- Adds Bluetooth Music streaming to select OEM Audi and Volkswagen radios.
- USB music playback with track up, track down and folder controls from the radio panel or steering
wheel controls.
- Adds 3.5mm auxiliary audio input jack.
- Hear turn-by-turn Navigation App Voice Prompts on your car audio system while in Bluetooth mode.
- USB port on the module can also be used to charge your phone.
- Magnetic phone mount included.
AUDI
VOLKSWAGEN
1999-2005
A2
1999-2008
Beetle
2001-2006
A3
1998-2006
Golf
1998-2006
A4 / S4
1999-2008
Jetta
2001-2004
A6 / S6
1999-2006
Passat
1998-2003
A8 / S8
1. Radio must have an 8-pin CD changer port.
2. Not compatible with navigation radios.
Rev.081116
1/2
Navigations Apps
iPod, USB flash drive
and 3.5mm cable not
included.
1. Carefully remove the radio to gain access to the radio connectors.
2. Locate the 8-pin CD changer port. If there is a connector plugged into this cavity, you need to
unplug it.
3. Plug the BLUE 8-pin connector of the BTS-VW1 to the CD changer port of the radio.
4. Connect the BLACK wire with ring terminal to a solid chassis ground.
5. If the line-in feature will be used, plug a 3.5mm to 3.5mm cable (sold separately) to the BTS-VW1
module and run towards the desired location.
6. If a USB flash drive will be used, plug in a male to female USB cable (not included) to the
BTS-VW1 module and run to the desired location.
7. You can also mount the BTS-VW1 to an accessible location such as the center console or glove
box, to use the 3.5mm line-in and USB features.
8. Test the system for functionality before putting back the radio.
For Bluetooth function:
1. Turn on the radio and press the CD button. Screen will show “CD1 TRACK1”.
2. Go to the Bluetooth menu on your phone and connect to “Crux BT”.
3. BTS-VW1 will announce when the phone has been connected.
4. Play the music on your phone or other audio player and audio should be heard on the factory
sound system.
For USB Mode:
1. Plug in your USB flash drive to the BTS-VW1 USB port.
2. Turn on the radio and press the CD button. Screen will show “CD1 TRACK1”.
3. BTS-VW1 will announce “USB Mode”.
4. USB Audio should be heard on the factory sound system. Use the radio knobs or steering wheel
controls to track up and track down.
For Line-In Mode:
1. Plug in a 3.5mm to 3.5mm cable (sold separately) to the BTS-VW1 USB line-in jack.
2. Turn on the radio and press the CD button. Screen will show “CD1 TRACK1”.
3. BTS-VW1 will announce “Line-In Mode”.
4. Plug the other end of the 3.5MM cable to the audio player and press play. Audio should be heard
on the factory sound system.
Magnetic Phone Mount Assembly and Use:
1. Pop-in magnetic head to base socket.
2. Tighten locking nut to desired tilt.
3. Slide into the AC vent grille.
4. Use the desired metal plate size and stick
on the back of the phone or insert behind
the phone case.
Rev.081116
2/2
