Sida 1/40

wall-mounted gas fired,

condensing combination boiler

DOMIcompact F 30 B

cod. 3540B284 - 05/2007 (Rev. 00)



G C N° 47-267-38

INSTRUCTIONS FOR USE, INSTALLATION AND MAINTENANCE

FOR THE UNITED KINGDOM EIRE&

Seasonal Efﬁ ciency

(SEDBUK)

band B

2Cod. 3540B284 - 05/2007 (Rev. 00)

DOMIcompact F 30 B

• Read the warnings given in this manual thoroughly.

They provide important information for safe instal-

lation, use and maintenance

• The instruction manual, by law must be left with the

end user.

• If the appliance is sold or transferred to another

owner or if the owner moves, leaving the appliance

behind, always ensure that the manual is kept with

the appliance for consultation by the new owner

and /or installer.

• Incorrect installation or poor maintenance absolves

the manufacturer from all liability for damage to

persons and property.

• Installation and maintenance must be carried out

in accordance with current legislation, according

to the manufacturer’s instructions and by qualified

corgi registered engineer.

• Before service or maintenance work is carried out

isolate the appliance from the mains electricity

supply.

• In the event of malfunction or faulty operation, iso-

late the appliance. Do not attempt to repair or carry

out any other operation on the appliance directly.

Contact Ferroli or a qualified engineer only.

• Repairs or the replacement of components must be

carried out exclusively by qualified personnel using

original spare parts only. Failure to adhere to the above

may compromise the safety of the appliance.

• To guarantee efficient operation, the appliance must

be serviced once a year by a Corgi registered engi-

neer.

• The appliance may not be used for purposes other

than those for which it was explicitly designed.

• Incorrect installation and use or failure to follow the

instructions provided by the manufacturer absolve

the manufacturer from all liability for damage.

• After unpacking, check that the contents are correct

and undamaged.

• Keep packing out of reach of children as it could be

potentially hazardous.

• To clean external parts, use a damp cloth moistened

with soapy water if necessary. Avoid using abrasive

cleaning products and solvents.

This symbol indicates and is placed next to all safety information. “Caution”

Strictly follow these instructions in order to avoid danger and damage to persons

or property.

This symbol calls attention to a note or important information, please read thou-

rougly.

President and Legal Representative

Cav. del Lavoro

Dante Ferroli



Declaration of conformity

Manufacturer: FERROLI S.p.A.

Address: Via Ritonda 78/a 37047 San Bonifacio VR Italy

declares that this unit complies with the following EU directives:

Gas Appliance Directive 90/396

Efficiency Directive 92/42

Low Voltage Directive 73/23 (amended by 93/68)

Electromagnetic Compatibility Directive 89/336 (amended by 93/68)

IMPORTANT

• Your "benchmark" Installation, Commissioning and Service Record Log Book is enclosed in the

last pages of this manual. “This record must be completed and left with the end user”.

Ferroli is a member of the Benchmark initiative and fully supports the aims of the programme.

Benchmark has been introduced to improve the standards of installation and commissioning of

central heating systems in the UK and to encourage the regular servicing of all central heating

systems to ensure safety and efficiency. Please see installation and servicing guidelines.

For EIRE (Southern Ireland) it is necessary to complete a “Declaration of Conformity” to indicate

compliance to I.S. 813. An example of this is given in the current edition of I.S. 813. In addition it

is necessary to complete the “Benchmark” logbook.

• "Ferroli declare that no substances harmful to health are contained in the appliance or used

during the appliance manufacture”.

Cod. 3540B284 - 05/2007 (Rev. 00)

DOMIcompact F 30 B

1. Operationg instructions ..........................................................................4

1.1 Introduction ............................................................................................................4

1.2 Control panel ..........................................................................................................5

1.3 Turning on and off ..................................................................................................6

1.4 Adjustments ............................................................................................................6

1.5 Maintenance ............................................................................................................8

1.6 Faults .......................................................................................................................8

2. Installation ..............................................................................................9

2.1 General Instructions ................................................................................................9

2.2 Boiler location .......................................................................................................10

2.3 Boiler water connections ......................................................................................12

2.4 Connection to the gas system ..............................................................................14

2.5 Electrical Connections ..........................................................................................14

2.6 Flue system ...........................................................................................................15

2.7 Condensate outlet connection .............................................................................23

3. Service and maintenance ......................................................................25

3.1 Adjustments ..........................................................................................................25

3.2 Initial start-up ........................................................................................................27

3.3 Maintenance ..........................................................................................................28

3.4 Troubleshooting ....................................................................................................30

4 Technical characteristics and data .........................................................31

4.1 Dimensions and connections ................................................................................31

4.2 General view and main components ....................................................................32

4.3 Hydraulic diagram .................................................................................................33

4.4 Technical data table ..............................................................................................34

4.5 Diagrams ...............................................................................................................35

4.6 Time Clock ............................................................................................................36

4.7 Wiring diagram .....................................................................................................37

Benchmark ................................................................................................38


