Installationandoperationmanual
DaikinAlthermasimplifieduserinterface English
Installationandoperation
manual
DaikinAlthermasimplifieduserinterface
EKRUCBS
TableofContents
Installationandoperationmanual
2
EKRUCBS
DaikinAlthermasimplifieduserinterface
4P3822511–2014.06
TableofContents
Fortheuser 2
1 Buttons 2
2 Statusicons 2
Fortheinstaller 3
3 Overview:Installationandconfiguration 3
4 Toconnectthesimplifieduserinterface 3
5 ToupdatethesoftwarewithUpdater 3
6 Toupdatethesoftwaremanually 4
Fortheuser
1 Buttons
b
e
c
a
d
aSPACEHEATING/COOLINGCONTROL
Gototheroomtemperaturehomepage,whereyoucan:
▪ Readouttheactualroomtemperature.
▪ Press or toadjustthedesiredroomtemperature.
▪ Press toturnONorOFFtheroomtemperaturecontrol.
bDOMESTICHOTWATERCONTROL
Gotothedomestichotwaterhomepage,whereyoucan:
▪ Read out the actual domestic hot water tank temperature
(onlyifthesystemcontainsadomestichotwatertank).
▪ Read out the desired instant domestic hot water
temperature (only in case of instant domestic hot water
productionbyaboiler).
▪ Press to turn ON or OFF the domestic hot water
control.
cDHWTANKBOOSTERMODE
Activate the DHW tank booster mode (only if the system
contains a domestic hot water tank, and provided that the
domestichotwatercontrolisturnedON).
dON/OFF
Turn ONorOFF thespace heating/coolingor domestichot
watercontrol(ontherespectivehomepages).
e NAVIGATIONBUTTONS
Adjust the desired room temperature (on the room
temperaturehomepage).
2 Statusicons
Icon Description
Spaceoperationmode=Heating.
Spaceoperationmode=Cooling.
Domestichotwateroperation.
TheDHWtankboostermodeisactive.
Unitisoperating.
Actualtemperature.
Desiredtemperature.
Amalfunctionoccurred.
Emergencyoperationisactive.
If or is displayed, check the main user interface for more
informationor,ifnecessary,contactyourinstaller.
3Fortheinstaller
Installationandoperationmanual
3
EKRUCBS
DaikinAlthermasimplifieduserinterface
4P3822511–2014.06
Fortheinstaller
3 Overview:Installationand
configuration
Installation
▪ Thesimplifieduserinterfacecanonlybeusedincombinationwith
themainuserinterface.
▪ The main user interface acts as control centre and needs to be
installedneartheunit.
▪ The simplifieduser interfaceacts as roomthermostatandneeds
tobeinstalledintheroomthatyouwantittocontrol.
Configuration
Itisrequiredthatthesimplifieduserinterfacehasthesamesoftware
versionasthemainuserinterface.Ifnecessary,updatetheleastup
todate interface. You can find the software version on the box of
eachinterface.
Therearetwowaystoupdatethesoftware:
▪ ByusingtheUpdatersoftware.
▪ Bymanuallyupdatingthesoftware.
INFORMATION
Toupdatethesoftware,itisrecommendedtouseUpdater.
Updatingthesoftwaremanuallycantakeupto2.5hours.
4 Toconnectthesimplified
userinterface
1Connect thecableofthe simplifieduserinterface totheindoor
unit.
X2M
X5M
A2P A2P
21
a b
aMainuserinterface
bSimplifieduserinterface
2Fixthecablewithcabletiestothecabletiemountings.
5 Toupdatethesoftwarewith
Updater
Prerequisite: PC with Updater (contact your dealer for the correct
versionofthesoftware)
Prerequisite:PCUSBcableEKPCCAB3orhigher(includesaUSB
cableandadditionalconnectioncables)
1MakesurethattheindoorunitispoweredOFF.
2ConnecttheuserinterfacetothePC.
X1A
X1A
ab c
d
aPCwithUpdater
bUSBcable
cUserinterfacePCB
dToindoorunit
3PowerONtheindoorunit.
4OpenUpdater.
5InUpdater,goto"Updateprocedure".
6Type in the name of the interface (EKRUCBL* or EKRUCBS,
dependingonwhichyouareupdating).
7Selectthedesiredlanguagepack(onlyforEKRUCBL*).
8Followtheonscreeninstructions.
