DHRCJ
Technical Information
Hydraulic Joystick
DHRCJ is part of D-HRC series.
D-HRC means Danfoss Hydraulic Remote Control valves which include:
DHRCJ — — Hydraulic Joystick
DHRCD — — Hydraulic Pilot Sectional Valve
DHRCP — — Hydraulic Foot Pedals
Excavator
Crane
Loader
AWP
Forklift
Drilling machine
Special vehicles
BC482581173883en-000101
1
Contents
General Description ---------------------------------------------------------------- 3 -----------------------------------------------------------------------------------
General Specication -------------------------------------------------------------- 4 -----------------------------------------------------------------------------------
Conguration ------------------------------------------------------------------------ 5 -----------------------------------------------------------------------------------
Options -------------------------------------------------------------------------------- 6 -----------------------------------------------------------------------------------
Dimensions---------------------------------------------------------------------------------- -------------------------------------------------------------------------- 10
Revision history --------------------------------------------------------------------- 13 ---------------------------------------------------------------------------------
2
BC482581173883en-000101
Description
Hydraulic Remote Controls (HRCs) are used to activate and control
directional valves or pumps from a remote and single operating
station. HRCs come in hand, foot and mechanically operated
versions, like the DHRCJ series, a dual-function hydraulic pilot
joystick that can achieve pilot control in both X-axis and Y-axis
directions. Suitable for various applications such as excavators,
drilling rigs, cranes, loaders and so on. Flexible conguration with
multiple valve bodies, handles, and switch options. It has excellent
handling performance, sturdy and durable design, and reliable
quality.
Operation
HRCs are fed a constant input pressure, from which they create
reduced output pressures that vary proportionally with lever or
pedal stroke. When the HRC is operated, output pilot pressure
ows to the main directional control valves, precisely controlling
main spool position and direction.
D-HRC Features
• Market leader with over 30 years of industry experience.
• Precision control with less leakage, close to at hysteresis and
excellent linearity.
• Reliability and Quality.
• Ergonomic eciency and customization capabilities provide
unparalleled exibility.
*HRC
Main Valve
BC482581173883en-000101
3
DHRCJ General Description
*Schematic exemplification can be either one of the DHRC products.
