket, and the door cannot be locked shut.

“No company is better positioned to offer an after sales service on

a Creda appliance than us - the manufacturer”.

As part of our commitment to you, all Creda appliances have the added

benefit of a fully inclusive parts and labour guarantee for the first 12

months. All in-guarantee repairs are guaranteed for the remainder of your

original guarantee period.

When the 12 months parts and labour guarantee expires we offer the

following after sales service options:

Repair Service and Information Help Desk

UK: 08709 066066

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the Model number and the Serial number

of your appliance.

Available 364 days a year with a fast, effective and value for money

service.We have the largest white goods repair service in the UK with over

1200 of our own fully trained engineers.

All chargeable repairs include a parts and labour guarantee for 12

months from the date of the repair.

If you require any information or have any questions about your

appliance, our operators are on hand with help and advice.

All this ensures that you will receive the best available after sales service

possible.

Extended Warranties

UK: 08709 088 088

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 502 200

Whether you have just one or a number of Creda appliances in your

kitchen, we offer two service cover plans to give you total peace of mind.

●Repair Protection Plan - FREE service repairs for a single Creda

appliance during the period of cover.

●Kitchen Cover - FREE service repairs for all your Creda

appliances less than 8 years old.

Genuine Parts and Accessories

UK: 08709 077 077

www.theservic enec tre o.c .uk

Republic of Ireland: (01) 842 6836

A wide range of genuine parts and accessories are available from our

hotline or through our web site.

Genuine parts and accessories, extended warranties and service

repairs are all available on our web-site at:

www.theservic enec tre.c .uko

Getting to Know your Appliance

Plumbing Indicator Line label

Hot Water inlet point and

supplied Hose (Red or Grey end)

Cold Water inlet point and

supplied Hose (Blue end)

Transit Bolts (both MUST be removed

before using your machine).

Control Panel

Interlocking door

and release lever

Rating Plate

Mains Cable

Drainage Hose

Hooked End Support

Dispenser Drawer

Model W220VW shows the maximum features available

Adjustable Feet

Wheels

Key Contacts

After Sales Service

Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in both the appliances and

services we offer.

Extended Warranties

UK: 08709 088 088

(Open 8 to 8 Mon - Sun)

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 502 200

Genuine Parts and Accessories

UK: 08709 077 077

(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)

www.theservic enec tre o.c .uk

Republic of Ireland: (01) 842 6836

Cleaning the Exterior:

Use a damp cloth or silicon polish to clean the exterior surfaces of the

appliance.

Cleaning the Door Bowl:

Clean the internal surface of the door bowl regularly with a soft cloth.

A build up of soap powder and water hardness residue may result in

water leaking from the door.

Repair Service and Information Desk

UK: 08709 066 066

(Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays)

www.theservic enec tre o.c .uk

Republic of Ireland: 1850 302 200

Note: Our operators will require the following information:

The Model number (which can be found on

the control panel)

The Serial number (which can be found on the

inner door trim)

Cleaning the Dispenser Drawer & Compartments:

It is advisable to clean the dispenser drawer regularly:

1Pull the drawer out until it reaches its stop.

2Press the drawer release latch

down to remove the dispenser

drawer.

4Relocate the dispenser drawer and push it

firmly back into place.

Clean and dry the

dispenser drawer,

syphons, grate and

fabric conditioner exit

channel (A).

Also,regularly clean the

outlet pipe area (B).

●Do not try to clean any

part of the dispenser

drawer while the machine

is working.

WARNINGS:

●Do not clean any part of the

machine with abrasive cleaners,

scouring agents, acids, any

bleaches or metal polish, as

they may cause damage.

3CONNECT TO THE WATER

SUPPLY...

The Dispenser Drawer

STEP 3

Electricity Supply Installation

WARNING: The appliance must be earthed.

CE marking certifies that this appliance conforms to the following

EEC directives:

Low Voltage Equipment - 72/23/EEC & 93/68/EEC

Electromagnetic Compatibility - 89/336/EEC, 92/31/EEC & 93/68/EEC

Fuses

Your appliance comes fitted with a plug and a 13 amp (13A) fuse. If

you need to replace the fuse, use only those rated at 13 amp (13A)

and ASTA approved to BS1362.To change the fuse lift the holder to

vertical position and lift the fuse out.To replace the fuse, insert the

fuse and push fuse holder down into the locked position.Correct

replacement is identified by colour coding or the marking on base of

plug.

WARNING: Do not use the plug unless the fuse holder is in the locked

position and the top cover firmly replaced.

Changing the Mains Lead

If you have damaged the existing lead and need a new one, contact

Creda Service UK on: 08709 066 066 or www.theservicecentre.co.uk

(or in the Republic of Ireland on: 1850 302 200). A charge will be

made.We strongly advised that fitting a new lead is carried out by a

qualified electrician.

Seek professional advice if you need to use an extension lead.

Changing the Plug

If you need to change your plug, if it does not fit your socket: isolate

the machine from the mains supply. Cut off the supplied plug and

safely dispose of the discarded plug. DO NOT plug into any other

socket.

NOTE: If you change the plug,the colour of wires in the mains lead

may not match the colour of the markings which show the different

terminals in the plug.You must wire it as shown below:

Green and yellow (Earth)

wire to terminal marked ‘E’,

symbol , or coloured

green and yellow.

Blue (Neutral) wire to

terminal marked ‘N’ or

coloured black.

13A ASTA approved fuse to

BS1362.

Brown (Live) wire to terminal

marked ‘L’ or coloured red.

Adding Fabric Conditioner

Dispensing Powder Detergent

Dispensing Liquid Detergent

Index:

1. Drawer release latch

2. Pre-wash detergent compartment

Maximum 200ml powder or

100ml liquid

3. Main detergent compartment

Maximum 400ml powder or

200ml liquid

4. Grate

5. Fabric conditioner compartment

120ml maximum

To achieve the best wash results the

manufacturer’s recommended amount

of detergent should be measured and

added to the main detergent

compartment (II symbol) (max. 400ml).

Alternatively you can obtain a liquid

detergent flap, a barrier for the dispenser

drawer.

Contact Genuine Parts and Accessories

(see Key Contacts)

Pour the recommended

amount of fabric

conditioner into the

compartment

(flower symbol).

Do not exceed the

maximum fill line.

Pre-wash Programme A

When selecting programme A,

add detergent to both the

pre-wash compartment (Isymbol)

and the main wash compartment

( symbol).II

DO NOT use in drum dosing

devices with the Pre-wash

programme, A.

4DRAINAGE SYSTEM... we recommend one of the following:

1POLYSTYRENE BLOCK...

5LEVEL?...

NOTE: ALTHOUGH YOU MAY NEED TO

MOVE THE HOOKED END SUPPORT

ALONG THE GREY DRAINAGE HOSE,

DO NOT REMOVE IT.

WHICHEVER DRAINAGE METHOD

YOU USE, MAKE SURE THAT THE

HOOKED END SUPPORT IS FIXED

LEVEL TO, OR ABOVE THE ‘PLUMBING

INDICATOR LINE’*

(*see Getting to Know your Appliance)

This is part of the packaging and

should have come away with the

polystyrene base.

IF IT HAS NOT... REMOVE IT!

NOTE: YOU MAY NEED A SECOND

PERSON TO HELP YOU RAISE AND

LOWER THE APPLIANCE.

PLEASE USE THE NEW HOSES SUPPLIED, FITTED

TO THE MACHINE.

If you have no hot water supply...

Old hoses may

cause leaks due to

worn out washers.

YOUR MACHINE WILL BE NOISY IF THE TWO FRONT FEET ARE NOT

ADJUSTED SO THE MACHINE STANDS FIRM AND LEVEL.

Check both hot

and cold water

supplies are

running freely...

A cold fill adaptor is available from

your local authorised Service

Centre or by calling the Genuine

Parts & Accessories Hotline (see

Key Contacts).

Connect fill hoses to

water supply taps:

Red or Grey Hose end

to Hot and Blue Hose

end to Cold.

TURN BOTH TAPS ON...

Turn one both front feetor

clockwise until the machine

stands firm and level.

The spring on each foot will

stop them coming loose.

2REMOVE TWO TRANSIT FIXINGS... Follow these instructions to remove the TWO transit fixings.

IMPORTANT:

Situated, one either

side of the rear panel,

both transit bolts

(complete with

spacers) MUST be

removed before use...

Failure to do so may

cause damage to

your machine!

DO NOT REMOVE!

STANDPIPE METHOD UNDER SINK METHOD

Attach the GREY

drainage hose to the

under sink drainage

unit securely, using a

hose clip.

Fix the hooked

end support at

a minimum

800mm from

the floor.

cut off the blocked

end of the under sink

drainage unit.

7READY...

TO CHECK ALL PARTS OF THE INSTALLATION AND TO THOROUGHLY

CLEAN THE INSIDE OF YOUR MACHINE:

RUN PROGRAMME ‘B’ (refer to ‘Programme Selector Dial’, STEP 4).

6CONNECT TO THE POWER SUPPLY...

PLUG YOUR MACHINE INTO AN ELECTRICAL SOCKET WHICH IS

EASILY ACCESSIBLE. SWITCH ON

NOTE: We recommend extension

leads are not used.

Move your machine into position,

take care not to trap or kink the

hoses.

WITHOUT ANY LAUNDRY

WITHOUT ANY DETERGENT

and

THIS WILL TAKE APPROXIMATELY 2hours TO COMPLETE

.............................

Standpipe height:

minimum 500mm

from the floor.

Insert drainage hose

approximately 100mm

into the standpipe.

✗✗

It is important the transit

bolt and spacer come out

intact (see pic).

For safety, replace both

plastic covers over the

holes left by removing

the two bolts.

Use a crosshead

screwdriver to

remove the

plastic cover.

Unscrew the

bolt using a

13mm spanner.

STOP when 3

threads can be

seen.

Hold, slide

across and pull

to remove.

800mm

from floor

Hooked End Support

STEP 1 STEP 2

WARNING:

●Do not put any items into

the drawer, other than

detergents designed to be

released from the drawer, as

they may cause damage or

blockage.

We recommend the use of a detergent dosing ball, as provided by your detergent

manufacturer.

Using your Machine

STEP 5

On-Off / Selecting a programme...

To change a programme...

NOTE:

Progress indicator lights...

‘OFF’ position

Run indicator lightDoor Locked indicator light

‘M’ Stop/Change Programme

Start button

Programme selector dial

Option buttons

End light

The machine is switched on, by turning the programme selector dial away from the ‘OFF’ position to your selected programme.

To start the programme press and release the ‘Start’ button.

NOTE: When the programme has finished, return the programme selector dial to the ‘OFF’ position.

If you want to change a programme, turn the programme selector dial to ‘M’ (Stop/Change Programme) and press the ‘Start’ button.

As you turn the programme selector dial the ‘ ’ light will flash. The flashing stops and the ‘Run Run’ light will go out when you press

the ‘Start’ button. The ‘End’ light will then flash as the machine pumps out the water in the drum to a safe level.When completed,

the ‘End’ light stops flashing and you can then change the programme (you may need to add detergent).Press the ‘Start’ button to

continue.

To stop a programme...

To stop a programme, turn the programme selector dial to ‘M’ (Stop/Change Programme) and press the ‘Start’ button. As you turn

the programme selector dial the ‘Run’ light will flash. The flashing stops and the ‘Run’ light will go out when you press the ‘Start’

button.The ‘End’ light will then flash as the machine pumps out the water in the drum to a safe level. When the ‘End’ light stops

flashing and the ‘Door Locked’ indicator light goes out, you can open the door.

CAUTION: The load and the remaining water in the drum may still be extremely hot.

If you turn the programme selector dial during a programme, the ‘Run’ indicator light will flash to show that the programme

running is not that shown on the dial. Turn the dial to the original programme to stop the flashing.

The flashing will automatically stop when the programme enters the rinse phase.

●

The ‘Run’ indicator light will come on as soon as the

selected programme has started. This light will remain lit

throughout the programme and will go out when the

programme has finished.

●

The ‘End’ indicator light will come on after the selected

programme has finished. This light will remain lit until you

return the programme selector dial to its ‘OFF’ position, or

start another programme.

Door Locked indicator light...

●

The ‘Door Locked’ indicator light will come on two

seconds after you press the ‘ ’ button and will stay lit Start

throughout the programme. A short time after the

programme has finished the indicator light will go out and

you can then open the door.

●

Selected programmes will not start if the door is not closed

properly, the ‘Door Locked’ indicator light will flash to show

this. Push the door shut until you hear the catch click.

WARNINGS:

●In the unlikely

event of something

not working, see

‘Troubleshooting’

STEP 8.

When all selections

have been made

press the ‘Start’

button.

The ‘End light will

go out and the ‘Run’

light will illuminate

to indicate the start

of a programme.

After a short time the ‘Door Locked’

indicator light will illuminate.

If you need to cancel a programme once

the machine has started see STEP 5 ‘Using

your Machine’.

A Typical Wash Programme

Turn the programme

selector dial from the

‘OFF’ position to the

programme required

(see STEP 4).

The ‘End’ light will

illuminate to

indicate that the

machine has power.

Sort laundry into

groups by washcare

labels.

Load the machine,

making sure that the

laundry is not

trapped in the door.

Close the door by

pushing it until it

clicks.

Select any optional

wash feature(s) that

you may require by

pressing the

appropriate button(s)

(see STEP 6) indicator

lights will show what

you have chosen.

During the wash, the

‘Run’ and ‘Door

Locked’ indicator light

will remain lit.

When the

programme has

finished the ‘End’

and ‘Door

Locked’ indicator

lights will remain

lit.

After a short time the ‘Door Locked’

indicator light will go out. You can

then open the door.

To switch the machine off, return the

programme selector dial to the ‘OFF’

position.

The ‘End’ light will go out.

We also recommend that you switch

off the electricity and water supply.

Add detergent (and

fabric conditioner if

required) to the

dispenser drawer (see

STEP 3).

Refer to the detergent

manufacturer’s

dosage instructions.

7 8

WARNINGS:

●DO NOT allow

children to play

with the appliance

or tamper with the

controls.

●DO NOT overload

the appliance!

It may damage the

laundry and reduce

the quality of the

wash.

●DO NOT try to

open the door

when the ‘Door

Locked’ indicator

light is on.

●During the wash

cycle, remember

that the door glass

may become hot to

the touch.

●DO NOT open the

dispenser drawer

during any

programme.

STEP 7

●If you stop a

programme part

way through a

wash or there is a

power cut, take

care when opening

the door, the

machine may

contain hot water.

(Model W220VW

only):

Reduce the spin

speed if you wish by

turning the variable

spin speed control

dial (see STEP 6).

Programme Selector Dial

IMPORTANT INFORMATION: The temperature of the incoming water supply and selection of any Optional Wash Feature, ie. Energy

Save, will affect the programme times*. Turn the programme selector dial from ‘OFF’ to the programme you need...

NOTE:

When the programme

has finished, return

the programme

selector dial to the

‘OFF’ position.

WEIGHT OF

WASH LOAD

Two examples of

maximum wash loads

for different types of

fabric:

2 Bath Towels

5 Shirts

6 Blouses

1 Pair of Pyjamas

4 Items of

Underwear

COTTON

= 5.5kg

2 Children’s Dresses

4 Shirts

4 Blouses

1 Pair of Pyjamas

4 Items of

Underwear

SYNTHETIC

= 3kg

Wash Fabric Temp. Max. Approximate Spin

label ˚C dry load programme time* speed

Prewash 30 5.5kg Slow

White cotton & linen

without special finishes 95 5.5kg Fast

Colourfast cotton 2 hours -

without special finishes. 60 5.5kg 2 hours 20minutes Fast

Non-colourfast cotton, linen

or viscose without special 40 5.5kg 1 hours 30minutes - Fast

finishes 1 hours 45minutes

Non-colourfast cotton, 1 hour 20minutes -

linen or viscose 30 5.5kg 1 hour 35minutes Fast

Synthetics

coloured nylon, polyester,

acrylic and cotton mixtures,

cotton or viscose with special

finishes, coloured polyester 1 hour 5minutes -

and cotton mixtures 50 3kg 1 hour 15 minutes Slow

Acrylics

acrylics and tri-acetate blends

of these fabrics with wool,

polyester and wool blends 40 3kg 40 - 50minutes Slow

Wool

Shrink resistant machine 1 hour 15minutes -

washable wool, woollen 40 1.5kg 1 hour 25minutes Medium

blankets.

Wool mixtures with cotton 1 hour 15minutes -

or rayon. 40 2.5kg 1 hour 25minutes Medium

Silk 55minutes -

Printed acetate 30 3kg 1 hour 5minutes Slow

Fast Wash for freshening up

lightly soiled items. 35 1kg 35 - 45minutes Slow

Warning: not for woollen,

silk or delicate items.

Cold wash 45minutes -

cold fill only, no heating action. 25 3kg 55minutes Slow

Stop/Change programme

Rinse and Spin 3kg 30minutes Slow

Fast Spin - Cotton 5.5kg 15minutes Fast

Slow Spin - Delicates 3kg 15minutes Slow

STEP 4

Pre-wash

Rinse and Spin Programme

Spin only Programmes

Wash Programmes 1 hour 40minutes -

1 hour 50minutes

25 minutes

Options

STEP 6

Button Selection:

To select an option, press the button and you will see a light come on above the button.

Press again to cancel, and the light will go out.

You cannot alter the options once the machine is running.

Energy Save...use this option to...

Save money and energy on lightly soiled loads.

●This option reduces the wash temperatures by 10˚C on

programmes B,C,D,F,G and H.

Rinse Hold... use this option to...

Hold the clothes in the final rinse water, keeping them fresh

until you are ready to complete the programme.

Complete the final spin by pressing the Rinse Hold button when

the light is flashing.

●This is not available with programmes A, H and L or Spin

only programmes.

NOTE: Remember to cancel buttons after use!

Automatic Features...

Unbalanced load warning

Your machine has an inbuilt feature to prevent it spinning with an unbalanced load. This will minimise excessive vibration and

prolong the life of the machine. Before each spin the machine ‘senses’ the load within the drum and if the machine considers the

load to be unbalanced, it will not automatically spin. Instead the machine will try to redistribute the load to achieve balance by

tumbling backwards and forwards. If it is unable to balance the load after the fifth attempt the machine will abort the spin process

and the load will still be wet at the end of the programme.

If this safety feature is encountered you can spin the load after first opening the door, redistributing the load and selecting a fast or

slow, spin only programme. In the case of small loads or single items you may try adding some extra items of a comparable size to

help balance the load.

Variable Spin Speed

Use this control to reduce the programme spin

speed only.

If you leave this dial in the maximum position,

the spin speed will be the maximum which is

appropriate for whatever wash programme you

have chosen.

When the programme has finished, return the

dial to the original setting.

Note: You cannot alter the spin speed while

the machine is spinning.

●Only available on model W220VW.

Is your water pressure too

high?

Troubleshooting - More ‘Troubleshooting information and general product advice can be found on our website, visit: www.theservicecentre.co.uk/help

If your machine is still not working

contact:

Repair Service and Information Desk

UK 08709 066 066

Republic of Ireland 1850302 200

You will be asked for the following

details: Name and Address, Post

Code,Telephone Number, Date of

Purchase, Colour and Model/Serial

Numbers - which can be found on

the inside of the door.

Clear and precise details of the query

or fault.

Remember, you will be charged for a

service call if a problem with your

machine is caused by incorrect

installation or misuse.

Check all loose items, such as

coins, have been removed

from the laundry.

Have both transit bolts been

removed from the machine?

See STEP 2: Installation

Is the fuse in the plug OK?

Has the polystyrene

block been

removed from

underneath the

machine?

MY MACHINE MAKES A

NOISE OR VIBRATES IN A

SPIN PROGRAMME.

Plug the machine in and

turn the socket switch on.

If possible use another socket

for the machine.

If not replace it, see STEP 1:

Electricity Supply

Is the standpipe or household

drain blocked.

Have you adjusted the feet to

stabilise the machine?

Check the feet have been

levelled.

Is steam coming

from the dispenser

drawer?

If not tighten them.

Does the washer need

replacing?

✓

Close the door. Choose a

programme and then press ‘Start’

Does the ‘Door Locked’ indicator

light come on after 2 seconds?

MY MACHINE WILL NOT

START MY MACHINE IS LEAKING

THE PROGRAMME TAKES A

LONG TIME

SUDS ARE COMING FROM

THE DISPENSER DRAWER

NOT ALL OF THE DETERGENT

HAS BEEN FLUSHED AWAY

Is the machine plugged in

and switched on?

Is the socket OK? Test with

another appliance to check.

The machine is designed to

release steam from the dispenser

drawer during hot washes.

You may need to call in a

plumber.

✓

Turn the main supply tap

down.

You may need a cold fill adaptor

to run your machine as cold fill

only. See ‘Installation’, STEP 2.

If you have fitted a detergent flap

ensure it is in the ‘UP’ position if

using powder. See STEP 3: ‘The

Dispenser Drawer’

Is your hot water pressure low?

Check the inlet hoses are not

kinked.

✓

Check that your water supply

taps are turned on fully.

✓

Was a short spin programme

used on a non-synthetic load.

Did the water pump out?

If not see ‘MY MACHINE DOES

NOT PUMP OUT WATER’.

Clean fabric dispenser drawer.

See STEP 3:‘The Dispenser

Drawer’.

Check for low temperature and

low pressure of the hot and

cold water supply.

THE DISPENSER WILL NOT

CLOSE PROPERLY

Check the correct amount of

suitable detergent has been used,

refer to manufacturer’s

recommendations.

If you have used the wrong type of

detergent, select a Rinse programme

to flush out your machine.

There has been an

unbalanced load and the machine

could not spin.

See ‘Automatic Features’ STEP 6.

MY LAUNDRY HAS NOT

SPUN DRY.

WATER COLLECTS IN THE

FABRIC DISPENSER

COMPARTMENT

✓

✗

Clean the dispenser drawer, see

STEP 3:‘The Dispenser Drawer’

Is the drawer clogged with

detergent?

The ‘Door Locked’indicator light:

Check the drawer is properly

aligned.

✓

✗

✓

Washcare Tips: Indicator Lights:

●Do not overload the machine

(maximum load 5.5kg).

In addition to reducing the

quality of the wash, this may also

damage your laundry and the

machine.

●We strongly recommend that you

do not wash in underwired bras

this machine. Should the wires

become detached it could cause

damage to your clothes and the

machine. If the washcare label

states that the bra is machine

washable, then we advise placing

it in a sealed pillow case or a

similar washbag. Remember, you

will be charged for a service call

resulting from a detached bra

wire.

●Do not use the machine if the

item to be washed does not have

a wash label.

Before washing laundry we

recommend that you do the

following:

●Pre-treat awkward stains with

washable treatments.

Do not wash any items that have

previously been treated with

solvents.

●Close zips, fasten belts, tie strings

and close press studs to prevent

tangling.

●Empty ALL objects from pockets

as they may damage the clothes

and the machine.

Remember, you will be charged

for a service call to rectify a

malfunction resulting from

objects, such as coins, pens, hair

grips etc. falling from pockets.

●Limit the size of absorbent loads

ie. towels, to 3kg (7lb) to give

good washing and rinsing results.

●Place small items in a wash bag.

●Always follow the care label on

items when choosing the wash

programme.

●Wash non-colourfast items or

really dirty laundry separately as

they may affect other items.

Are the fill hoses on correctly?

●

If the ‘Door Locked’ indicator light is flashing:

Shut the door firmly, until it clicks.

The ‘Door Locked’ indicator light should now stay on.

●

If the door will not open... Check the programme has

finished, is the ‘End’ indicator light lit? It takes about

two minutes for the ‘Door Locked’ indicator light to

go out after a programme has finished.

The door will not open until the ‘Door Locked’

indicator light has gone out.

The ‘ ’ and ‘Run End’ indicator lights are

both flashing...

●

This means that the machine cannot fill.

Check that the water supply is turned on and that the

inlet hoses are not kinked.

The ‘Run’ indicator light is flashing...

●

If the ‘Run’ indicator light is flashing:

This means that the programme selector dial has been

moved since the programme started.

Return the dial to the original selection.

STEP 8

Remember, you will be charged for a service call for problems caused by incorrect installation, non-removal of transit bolts or packaging, leaks from household pipework, loose or blocked fill and drain hoses.

Washing items that DO NOT have a wash label or washing items that are not intended as machine washable and NOT emptying contents from pockets may cause pump or drain blockages, or may damage components within the machine.

See STEP 2: Installation

Clear any blockages that have

been found

MY MACHINE DOES NOT

PUMP OUT WATER

Is the machine connected to

a sink waste system?

Check the blocked end of the

under sink drainage unit has

been cut off.

✓

Has ‘Rinse Hold’ been selected?
