Tel: + : + : www.fenixlight.com E86 755 29631163/83/93 Fax- - 86 755 29631181- - Website -mail:info@fenixlight.com
Address: 8/F, 2nd Building, DongFangMing Industrial Center , Bao’an, Shenzhen 518133, China, 33rd District
Fenix™ E15
Fenix E15 is a universal EDC flashlight. Offering 3 brightness levels, it can meet various
requirements of the brightness and the runtime perfectly. The portable and compact design makes
it extremely convenient to be carried. It performs well in the cold areas due to the anti-freezing
lithium battery. Thanks to the advanced constant brightness technology and waterproofing to the
IPX-8 Standard, E15 must be able to satisfy your needs in different outdoor conditions and in
emergency.
Technical Parameters
ANSI/FSC
Mid
Low
High
OUTPUT
75 LUMENS
10 LUMENS
140 LUMENS
RUNTIME
4h 16min
30h
1h 51min
DISTANCE
89m
INTENSITY
1986cd
IMPACT
RESISTANCE
1m
WATERPROOF
IPX-8 underwater 2m
Extra
FUNCTION
ACCESSORIES
Key chain and spare o- ring
◎ Cree XP-E LED with a lifespan of 50,000 hours
◎ Uses one 3V CR123A Lithium battery
◎ 59.6mm (Length) x 19.7mm (Diameter)
◎ -23 gram weight (excluding battery)
◎ Digitally regulated output - maintains constant brightness
◎ Reverse polarity protection, to protect from improper battery installation
Tel: + : + : www.fenixlight.com E86 755 29631163/83/93 Fax- - 86 755 29631181- - Website -mail:info@fenixlight.com
Address: 8/F, 2nd Building, DongFangMing Industrial Center , Bao’an, Shenzhen 518133, China, 33rd District
◎ Reliable twisty switch
◎ Capable of standing up securely on a flat surface to serve as a candle
◎ Made of durable aircraft-grade aluminum
◎ Premium Type III hard- -anodized anti abrasive finish
◎ High-efficiency total reflection lens
Notice: The above-mentioned parameters (tested with high-quality CR123A Lithium battery in
Lab) are approximate and may vary between flashlights, batteries and environments.
Operation Instruction
Screw the light head to turn it on and unscrew it to turn it off.
Turn off the light and turn it on again within two seconds, it will select the brightness level in the
order of Mid→Low→High→Cycle.
If the off- time is over two seconds, when turn on again, it will enter into the Mid brightness level.
Battery Specifications
Type
Dimensions
Nominal
voltage
Usability
Non- rechargeable Battery
(Lithium)
CR123A
3V
Usable
√
Rechargeable Battery
(Li- ion)
16340
3.7V
Banned
×
Battery Replacement
Unscrew the light head to put in the battery with the anode (+) toward the light head, screw the
light head back on to test.
Usage and Maintenance
◎ Please don't disassemble the sealed head, doing so can cause damage to the flashlight and will
void the warranty.
◎ Please use battery of high quality, and take out the battery if you do not use the flashlight for a
long time, or the flashlight could be damaged by electrolyte leakage or battery explosion which is
caused by low quality battery.
◎ - -The o ring may be worn out after using for a long time. If it happens, please replace the o ring
with a new one to keep the flashlight properly sealed against water.
◎ Please clean the contacts of your light from time to time, especially if the light flickers or
doesn't light up. There may be several reasons for a flickering or not working light:
Reason A: The battery needs replacing.
Solution: Replace battery (Please confirm the correct installation of anode and cathode).
Reason B: The threads PCB board contact or other contacts are dirty.
Solution: Clean the contact points with an alcohol soaked cotton swab.
If the above methods don't work, please contact your distributor and refer to the warranty policy.
Notice: The routine cleaning video can be watched and downloaded through Fenix official website,
please log onto the service channel->'maintenance for light'.
Product Warranty
We will replace products afflicted with manufacturing defects within 15 days of purchase and
repair a light free of charge within 24 months of purchase if problems develop with normal use; if
repair is required after 24 months from the date of purchase, we will charge for parts. The total
repair fee is dictated by the cost of the replaced materials.
Tel: + : + : www.fenixlight.com E86 755 29631163/83/93 Fax- - 86 755 29631181- - Website -mail:info@fenixlight.com
Address: 8/F, 2nd Building, DongFangMing Industrial Center , Bao’an, Shenzhen 518133, China, 33rd District
Warranty Card Registration
We kindly suggest that you register your guarantee card on the official website of Fenixlight
Limited. You can get an extra six-month warranty period once you have successfully registered.
What's more, you could take part in the lottery of questionnaire at the same time.
Warning
E15 is a high-intensity lighting device and capable of causing eye damage, avoid shining the light
directly into the eyes.
