Sida 1/16

318200919 (0203) Rev. E

ElectricElectric

Electric

Wall Oven

CONTENTS Page

Product Registration ....................................................... 2

Important Safety Instructions .....................................3-4

Before Setting Oven Controls.......................................... 4

Setting Oven Controls ..................................................... 4

Oven Door Bracket Adjustment ....................................... 5

Convection Cooking ........................................................ 5

Convection Roasting ...................................................... 5

Air Circulation in the Oven .............................................. 5

Oven Baking .................................................................... 6

Broiling ............................................................................ 7

Oven Cleaning .............................................................. 8-9

General Cleaning ..................................................... 10-11

Changing Oven Light .................................................... 11

Adjusting Oven Temperature ........................................ 11

Avoid Service Checklist ........................................... 12-13

Notes ....................................................................... 14-15

Warranty ........................................................................ 16

Thank you for choosing this appliance. The information contained within this

Owner's Guide will instruct you on how to properly operate and care for your

appliance. Please read through the information contained in your literature pack to

learn more about your new appliance.

Record Your Model and Serial Numbers

Record in the space provided below the model and serial numbers found on the serial

plate located on the front frame or on the side trim and visible when the oven door

is open.

Model Number: _____________________________________________________

Serial Number: _____________________________________________________

Date Purchased: ____________________________________________________

This Owner's Guide contains general operating instructions for your appliance and

feature information for several models. Your cooktop may not have all the described

features.

Note: The instructions appearing in this Owner's Guide are not meant to cover every

possible condition and situation that may occur. Common sense and caution must be

practiced when installing, operating and maintaining any appliance.

Important: Keep a copy of your bill of sale.

The date on the bill establishes the warranty period service be required. Place it where

it can be easily retrieved. If service is performed while the appliance is under warranty,

you may have to show your bill of sale.

Product Registration

The PRODUCT REGISTRATION CARD

should be filled in completely, signed

and returned to the Electrolux Home

Products North America.

Versión en español

Si desea obtener una copia en español de

este Manual del Usuario, sírvase escribir a

la dirección que se incluye a continuación.

Solicite la P/N 318204008.

Electrolux Home Products

Attn : Care Use

P.O. Box 212378

Augusta, GA 30917

Do not store items of interest to children in the

cabinets above an appliance.

• Do not leave children alone—Children should not be left

alone or unattended in the area where an appliance is in use.

They should never be allowed to sit or stand on any part of the

appliance.

• DO NOT TOUCH INTERIOR OVEN ELEMENTS OR INTERIOR

SURFACES OF THE WALL OVEN UNTIL THEY HAVE COOLED.

The oven heating elements may be hot even though the elements

are dark in color. Areas near the elements may become hot enough

to cause burns. During and after use, do not touch, or let clothing

or other flammable materials touch these areas until they have had

sufficient time to cool. Among these areas are the oven vent

openings, the surfaces near these openings, oven door and

window.

• Wear Proper Apparel—Loose-fitting or hanging garments

should never be worn while using the appliance. Do not let

clothing or other flammable materials contact hot surfaces.

Never use your appliance for warming or

heating the room.

• Do Not Use Water or Flour on Grease Fires—Smother the fire

with a pan lid, or use baking soda, a dry chemical or foam-type

extinguisher.

•When heating fat or grease, watch it closely. Fat or grease may

catch fire if allowed to become too hot.

•Use Only Dry Pot holders—Moist or damp pot holders on hot

surfaces may result in burns from steam. Do not let the pot

holders touch the hot heating elements. Do not use a towel or

other bulky cloth instead of a pot holder.

•Do Not Heat Unopened Food Containers—Build-up of

pressure may cause the container to burst and result in injury.

IMPORTANT INSTRUCTIONS FOR USING YOUR

OVEN

• Use Care When Opening an Oven Door—Stand to the side of

the appliance when opening the door of a hot oven. Let hot air

or steam escape before you remove or replace food in the oven.

• Keep Oven Vent Ducts Unobstructed. The wall oven is vented

at the upper control panel or at the center trim depending of the

model. Touching the surfaces in this area when the wall oven is

operating may cause severe burns. Also, do not place plastic or

heat-sensitive items near the oven vent. These items could melt or

ignite.

•Remove all tape and packaging wrap before using the

appliance. Destroy the carton and plastic bags after

unpacking the appliance. Never allow children to play with

packaging material. Do not remove the wiring label and other

literature attached to the back of the wall oven. Do not remove

model/serial number plate.

•Proper Installation—Be sure your appliance is properly

installed and grounded by a qualified electrician or installer

in accordance with the National Electrical Code ANSI/NFPA

No. 70 (U.S.A.) or CSA C22.1, PART 1 (Canada)—latest

editions and local code requirements. Install only per

installation instructions provided in the literature package for this

appliance.

Ask your dealer to recommend a qualified technician and an

authorized repair service. Know how to disconnect the electrical

power to the appliance at the circuit breaker or fuse box in case of

an emergency.

Electronic controllers can be damaged by cold

temperatures. When you use your appliance for the first time,

or if it has not been used for a long period of time, make sure

that it has been exposed to a temperature above 0°C/32°F for

at least 3 hours before connecting it to the power supply.

•User Servicing—Do not repair or replace any part of the

appliance unless specifically recommended in the manuals.

All other servicing should be done only by a qualified technician

to reduce the risk of personal injury and damage to the appliance.

•Never modify or alter the construction of the appliance by

removing panels, wire covers, or any other part of the

product.

• Remove the oven door from any unused appliance if it is to

be stored or discarded.

Stepping, leaning, sitting or pulling down on the

door of this appliance can result in serious injuries and may also

cause damage to the appliance. Do not allow children to climb or

play around the appliance.

• Storage in or on Appliance—Flammable materials should not

be stored in an oven. This includes paper, plastic and cloth items,

such as cookbooks, plasticware and towels, as well as flammable

liquids. Do not store explosives, such as aerosol cans, in or near

the appliance.

Do not use the oven for storage.

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using this appliance.

Save these instructions for future reference.

This guide contains important safety symbols and instructions. Please pay special attention to these symbols and follow all

instructions given. Here is a brief explanation of the use of these symbols.

This symbol will help alert you to situations that may cause serious bodily harm, death or property damage.

This symbol will help alert you to situations that may cause bodily injury or property damage.
