OPERATION MANUAL
EWLP012KBW1N
EWLP020KBW1N
EWLP026KBW1N
EWLP030KBW1N
EWLP040KBW1N
EWLP055KBW1N
EWLP065KBW1N
Condenserless water-cooled water chillers
Operation manual
1
EWLP012~065KBW1N
Condenserless water-cooled water chillers
4PW61666-1A – 2012.04
CONTENTS Page
Introduction ....................................................................................... 1
Technical specifications ............................................................................. 2
Electrical specifications ............................................................................. 2
Description ........................................................................................ 3
Function of the main components.............................................................. 4
Safety devices............................................................................................ 4
Internal wiring - Parts table ........................................................................ 5
Before operation................................................................................ 6
Checks before initial start-up ..................................................................... 6
Water supply.............................................................................................. 6
Power supply connection and crankcase heating...................................... 6
General recommendations ........................................................................ 6
Operation .......................................................................................... 6
Digital controller......................................................................................... 6
Working with the units................................................................................ 7
Advanced features of the digital controller............................................... 10
BMS connection modbus ................................................................ 13
General description of Modbus................................................................ 13
Implemented error code........................................................................... 14
Defining the BMS setting ......................................................................... 14
Variables database .................................................................................. 14
Troubleshooting ............................................................................... 15
Maintenance.................................................................................... 16
Important information regarding the refrigerant used .............................. 16
Maintenance activities ............................................................................. 16
Disposal requirements ............................................................................. 16
Annex I ............................................................................................ 17
Saturated temperature............................................................................. 17
Menu overview ................................................................................ 18
The English text is the original instruction. Other languages are
translations of the original instructions.
This appliance is not intended for use by persons, including children,
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
INTRODUCTION
This operation manual concerns condensorless water-cooled water
chillers of the Daikin EWLP-KB series. These units are provided for
indoor installation and used for cooling applications. The EWLP units
can be combined with Daikin fan coil units or air handling units for air
conditioning purposes. They can also be used for supplying water for
process cooling.
This manual has been prepared to ensure adequate operation and
maintenance of the unit. It will tell you how to use the unit properly
and will provide help if problems occur. The unit is equipped with
safety devices, but they will not necessarily prevent all problems
caused by improper operation or inadequate maintenance.
In case of persisting problems contact your local Daikin dealer.
EWLP012KBW1N EWLP040KBW1N
EWLP020KBW1N EWLP055KBW1N
EWLP026KBW1N EWLP065KBW1N
EWLP030KBW1N
Condenserless water-cooled water chillers Operation manual
READ THIS MANUAL ATTENTIVELY BEFORE STARTING
UP THE UNIT. DO NOT THROW THIS MANUAL AWAY.
KEEP IT IN YOUR FILES FOR FUTURE REFERENCE.
Read the chapter "Operation" on page 6 before changing
the parameters.
Before starting up the unit for the first time, make sure that
it has been properly installed. It is therefore necessary to
carefully read the installation manual supplied with the unit
and the recommendations listed in "Before starting".
EWLP012~065KBW1N
Condenserless water-cooled water chillers
4PW61666-1A – 2012.04
Operation manual
2
Technical specifications
(1) Electrical specifications(2)
(1) Refer to the engineering data book for the complete list of specifications.
General EWLP 012 020 026 030
Dimensions HxWxD 600x600x600(mm)
Machine weight (kg) 104 138 144 149
Connections
• condenser
discharge
connection
(copper)
(mm) 12.7 flare 19.1 flare 19.1 flare 19.1 flare
• condenser liquid
connection
(copper)
(mm) 9.52 flare 12.7 flare 12.7 flare 12.7 flare
General EWLP 040 055 065
Dimensions HxWxD 600x600x1200(mm)
Machine weight (kg) 252 265 274
Connections
• condenser
discharge
connection
(copper)
(mm) 2x 19.1 flare 2x 19.1 flare 2x 19.1 flare
• condenser liquid
connection
(copper)
(mm) 2x 12.7 flare 2x 12.7 flare 2x 12.7 flare
Compressor EWLP 012 020 026 030
Model JT140BF-YE JT212DA-YE JT300DA-YE JT335DA-YE
Speed (rpm) 2900
Oil type FVC68D
Oil charge volume (l) 1.5 2.7 2.7 2.7
Refrigerant type R407C
Evaporator
Type brased plate heat exchanger
Min. water volume (l) 62.1 103 134 155
Water flow range (l/min) 31~69 53~115 65~153 76~179
Condenser
refer to engeneering specifications as published by the supplier of your
remote condenser
Compressor EWLP 040 055 065
Model 2x
JT212DA-YE
2x
JT300DA-YE
2x
JT335DA-YE
Speed (rpm) 2900
Oil type FVC68D
Oil charge volume (l) 2x 2.7 2x 2.7 2x 2.7
Refrigerant type R407C
Evaporator
Type brased plate heat exchanger
Min. water volume (l) 205 268 311
Water flow range (l/min) 101~229 131~307 152~359
Condenser
refer to engeneering specifications as published by the supplier of your
remote condenser
(2) Refer to the engineering data book for the complete list of specifications.
Model EWLP 012 020 026 030
Power supply
• Phase 3N~
• Frequency (Hz) 50
• Voltage (V) 400
• Voltage tolerance (%) ±10
• Recommended fuses (aM) 3x 16 3x 20 3x 25 3x 32
Compressor
• Phase 3~
• Frequency (Hz) 50
• Voltage (V) 400
• Nominal running current (A) 7.4 11.6 14.7 16.8
Control
• Phase 1~
• Frequency (Hz) 50
• Voltage (V) 230
• Recommended fuses (aM) factory installed
Model EWLP 040 055 065
Power supply
• Phase 3N~
• Frequency (Hz) 50
• Voltage (V) 400
• Voltage tolerance (%) ±10
• Recommended fuses (aM) 3x 40 3x 50 3x 50
Compressor
• Phase 3~
• Frequency (Hz) 50
• Voltage (V) 400
• Nominal running current (A) 11.6 14.7 16.8
Control
• Phase 1~
• Frequency (Hz) 50
• Voltage (V) 230
• Recommended fuses (aM) factory installed
Produktspecifikationer
| Varumärke: | Daikin |
| Kategori: | Hårdvarakylning |
| Modell: | EWLP020KBW1N |
