Operation & Installation Instruction
Garnet SRS2 Freestanding
Please keep these instrution for future reference.Rev B 230045
Garnet SRS2 Freestanding 12
A.F. Gason Pty Ltd reserves the right to modify or alter specications, material etc. in the intrest of product improvement
WARRANTY
1. Subjects to clauses 2 & 3 of this warranty, A.F. Gason Pty Ltd ACN 004 667 556 (Gason warrants the follow components of its heaters against defects in workmanship
and/or materials for the following periods from the date of purchase:
a) the rebox for ten years;
b) the paint nish for a period of twelve months if the purchaser has followed the instruction provided by Gason in the Operati on and Installation Instructions manual; and
c) all other components for twelve months execpt the glass, re brick lining or bae plate if, in the opinion of Gason, these it ems have been damaged by impact.
2. This extended warranty does not apply;
a) if the heater is purchased from a person who has not been authorised by Gason to sell its products;
b) if, in the opinion of Gason, the heater or any other component has been subject to abuse, misuse, alteration, modication or has not been installed, operated or maintained in
accordance with the instructions provided b y Gason; or,
c) to owners other then the original purchaser.
3. If you believe that the heater you purchased contains a manufacturing defect and you wish to make a claim under this warranty, please contact an authorised Gason servi ce
centre to arrange for an assessment.
4. If, after assessing the heater, Gason determines that the heater contains a manufacturing fault, Gason may at its discretion:
a) replace the heater;
b) repair or replace specic components of the heater; or
c) provide a full refund.
5. Parts replaced under warranty are warranted for the balance of their original warranty period.
6. If, at the discretion of Gason, the heater or any part needs to be replaced, serviced or repaired at an authorised Gason service centre, then the person claiming under this
Warranty must pay a ll costs associated with:
a) returning the heater; and
b) the delivery or collection of any new or repaired heater.
Our goods come with guarantees that cannot be excluded under the Austrlian Consumer Law. You are entilted to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or repla ced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
Any benets you receive under these warranties are in addition to other rights and remedies that you may have as a consumer under a law in relation to the heater to which
these warranties relate.
These warranties are given by:
A.F. Gason Pty Ltd
Blake Street
Ararat VIC 3377
Please contact us if y ou have any queries on:
Phone: 03 53522151
or email us via the “Contact Us” section of our website: www.gason.com.au
Garnet SRS2 Freestanding 2 Garnet SRS2 Freestanding 11
T
Read and follow these instructions carefully before installing and
u
sing this appliance
S
AVE THESE INSTRUCTIONS
PAGE INTENTIONALLY BLANK
WARNING
!
WARNING
!
Safety Warnings
•
A ue re with resulting damage may occur if the appliance is not installed,
operated and maintained as per this booklet.
• Never place combustible materials such as wood, paper or furniture near the
appliance.
• This appliance is designed to burn dry wood. Do not burn rubbish, driftwood,
flammable liquids or any substance containing salts or corrosives.
• This appliance must not be installed and operated in an area where kerosene,
petrol, paint thinner or other ammable liquid is used or stored.
• The ue system must be inspected and cleaned annually or sooner if required.
Failure to do so could result in an excessive buildup of creosote which may
result in a ue re which may damage the ue or cause damage to your home.
• The surface of the appliance becomes hot during operation. Do not touch the
surface of this appliance. Keep children away from this appliance during
operation. Do not allow anyone to operate this appliance who is not familiar
with this instruction booklet.
WARNING
!
Paint curing and care
Your heater is coated with the best available heat resistant paint. Even though
t
he paint has been baked after application, it may require further temperature
c
uring. It may, if you overre the heater on its rst re, discolour. For your rst
t
wo or three rings, never exceed medium air setting and always have the fan
o
n when above low burn. Do not wipe the heater while the paint is curing. After
t
he paint has cured the only maintenance required to maintain the heaters nish
i
s to wipe it with a soft cloth. Do not use any commercial cleaners or solvents on
t
he paint nish.
W
e are proud of the presentation of our products. If at any time you need to
f
reshen up the paint, your local dealer has touchup paint available for purchase.
Y
ou may even change the colour of your heater if you wish.
If you have any enquiries, please contact the dealer from whom you purchased your heater:
P
LEASE COMPLETE:
D
ealer Name
D
ealer Address
Phone:
P
lease attach your original purchase dockets to this booklet for future reference.
Garnet SRS2 Freestanding 10 Garnet SRS2 Freestanding 3
Troubleshooting Installation
(Continued)
• Smoke entering the room from the rebox when the door is open may be caused by
• Insucient length of ue (Flue to be 4500mm minimum underneath the base of heater to
underside of cowl)
Increase height of ue
• Flue downdraught
Consult dealer or increase height of ue.
• Creosote buildup in ue
Remove cowl and clean ue as per cleaning instructions. Check moisture content of wood.
• Excessive ash build up
some woods will give large amounts of ash despite how you run the h eater. Others will give you very little.
Use the wood which is most convenient for you as long as it is dry. After a period of time you will get to
know when to empty your unit. Bark will give you excessive ash. Try not to burn it.
If you are burning wood that gives you charcoal, you maynd that after running the heater say for 8 hours
at maximum burn rate, the charcoal builds up excessively. Overnight burn will reduce this charcoal back to
a ne ash. If you are not ready to shut down for overnight burn when you next fuel the stove, load the
stove with only one piece of wood and lay it across the rebox on top of the charcoal. Open the air control
wide open and you will nd the charcoal will burn down with the one piece of wood. Repeat the process
until the ash level is signicantly reduced.
WARNING
!
Installation
THE INS TALL TION OFA THIS APPLIANCE MUST BE CARRIED OUT AS PER THIS
MANUAL AND THE FLUE MANU FACTURERS SPECIFIC ATIONS.
WE RECOMMEND TH AT YOU USE A QUALIFIED INS TALLER TO RY TCAR OU
THE INS TALLATION.
If you have any other enquirie please contact the dealer from whom yo s, u
purchased your heate r.
THIS APPLIANCE WEIGHS IN EXCESS OF 120 KILOGRAM S. EEXTREME CAR
SHOULD BE TAKEN WHEN HANDLING THE APPLIANCE.
t is important you understand these installation instructions and minimum clearances to combustible befor
electing a position for your Eureka Garnet to ensure a safe and correct installation is achieved.
nstallation Permit
epending on your local authority requirements, a permit may be required for the installation of your heater. It i
our responsibility to arrange the same.
learances
ll dimensions used in this document are in millimeters and are minimum unless otherwise stated. Thes
imensions state the minimum distance the Eureka Garnet can be placed in relation to any non-combustibl
aterials – plaster, wallpaper, timber, MDF etc.
n the instance your Eureka Garnet is surrounded by non-combustible materials – brick, stone, concrete, cemen
heet, villaboard or similar, wall clearances can be reduced to 100mm. A 100mm clearance is required to ensur
oom air can circulate around the woodheater while operating.
he Eureka Garnet freestanding heater conforms to AS/NZS 2918:2001 when positioned in relation to combustible
urfaces as shown in the graphic on the following page.
earth Requirements
f the Eureka Garnet will be installed onto a non-combustible oor such as a brick, stone or a concrete slab with
iles etc. which is at least 20mm thick and extends at least 450mm in front of the appliance base, a hearth or oor
rotected may not be required.
f the Eureka Garnet is to be installed onto a combustible oor, a minimum 20mm cement sheet or similar non-
ombustible hearth or oor protector must be placed on top of the combustible oor. At a minimum, the oor
rotector must extend 450mm in front of appliance base. The protector must be at least 1020mm wide and
80mm deep. If desirable, the oor protector can extend to 1100mm deep to meet skirting boards or walls at the
ear of the appliance when installed as per the rear wall clearances.
or detail please see pictorial on next page.
