Sida 1/4
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021419
BTCR-35X
Bluetooth Handsfree + 4 Channel Audio Streaming +
Auxiliary Input for Select Chrysler, Dodge and Jeep Vehicles
1 of 2
- Adds Bluetooth Handsfree Calling to the OEM radio.
- Adds 4 channel Bluetooth Music streaming.
- Adds an auxiliary audio input.
- Automacally pauses BT Streaming when a call is received, and resumes when the call is ended.
- Allows user to answer, end calls track up and track down using the steering wheel controls.
- DSP and Echo-Cancellaon allows for clear conversaons on both sides of the phone call.
- Automacally mutes any source as soon as a call is received, and resumes when call is ended.
- Allows any previously paired mobile phone to automacally re-connect to the Bluetooth interface.
- Hear Navigaon App voice prompts from the factory speakers while in Bluetooth mode.
PRODUCT FEATURES:
R
INTERFACING SOLUTIONS
PARTS INCLUDED:
BTCR-35X Module BTCR-35X Harness Microphone
Aux Input
TO RADIO
GRAY
22-PIN
(MALE)
GRAY
22-PIN
(FEMALE)
TO FACTORY
HARNESS
Microphone
GRAY
10-PIN
(MALE)
GRAY
10-PIN
(FEMALE)
INSTALLATION DIAGRAM:
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021419
BTCR-35X
Bluetooth Handsfree + 4 Channel Audio Streaming +
Auxiliary Input for Select Chrysler, Dodge and Jeep Vehicles
2 of 4
R
INTERFACING SOLUTIONS
INSTALLATION INSTRUCTIONS:
1. Remove the power windows switch
plate by prying o with a plasc panel
removal tool.
2. Slide back back the red connector
locking tab.
3. Unplug the power window switch
connector.
4. Remove the phillips screw in the
middle of the dash trim.
5. Pull out the HVAC control knobs. 6. Using a plasc panel removal tool,
carefully pry out the dash trim.
7. The radio is secured by 4 phillips
screws.
8. Unplug the radio connectors. 9. Plug the 12 pin Molex connector to
the BTCR-35X module.
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021419
BTCR-35X
Bluetooth Handsfree + 4 Channel Audio Streaming +
Auxiliary Input for Select Chrysler, Dodge and Jeep Vehicles
3 of 4
R
INTERFACING SOLUTIONS
INSTALLATION INSTRUCTIONS:
10. Plug in the 3 pin microphone
connector to the harness.
11. Run the microphone cable along the
A pillar and clip the microphone on the
A pillar trim.
12. Plug in the auxiliary device to be
used into the RCA aux input.
OPERATION:
1. Turn on the radio and go to the Bluetooth sengs on the phone.
2. Pair the phone to blueLogic.
3. Change the source on the radio to VES/DVD mode.
4. Play music on your phone and audio will be heard on the car speakers.
5. BT music will stop when the source is changed, i.e. FM/AM/CD.
6. BT music will automacally resume when the source is changed back to VES/DVD mode.
7. When there is an incoming call, the module will automacally switch to VES/DVD mode and switch back to the
source selected before when call is ended.
CONTROL BUTTONS ON RADIO:
While on VES/DVD mode while BT music is playing:
SEEK UP Next Track
SEEK DOWN Previous Track
ONLY for RAK radios:
SCAN Voice Recognion
While on VES/DVD mode when there is an incoming call:
SEEK UP Phone Pick up / Hang Up
SEEK DOWN Phone Pick up / Hang Up
ONLY for RAK radios:
SCAN Phone Pick up / Hang Up
REC Radio
RAK Radio
