BR-6204WLg
Wireless IEEE802.11 b/g
Broadband Router
Internet Connection Sharing
Integrated 4-port Ethernet switch and wireless 802.11b/g standards, BR-6204WLg is able to maximize Cable or
xDSL Internet connection. With the built-in DHCP server and NAT function, it allows up to 250 wired or wireless
devices share the Internet connection at the same time.
Wireless On/Off Switch
The push button on the back panel enables you to switch on/off wireless connection easily. When there is no
wireless device in the environment, you can press the button to stop wireless signal. It protects you from
unauthorized wireless connection and saves energy.
EZmax Multi-languages Setup Wizard*
A unique 16-language setup wizard is included in the CD ROM. You can select your native language and follow
the simple steps to setup Internet connection, password, SSID, wireless security and firmware upgrade.
Port Forwarding and DMZ
BR-6204WLg supports port forwarding and DMZ. You can enjoy the Internet game play, setup a web server
and execute other applications required ports opening.
Wireless Turbo Mode**
BR-6204WLg supports wireless turbo mode to increase the wireless performance 35% than the normal
wireless 802.11b/g connection.
** You need to connect with EW-7316Ug and EW-7326Ig to enable the turbo mode.
*The EZMax Setup Wizard only supports Edimax BR router series.
FEATURES AND TECHNICAL SPECIFICATIONS
HARDWARE INTERFACE MANAGEMENT POWER ADAPTER
1 RJ-45 WAN Port
4 RJ-45 Ethernet LAN Ports
LED Indicators: Power, WLAN, WAN, LNK/ACT
High gain 3dBi Antenna
Wireless on/off Button and Reset Button
Supports Remote Management
System Status and Log (Web Interface)
Firmware Upgradeable
DC 12V, 1A
WAN INSTALLATION MEMORY
Supports cable/xDSL modem
WAN Protocols: PPPoE/Static IP/DHCP/L2TP/PPTP
Multi-language EZMax Setup Wizard 2 MB NOR Flash
8 MB SDRAM
SECURITY Output Power & Receive Sensitivity HUMIDITY &
TEMPERATURE
NAT/NAPT IP Sharing
64/128-bit WEP, WPA and WPA2
Port / MAC / IP Filter
11g: 16±1dBm
11b: 18±1dBm
10-90%
(Non-condensing)
0~45 Degree Celsius
FUNCTIONS DIMENSION CERTIFICATIONS
Wireless Mode : AP / AP Client / WDS / AP+WDS
WMM Function to Meet the Multimedia Transmission
Requirement
DDNS (DynDNS, TZO)
Port Forwarding and DMZ
UPnP
VPN Pass Through (IPSec/PPTP)
Wireless Turbo mode
179 x 133 x 25 mm CE, FCC
An example of how the BR-6204WLg can be setup:
•Connect the BR-6204WLg router to your Ethernet (RJ-45) cable/xDSL modem.
• Connect a computer to the LAN port and setup the Internet connection by running the multi-language setup wizard.
• Share the Internet connection by connecting a LAN cable to other computers or wireless devices.
• You can also share your printer using an Edimax print server.
NETWORK SETUP DIAGRAM AND RELATED PRODUCTS
