1. Subject to clauses 2 & 3 of this warranty, A.F. Gason Pty Ltd ACN 004 667 556 (Gason) warrants the following components of its heaters against defects in workmanship
and/or materials for the following periods from the date of purchase:
(a) the firebox for ten years;
(b) the paint finish for a period of twelve months if the purchaser has followed the instructions provided by Gason in this Operation and Installation Instructions manual; and
(c) all other components for twelve months except the glass, fire brick lining or baffle plate if, in the opinion of Gason, these items have been damaged by impact.
2. This extended warranty does not apply:
(a) if the heater is purchased from a person who has not been authorised by Gason to sell its products;
(b) if, in the opinion of Gason, the heater or any component has been subjected to abuse, misuse, alteration, modification or has not been installed, operated or maintained in
accordance with the instructions provided by Gason; or
(c) to owners other than the original purchaser.
3. If you believe that the heater you purchased contains a manufacturing defect and you wish to make a claim under this warranty, please contact an authorised Gason service
centre to arrange for an assessment.
4. If, after assessing the heater, Gason determines that the heater contains a manufacturing fault, Gason may at its discretion:
(a) replace the heater;
(b) repair or replace specific components of the heater; or
(c) provide a full refund.
5. Parts replaced under this warranty are warranted for the balance of their original warranty period.
6. If, at the discretion of Gason, the heater or any part needs to be replaced, serviced or repaired at an authorised Gason service centre, then the person claiming under this
warranty must pay all costs associated with:
(a) returning the heater; and
(b) the delivery or collection of any new or repaired heater.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.
Any benefits you receive under these warranties are in addition to other rights and remedies that you may have as a consumer under a law in relation to the heater to which
these warranties relate.
These warranties are given by:
A.F. Gason Pty Ltd
Blake Street
Ararat VIC 3322
Please contact us if you have any queries on:
Phone: 03 5352 2151;
or email us via the “Contact Us” section of our website: www.gason.com.au.
A.F. Gason Pty Ltd reserves the right to modify or alter specifications, materials, etc. in the interest of product improvement.
WARRANTY
Stockade SRS5 Insert
16
GPN 230576
Stockade SRS5 Insert
Operation & Installation Instructions
Woodheating
REV. B
Please keep these instructions for future reference.
Stockade SRS5 Insert
15
THIS PAGE INTENTIONALLY LEFT BLANK
Stockade SRS5 Insert
2
!
WARNING
Read and follow these instructions carefully before installing and
using this appliance.
SAVE THESE INSTRUCTIONS
Paint curing and care
!
WARNING
• A flue fire with resulting damage may occur if this appliance is not installed,
operated and maintained as per this booklet.
• Never place combustible material such as wood, paper or furniture near the
appliance.
• This appliance is designed to burn dry wood. Do not burn rubbish, driftwood,
flammable liquids or any substance containing salts or corrosives.
• This appliance must not be installed and operated in an area where kerosene,
petrol, paint thinner or other flammable liquid is used or stored.
• The flue system must be inspected and cleaned annually or sooner if required.
Failure to do so could result in an excessive build up of creosote which may
result in a flue fire which may damage the flue or cause damage to your
home.
• The surface of the appliance becomes hot during operation. Do not touch the
surface of this appliance. Keep children away from the appliance during
operation. Do not allow anyone to operate this appliance who is not familiar
with the instructions in this booklet.
!
WARNING
Your heater is coated with the best available heat resistant paint. Even though
the paint has been baked after application, it may require further temperature
curing. It may, if you overfire the heater on its first fire, discolour. For your first
two or three firings, never exceed medium air setting and always have the fan on
when above low burn. Do not wipe the heater while the paint is curing. After the
paint has cured the only maintenance required to maintain the heaters finish is to
wipe it with a soft cloth. Do not use any commercial cleaners or solvents on the
paint finish.
We are proud of the presentation of our products. If at any time you need to
freshen up the paint finish, your local dealer has touch up paint available for
purchase.
If you have any enquires, please contact the dealer from whom you purchased your heater:
PLEASE COMPLETE:
Dealer Name
Dealer Address
Phone
Please attach your original purchase dockets to this booklet for future reference.
Safety Warnings
Stockade SRS5 Insert
3
Installation
!
WARNING
This heater is to be installed into a masonry fireplace or a Eureka ZCV Clearance
cabinet.
THE INSTALLATION OF THIS APPLIANCE MUST BE CARRIED OUT AS PER THIS
MANUAL AND THE FLUE MANUFACTURERS SPECIFICATIONS.
WE RECOMMEND THAT YOU USE A QUALIFIED INSTALLER TO CARRY OUT
THE INSTALLATION.
If you have any other enquiries, please contact the dealer from whom you
purchased your heater.
THIS APPLIANCE WEIGHS IN EXCESS OF 120 KILOGRAMS. EXTREME CARE
SHOULD BE TAKEN WHEN HANDLING THE APPLIANCE.
Installation
All dimensions used in this document are in millimetres and are minimum
unless otherwise stated. Under no circumstances can these dimensions be
reduced.
A.F. Gason Pty Ltd accepts no liability whatsoever for any interpretation of
AS/NZS 2918:2001
Installation Permit
Depending on your local authority requirements, a permit may be required for
the installation of your heater. It is your responsibility to arrange the same.
Installation into existing or masonry fireplace
The Eureka Stockade SRS5 insert can be installed into a masonry fireplace with
a flue system that is in accordance with the relevant sections of AS/NZS
2198:2001. No combustible or heat sensitive material may be placed closer
than 1340mm from the top of the hearth/base of appliance and 50mm either
side of the appliance’s fascia.
Minimum hearth depth of 510mm from the front of the fascia panel must be
achieved. If it is desired to reduce the hearth depth to the minimum allowable
300mm in front of appliance fascia, the appliance must be raised to a new
height - refer elevated installation instructions on page 7.
For detailed mantle clearance dimensions, refer to Figure 4.
Brick removal
!
WARNING
IF BRICKS REQUIRE REMOVAL WHEN PREPARING THE FIREPLACE, ENSURE THAT
YOU DO NOT EXPOSE COMBUSTIBLE MATERIALS BEHIND THE BRICKWORK OR
WEAKEN THE INTEGRAL STRUCTURE OF THE CHIMNEY.
Section showing Installation
Figure 1. Masonry Installation
Stockade SRS5 Insert
14
• Smoke entering the room from the firebox when the door is open may be caused by
• Insufficient length of flue (Flue to be 4500mm minimum from underneath base of heater to underside of cowl)
– Increase height of flue.
• Flue Downdraught
– Consult dealer or increase height of flue.
• Creosote Build up in flue
– Remove cowl and clean flue as per cleaning instructions. Check moisture content of wood.
• Excessive ash build up
Some woods will give large amounts of ash despite how you run the heater. Others will give you very little. Use the
wood which is most convenient for you as long as it is dry. After a period of time you will get to know when to
empty your unit. Bark will give you excessive ash. Try not to burn it.
If you are burning wood that gives you charcoal, you may find that after running the heater say for 8 hours at
maximum burn rate, the charcoal builds up excessively. Overnight burn will reduce this charcoal back to a fine ash. If
you are not ready to shutdown for overnight burn when you next fuel the stove, load the stove with only one piece
of wood and lay it across the firebox on top of the charcoal. Open the air control wide open and you will find the
charcoal will burn down with the one piece of wood. Repeat the process until the ash level is significantly reduced.
Troubleshooting (Continued)
