MICROWAVE INSTALLATION KIT
1. Frame IPCS 2. Fixing Bolt 4 PCS 3. Bolts 0.12''X0.47'' 8 PCS
4. Metal Piece IPCS 5. Base setting paper I PCS 6. feetmat 2 PCS
7. Bolts 0.16''X10.39'' 4PCS
Technical Specifications of the Installation Kit
Cavity dimensions Overall Kit Dimensions
Internal Width 22.36'' Width 23.31''
External FRONT HEIGHT 14.37'' Height 14.8''
Depth 21.65'' Depth 0.79''
Microwave Oven Cabinet
vent
MICROWAVE CAVITY
vent
Cabinet Measurement Requirements (illustrated above):
1. Cabinet's inner dimension in transverse direction is 22.36''. This is the minimum distance from the left batten to right batten.
Do not alter.
2. Cabinet's inner dimension in lengthways direction is 14.37''. This is the minimum distance from the left batten to right batten.
Do not alter.
3. Cabinet' s depth should be no less than 21.65''.
4. Outside dimension of cabinet should be no less than 23.46'' as the frame length is 23.31''.
5. Cabinet's board less than 0.59'' or 0.78'' thick.
8. Fix metal sheet 2 PCS
450
28.4
568
94.7
320
380
1
2
4
35
6
7
8
Attention: The bottom of the Microwave Oven should be 850mm
away from the floor at least while doing the installation;
1/EN
21.65''
5.91''
21.65''
5.91''
14.37''
3.94''
22.36''
15.75''
INSTALLATION STEPS
Metal Sheet
1. Fix the cabinet as per diagram above. Put the base
setting paper (Component 5) on the bottom board of the
cabinet cavity. Keep the paper's front edge and cabinet
outside edge in one line. Then put the base (Component 6)
on the paper and adjust their holes as per the hole position
in the drawing. Then, fix the required bolts.
2. Fix Metal sheet end on the left and right of
Cabnit, another end on the upper and lower of
cabinet. After fixing the metal sheet, then fix
the buckle and let it touch another end of
metal sheet tighly. Please pay attantion that
buckle's bent side shall be installed as to the
drawing while fixing the bunkle. Then press
the buckle and take away metal sheet, tigten
screws.
N.B. Indentation is on
left-hand side
3. Put the Microwave Oven carefully into
the cabinet, placing the underside of the
Microwave Oven into the base plate now
created.
4. Keep the Microwave Oven in a horizontal direction.
Push the metal piece of the frame into the metal
buckle. The frame should now be installed.
Assemble fix metal sheet to the front
two feet after the oven fixed
2/EN
3/EN
ir Inlet installation instruction:A
A
