Fenix TK32 Flashlight User Manual
400 meters (437 yards) from a palm- sized light? No, you are not mistaken. The TK32
Flashlight drives deep downrange to 400 meters -with 900 lumen output. Balanced for
easy carry, the light also features red, green and blue LEDs and the dual tail switch
system color flashlight. -is all you need to control this multi
Technical Parameters
ANSI/NEMA
FL1
Turbo
High
Mid
Low
OUTPUT
900
lumens
400
Lumens
130
Lumens
10
Lumens
RUNTIME
1h30min
3h45min
13h
15 0h
DISTANCE
400m（Max）
INTENSITY
40000cd（Max）
IMPACT
RESISTANT
1m
WATER
RESISTANT
IPX-8 ( 2 meters underwater)
ACCESSORIES
Holster, lanyard and spare O- ring
Notice: The above-mentioned parameters (lab- -tested by Fenix using ARB L2S 18650
Li-ion battery) are approximate and may vary between flashlights, batteries and
environments.
The flashlight will drop down into the high brightness level after working about 15 minutes
in the Turbo mode. Therefore, the runtime of Turbo output is an accumulated time.
● Utilizes Cree XM-L2 (U2) LED with a lifespan of 50,000 hours
● I ntegrated Red, Green and Blue LEDs with 100mW output
● Uses one 18650 rechargeable Li- ion battery or two CR123A batteries
● 159 mm (Length) 25.4 mm (Body Diameter) 52mm (Head Diameter)× ×
● 180- gram weight (excluding batteries)
● Digitally regulated output - maintains constant brightness
● Low-voltage warning function to remind users of low power
● Reverse polarity protection to protect from improper battery installation
● Anti- - roll, slip resistant body design
● Dual tail switch for momentary-on and output selection
● Made of durable aircraft-grade aluminum
● Premium Type III hard- -anodized anti abrasive finish
● Toughened ultra-clear glass lens with anti- reflective coating
Operation
Momentary- on
Slightly press and hold the tail power switchTK32’s .
Constant- on
Fully press the tail power switch to turn the light on, pressing again to turn the light off.
Output selection
When the light is on, press the tail mode switch to cycle through four brightness levels in
the order of Turbo>Low>Mid>High
Colored LEDs
When the light is on, press and hold the mode switch for one second to light up the
colored LEDs. P ress the mode switch to cycle through them in the order of
Red>Green>Blue. Press and hold the mode switch for one second to return to white light.
Instant access to red light
When the light is off, press and hold the mode switch to activate the red light momentarily
Intelligent memory circuit
White light
The flashlight memorizes the last used output of white light. The next time you turn the
flashlight on; . it will activate the last used brightness level of white light
Colored LEDs
The flashlight memorizes the last used The next time you colored LED. switch from the
white light to colored ctivate the last light, it will a used color.
Over-heat Protection:
TK32 will accumulate a lot of heat when it is working in Turbo output. To avoid
overheating, the flashlight will automatically drop down into the High brightness level after
working in Turbo output for 15 minutes. If the non-stop Turbo output is needed, just reset it
again.
Low-voltage Warning Function
When the voltage level drops below the preset level, the flashlight will downshift to a lower
brightness level. When the voltage level drops below the threshold voltage in Low output
mode, the flashlight will blink three times every five minutes to remind you to replace the
battery.
Battery Specifications
Type
Dimensions
Nominal
voltage
Usability
FENIX ARB- L2 Series
18650
3.7V/3.6V
Recommend
ed
√
Non-rechargeable
Battery
(Lithium)
CR123A
3V
Recommend
ed
√
Rechargeable Battery
(Li- ion)
16340
3.7V/3.6V
Cautious*
!
Rechargeable Battery
(Li- ion)
18650
3.7V/3.6V
Cautious*
!
Rechargeable Battery
（ ）LiFePO4
16340
3.2V
Usable
√
Rechargeable Battery
（ ）LiFePO4
18650
3.2V
Usable
√
Warning: Please do not mix batteries of different brands, size, capacity or type. Doing so
may cause damage to the flashlight or the batteries being used.
* -18650 /16340 Li ion batteries are powerful cells designed for commercial applications
and must be treated with caution and handled with care. Quality batteries with circuit
protection will reduce the potential risk for combustion or explosion but cell damage or
short circuiting are potential risks the user assumes.
Battery Replacement
Unscrew the tail cap to insert the batteries with the anode side (+) toward the light's head,
then align the threads and screw the tail cap back on.
Usage and Maintenance
◎Please don't disassemble the sealed head, doing so can cause damage to the flashlight
and will void the warranty.
◎We recommend the use of high quality battery. If the flashlight is not to be used for an
extended period, remove the battery, or the flashlight could be damaged by electrolyte
leakage or battery explosion.
◎Due to the momentary-on tactical switch, the flashlight may be accidentally activated
when stored, transported or placed in a pocket. Unscrew the tail cap one-half turn or take
out the battery to avoid unwanted operation.
◎The o-ring may be worn out after using for a long time. If this happens, please replace
the o- ring with a new one to keep the flashlight properly sealed against water.
◎Please clean the contacts of your light from time to time, especially if the light flickers or
doesn't light up. There may be several reasons for a flickering or not working light:
Reason A: The battery needs replacing.
