Sida 1/32

4-Channel high Power(40W 4Ch)

Electronic Tuning

Electronic Volume/Bass/Treble/Balance/ Fader

42Memory Capability (18FM + 12MW + 12LW)

Tel. Mute & Loudness controls

Full Detachable Face for Anti-Theft

Panel Carrying Case Included

INSTRUCTION MANUAL

ACP-

5030

RDS

CD Player/Receiver with 4-Channel High Power Output

Full Detachable Face Panel

WIRING CONNECTIONS

The pins in the ISO connector have the following functions (connector seen from the rear)

A. ELECTRIC CONNECTIONS

1. TEL.MUTE : BROWN

4. Back-up+12V : YELLOW

5. +12V (electric antenna) : BLUE

6. Dimmer : PINK

7. +12V supply(from ignition lock) : RED

8. Earth : BLACK

B. LOUD SPEAKER

1. +Right Rear : VIOLET

2. - Right Rear : VIOLET/BLACK

3. +Right Front : GRAY

4. - Right Front : GRAY/BLACK

5. +Left Front : WHITE

6. - Left Front : WHITE/BLACK

7. +Left Rear : GREEN

8. - Left Rear : GREEN/BLACK

NOTE! The red cable must be connected via the car s ignition lock to prevent unwanted

discharge of the battery if it is not used for longer periods of time.

GRAY

RED

WHITE

RED

WHITE

Front

Rear

Connect to input plns of additional AMP or device.

LINE OUT

(4 Ch.)

LINE OUT(RCA CORD)

D. FUSE

10A

BLACK

RED

WHITE

LINE OUT

(2 Ch.)
