TK60 Flashlight
Fenix TK60 is a high- -intensity multi functional flashlight powered by D batteries. The dual switch
system in the front can realize a rapid selection between the four brightness levels and the two
different flashing functions. With a max 800 day extremely long runtime, it - -lumen output a 15and
must be able to meet your needs in various conditions.
Meanwhile the compact design can lessen the volume and decrease the weight of TK60 to the
largest extent. With the perfect combination of the outstanding performance and the enjoyment of
using it, TK60 is the dependable partner when outdoor searching, caving or using as a spare light
for automobiles, etc.
Technical Parameters
General Mode
Flashing Mode
ANSI/FSC
Turbo
High
Mid
Low
Strobe
SOS
OUTPUT
800
LUMENS
350
LUMENS
111
LUMENS
10
LUMENS
800
LUMENS
111
LUMENS
RUNTIME
4h 16min
12h
40h
400h
DISTANCE
476m
INTENSITY
56628cd
IMPACT
RESISTANT
1m
WATERPROOF
IPX-8 2m ，underwater
EXTRA
FUNCTIONS
ACCESSORIES
Lanyard, spare o- ring and strap
◎ Uses Cree XM-L LED with a lifespan of 50000 hours
◎ Uses four 1.5V (NiD -MH, Alkaline) batteries
◎ 354mm (Length) mm (Diameter) mm(Head) x 40 x 62.5
◎ -407 gram weight (excluding batteries)
◎ Digitally regulated output - maintains constant brightness
◎ Reverse polarity protection, to protect from improper battery installation
◎ Dual switch system in the front, simple and fast operation
◎ Made of durable aircraft- grade aluminum
◎ Premium Type III hard- -anodized anti abrasive finish
◎ Toughened ultra-clear glass lens with anti- reflective coating
Notice: The above-mentioned parameters (tested by four high-quality D Ni-MH batteries with a
measured capacity of 9000mAh in Lab) are approximate and may vary between flashlights,
batteries and environments.
Operation Instruction
The right button switch is a power switch. A single press on it can turn it on/off. The left button
switch is a mode switch;
When turn on the light, it will enter into the default general mode directly. A fast double press on
the power switch can select between the general mode and the flashing mode.
In the general mode, a single press on the mode switch can transfer the brightness levels in the
order of Turbo→Low→Mid→High→Cycle.
In the flashing mode, a single press on the mode button switch can select different flashing
functions in the order of Strobe→SOS→Cycle.
The circuit can memorize any brightness level in the two modes. When turn on the light or transfer
the mode, it will directly enter into the brightness level when switched off.
Battery Specifications
Type
Dimensions
Nominal voltage
Usability
Ni- MH battery
D
1.2V
Recommended
√
Alkaline battery
D
1.5V
Usable
√
Non- rechargeable Battery
(Lithium)
D
1.5V
Usable
√
Rechargeable Battery
(Lithium)
32650
3.7V
Banned
×
Battery Replacement
Unscrew the tail cap to put in the batteries with the anode side (+) toward the light head, screw the
tail cap and the extension tube back on to test.
Usage and Maintenance
◎ For first use, open the package and screw off the tail cap to attach the extension tube to the
end of the tube. And then put in four batteries with the anode side (+) toward the light head,
screw the tail cap and the extension tube back on to test.
◎ If the light is not used for a couple of days, plea for half a se unscrew the head turn to prevent
slow discharge of the batteries.
◎ The light can be powered by three batteries in emergency. Please screw off the extension tube
from the tube and put in three batteries, screw the tail cap back on to test. However in this
case, the runtime of each brightness level will be shortened.
◎ Please don't disassemble the sealed head, doing so can cause damage to the light and will void
the warranty.
◎ -High power light should use battery with high current discharge capability; We suggest using
high performance Ni-MH rechargeable battery to increase the runtime of this high
intensity light.
◎ Please use battery of high quality, and take out the battery if the flashlight will not be used for
a long time, or it may cause damage from electrolyte leakage or battery explosion.
◎ - -The o ring may be worn out after using for a long time. If it happens, please replace the o ring
with a new one to keep the light properly sealed against water.
◎ Please clean the contacts of your light from time to time, especially if the light flickers or
doesn't light up. There may be several reasons for a flickering or not working light:
Reason A: The battery needs replacing.
Solution: Replace batteries (Please confirm the correct installation of anode and cathode).
Reason B: The threads, PCB board contact or other contacts are dirty.
Solution: Clean the contact points with an alcohol soaked cotton swab.
If the above methods don't work, please contact the distributors and refer to the warranty policy.
Notice: The routine cleaning video can be watched and downloaded through Fenix official website,
please log onto the service channel->'maintenance for light'.
Product Warranty
We will replace products afflicted with manufacturing defects within 15 days of purchase and
repair a light free of charge within 24 months of purchase if problems develop with normal use; if
repair is required after 24 months from the date of purchase, we will charge for parts. The total
repair fee is dictated by the cost of the replaced materials.
Warranty Card Registration
We kindly suggest that you register your guarantee card on the official website of Fenixlight
Limited. You can get an extra six-month warranty period once you have successfully registered.
What's more, you could take part in the lottery of questionnaire at the same time.
Warning
TK60 is a high-intensity lighting device and capable of causing eye damage, avoid shining the
light directly into the eyes.
