for 7-14 Inch Tablets
PAD-CFSM
Custom Flex Suction Mount
Package Contents:
Instructions:
Custom Flex Suction Mount
4
Foam Pads
2. Loosen ball socket joint to rotate tablet to desired
orientation, then tighten ball socket again.
1.Press quick release button on side of tablet holder
to release the adjustable end. Insert tablet corner
against the spring arm, then push adjustable arm
down against opposite corner. Be sure it is as snug
as possible.
360 rotation˚
4. Installing your Device and Adjusting the Tablet holder
3.Adjusting the Flex Arm
2. Attaching Suction Mount Base
With the lock clasp up,
press the suction mount
against surface. Press the
lock clasp down to secure
in place.
1. Twist the SCREW KNOB of the arms
counter clockwise to release the
connection.
2. Adjust the arms to your favorite position and then
tighten the SCREW KNOB clockwise .
Foam Pad
Thickness
Tablet
Thickness:
1mm 0.67-1.06in
5mm 0.51-0.91in
10mm 0.31-0.71in
17-27mm
13-23mm
8-18mm
Use this table to determine the appropriate
foam pad to use with your tablet.
Note: sizes refer to total tablet size with or without a case.
/
/
/
Select the appropriate foam pad according to the
thickness of your tablet (or tablet in its case), then
press adhesive side into center of the tablet holder.
1mm Foam Pad
5mm
Foam
Pad
10mm
Foam
Pad
1.Attaching Foam Pad to Tablet Holder
