Sida 1/4
Test adapter SECULOAD-N
for testing the off-load voltage of welding equipment per EN 60974 3-349-709-03
6/12.16
Operating Instructions
GMC-I Messtechnik GmbH 1
1 Standard Equipment
1 test adapter (article number Z745R)
1 measurement cable red, 1 measurement cable black,
2 measurement cables blue,
2 alligator clips blue for contacting the welding electrodes,
1 set of operating instructions German/English
2 Applications
In conjuction with a multimeter or a SECUTEST... test instrument,
the SECULOAD-N test adapter is designed for testing welding
equipment (subsequenly referred to as device under test or DUT)
in accordance with standard EN 60974-4:2007. According to this
standard, the peak values of the off-load voltage may not exceed
the limit values for any possible setting.
Attention! The peak value rectifier of the SECULOAD-N uses rectifier
diode 1N 4007 recommended by the standard. This diode is a
power rectifier diode and, due to its design principle, only suitable
for voltage sources with a low clock rate in the line frequency
range or for voltage sources with conventional transformers.
However, there is welding equipment in the market, which uses
pulsed voltage sources with considerably higher clock rates. The
equipment can produce pulses with high voltage which, in turn,
are not completely captured by the peak value rectifier of the SEC-
ULOAD-N. In these cases, the voltage issued by the SECULOAD-N
may be distinctly below the peak values in the output voltage of
the welding equipment. It is imperative that this fact be taken into
account in evaluating the measured values!
Special case: Welding instruments with an open-circuit voltage of less
than 30 V *
In this case, the
SECULOAD-N
does not provides for
any load control.
Measurements are performed with a load resistance of 5 k. For
such low voltages, load control can be neglected, so that the
measuring result is shown on the display even without pressing
the START key.
* For the purpose of verification, perform a direct voltage measurement of
your welding unit by using a multimeter or a SECUTEST... test instru-
ment (without having the test adapter connected in this case).
Special case: Welding instruments which deactivate open-circuit voltage
In this case, a certain key at the welding instrument must be
pressed consistently in order to prevent deactivation. Please refer
to the operating instructions of the welding instrument or contact
the manufacturer for details on such cases.
Test Sequences and Individual Measurements with the Test Adapter
The following test instruments include test sequences for welding
instruments in accordance with EN 60974-4:
•
SECUTEST S2N+w
•SECUTEST BASE(10)
•SECUTEST PRO (or Feature I01)
•SECUSTAR FM+
➭Only experts who are familiar with welding, cutting
and related processes are allowed to perform these
tests.
➭Persons with basic electrotechnical training are allowed
to perform maintenance work and periodic tests provided that
the welding equipment is not opened.
3 Safety Instructions
This instrument fulfills the requirements of the applicable EU
guidelines and national regulations. We confirm this with the CE
marking. The relevant declaration of conformity can be obtained
from GMC-I Messtechnik GmbH. The test adapter is manufac-
tured and tested in accordance with safety regulations
IEC 61010-1/DIN EN 61010-1/VDE 0411-1.
When used for its intended purpose, the safety of the operator, as
well as that of the instrument, is assured.
Please make sure that the output of the DUT is de-energized for connect-
ing it to or disconnecting it from the test adapter.
Before using the test adapter, the off-load voltage of the welding equip-
ment must be checked. Input voltages at the test adapter of more than
130 V are not permissible and result in the destruction of the test adapter.
In this case, the welding equipment must be repaired prior to testing it
with the test adapter.
In order to protect the internal resistor against overloading
between the red and black socket connectors of the test adapter,
these two socket connectors may not be short-circuited. Wait until the
measured voltage is no longer applied and/or the respective
capacitors are discharged (this is performed automatically during
operation with a SECUTEST... test instrument).
If the test adapter should nevertheless be overloaded once, volt-
age measurements are no longer possible. You are kindly
requested to send the test adapter to GMC-I Service GmbH for
repair in this case.
The test adapter may not be used
• for testing plasma jet welding equipment
• in the event of input voltages of more than 130 V
• in the event of any visible external damage
• if it no longer functions properly
Meaning of Symbols on the Instrument
Warning concerning a source of danger
(attention: observe documentation!)
CAT II Measurement category II device
Continuous, doubled or reinforced insulation
Indicates EC conformity
This device may not be disposed of with the trash. Fur-
ther information regarding the WEEE mark can be
accessed on the Internet at www.gossenme-
trawatt.com by entering the search term ’WEEE’
Carefully read the operating instructions before use, in particular the op-
erating instructions included with the test instrument with which you in-
tend to use the adapter.
Opening of Equipment / Repair
The equipment may be opened only by authorized service per-
sonnel to ensure the safe and correct operation of the equipment
and to keep the warranty valid.
Even original spare parts may be installed only by authorized ser-
vice personnel.
In case the equipment was opened by unauthorized personnel,
no warranty regarding personal safety, measurement accuracy,
conformity with applicable safety measures or any consequential
damage is granted by the manufacturer.
!
2 GMC-I Messtechnik GmbH
4 Connection facilities
Connection of SECUTEST S2N+w / SECUTEST S2N+(10)
➭Connect the welding current outputs with the input sockets of
the test adapter (blue sockets).
➭Connect the test instrument (via test sockets 2 and 3) with the
output sockets (+ and –) of the test adapter.
Connection of SECUTEST S2N+w / SECUTEST S2N+(10)
➭Connect the welding current outputs with the input sockets of
the test adapter (blue sockets).
➭Connect the test instrument (via test sockets 2 and 3) with the
welding current outputs.
Multimeter Connection for Report Generation, for Example, with SECUSTAR FM+
➭Connect the welding current outputs with the input sockets of
the test adapter (blue sockets).
➭Measurement of US: Connect a multimeter (e.g. METRAHIT X-TRA)
with the output sockets (+ and –) of the test adapter.
Multimeter Connection for Report Generation, for Example, with SECUSTAR FM+
➭Connect the welding current outputs with the input sockets of
the test adapter (blue sockets).
➭Measurement of UR: Connect a multimeter (e.g. METRAHIT X-TRA)
with the welding current outputs.
Connection of SECUTEST PRO (for Test Sequence)
➭Connect the welding current outputs with the input sockets of
the test adapter (blue sockets).
➭Measurement of US with SECUTEST PRO: Connect the test instru-
ment (via the test sockets COM and V) with the output sock-
ets (+ and –) of the test adapter.
➭Measurement of UR with SECUTEST PRO: Connect the test instru-
ment (via the test sockets COM and V) with the welding cur-
rent outputs.
3
2
SECULOAD
blue
+ red
– black
Welding Equipment
Measurement of US
(Peak Value)
3
2
SECULOAD
blue
+ red
– black
Welding Equipment
Measurement of UR
(RMS Value)
V DC
SECULOAD + red
blue
– black
V
Welding Equipment
Measurement of US
(Peak Value)
V DC
SECULOAD + red
blue
– black
V
Welding Equipment
Measurement of UR
(RMS Value)
SECULOAD
blue
+ red
COM
SECUTEST PRO
Welding Equipment
black –
V
SECULOAD
blue
+ red
COM
SECUTEST PRO
Welding Equipment
black
–
V
Measurement of US
Measurement of UR
(Peak Value)
(RMS Value)
GMC-I Messtechnik GmbH 3
Connection of SECUTEST BASE(10) (for Test Sequence)
➭Connect the welding current outputs with the input sockets of
the test adapter (blue sockets).
➭Measurement of US with SECUTEST BASE(10): Connect the black
output socket (–) of the test adapter directly with the mains
PE. Connect test probe P1 of the test instrument directly with
the red socket (+) of the test adapter voltage output.
➭Measurement of UR with SECUTEST BASE(10): Connect one weld-
ing current output directly with the mains PE. Connect test
probe P1 of the test instrument directly with the second weld-
ing current output.
5 Individual Measurements
Preparations for Individual Measurements
➭Read the operating instructions for your test instrument and
familiarize yourself with the voltage test function of your test
instrument.
•SECUTEST S2N+(10) or SECUTEST S2N+w:
Voltage measurement is performed in switch position Menu
under parameter UAC/DC, as described in chapter „Individual
Measurements“, sub-section „Alternating /Direct Voltage“ of
the operating instructions for the test instrument.
•
SECUSTAR FM+:
There is no connection provided for the test adapter.
Voltage is measured with a multimeter.
When using a multime-
ter, activate its min/max value memory.
•SECUTEST PRO (or Feature I01):
Connection is established via the input sockets COM and V, in
the same way as connecting a multimeter. Voltage measure-
ment is performed in switch position U.
Performing Individual Measurements
➭Switch the DUT on and wait for approx. 5 seconds.
➭
Press and hold the
START
key at the test adapter. After about 1 to
2 seconds a rising test current is present and
LED
lights up.
➭As soon as the maximum current is reached and the Stop LED
lights up, release the START key at the test adapter.
➭
Read out the maximum voltage value saved to the respective
measuring or test instrument and check whether it is below the
maximum value specified for the respective welding equipment.
In the SECUTEST S2N+(10) or SECUTEST S2N+w test instrument,
the min/max values can be displayed with key as from firm-
ware version 7.1.
➭Separate the DUT from the voltage source.
Attention!
!
When the Temp. LED lights up, the test adapter must be
disconnected from the DUT. Allow the test adapter to
cool down for 10 to 20 minutes before using it again.
Note
Always disconnect the test adapter from the DUT
when it is not required in order to avoid unnecessary self-
heating.
6 Characteristic Values
Operating voltage 30 V ... 130 V (RMS) AC / DC
Output voltage max. 200 V DC
Current consumption
Standby: 5 ... 45 mA, Load current max. 650 mA
Input resistance 200 ... 5.4 k
Output resistance 10 k
Measuring category CAT II 300 V
Voltage supply
from DUT
Dimensions, Weight
W x H x D: 13 x 6.7 x 4.5 cm, approx. 200 g
Protection Housing: IP40, terminals IP20
Interference emission EN 61326-1:2013 class B
Interference immunity EN 61326-1:2013
7 Device Return and Environmentally Compatible Disposal
The instrument is a category 9 product (monitoring and control
instrument) in accordance with ElektroG (German Electrical and
Electronic Device Law). This device is subject to the RoHS direc-
tive. Furthermore, we make reference to the fact that the current
status in this regard can be accessed on the Internet at
www.gossenmetrawatt.com by entering the search term WEEE.
We identify our electrical and electronic devices in accor-
dance with WEEE 2012/19/EU and ElektroG with the
symbol shown to the right per DIN EN 50419.
These devices may not be disposed of with the trash. Please con-
tact our service department regarding the return of old devices.
SECULOAD
blue
+ red
SECUTEST BASE(10)
Welding Equipment
black –
SECULOAD
blue
+ red
SECUTEST BASE(10)
Welding Equipment
black
–
Measurement of US
Measurement of UR
(Peak Value)
(RMS Value)
P1
P1
PE Mains
PE Mains
Produktspecifikationer
| Varumärke: | Gossen Metrawatt |
| Kategori: | Mätutrustning |
| Modell: | SECULOAD-N |
Behöver du hjälp?
Om du behöver hjälp med Gossen Metrawatt SECULOAD-N ställ en fråga nedan och andra användare kommer att svara dig
Mätutrustning Gossen Metrawatt Manualer
26 September 2024
25 September 2024
24 September 2024
23 September 2024
22 September 2024
22 September 2024
21 September 2024
21 September 2024
21 September 2024
21 September 2024
Mätutrustning Manualer
- Mätutrustning Bosch
- Mätutrustning Panasonic
- Mätutrustning DeWalt
- Mätutrustning Fysic
- Mätutrustning Honeywell
- Mätutrustning Pioneer
- Mätutrustning Albrecht
- Mätutrustning Alecto
- Mätutrustning Amprobe
- Mätutrustning Yato
- Mätutrustning Lanaform
- Mätutrustning Megasat
- Mätutrustning Meec Tools
- Mätutrustning Milwaukee
- Mätutrustning Extech
- Mätutrustning Victron Energy
- Mätutrustning Hazet
- Mätutrustning Metrix
- Mätutrustning Benning
- Mätutrustning Einhell
- Mätutrustning Voltcraft
- Mätutrustning Midland
- Mätutrustning Mitsubishi
- Mätutrustning Velleman
- Mätutrustning Vemer
- Mätutrustning Perel
- Mätutrustning Kyoritsu
- Mätutrustning IFM
- Mätutrustning Ideal
- Mätutrustning Flir
- Mätutrustning Grohe
- Mätutrustning Technoline
- Mätutrustning Soler And Palau
- Mätutrustning Continental Edison
- Mätutrustning Rossmax
- Mätutrustning Carrier
- Mätutrustning Testboy
- Mätutrustning Goclever
- Mätutrustning Trotec
- Mätutrustning LaCie
- Mätutrustning Danfoss
- Mätutrustning Hager
- Mätutrustning Bresser
- Mätutrustning TFA
- Mätutrustning Owon
- Mätutrustning Flex
- Mätutrustning Fluke
- Mätutrustning Fantini Cosmi
- Mätutrustning Eltako
- Mätutrustning EBERLE
- Mätutrustning Basetech
- Mätutrustning Stabila
- Mätutrustning Be Cool
- Mätutrustning Laserliner
- Mätutrustning Wentronic
- Mätutrustning REV
- Mätutrustning Testo
- Mätutrustning Clean Air Optima
- Mätutrustning Eastron
- Mätutrustning ORNO
- Mätutrustning RIDGID
- Mätutrustning Westfalia
- Mätutrustning Monacor
- Mätutrustning Multimetrix
- Mätutrustning GW Instek
- Mätutrustning Logilink
- Mätutrustning SIIG
- Mätutrustning Oregon Scientific
- Mätutrustning Etymotic
- Mätutrustning Reely
- Mätutrustning Muller
- Mätutrustning TFA Dostmann
- Mätutrustning Werma
- Mätutrustning Greisinger
- Mätutrustning Beha-Amprobe
- Mätutrustning Kopp
- Mätutrustning Kern
- Mätutrustning Kogan
- Mätutrustning Kreg
- Mätutrustning Pancontrol
- Mätutrustning Peak
- Mätutrustning Uni-T
- Mätutrustning H-Tronic
- Mätutrustning Elgato
- Mätutrustning Hikmicro
- Mätutrustning PeakTech
- Mätutrustning Sonel
- Mätutrustning Tru Components
- Mätutrustning Emko
- Mätutrustning Aktobis
- Mätutrustning Entes
- Mätutrustning KS Tools
- Mätutrustning Lund
- Mätutrustning Trumeter
- Mätutrustning Delta Ohm
- Mätutrustning Hanna
- Mätutrustning MGL Avionics
- Mätutrustning Adwa
- Mätutrustning Chauvin Arnoux
- Mätutrustning Megger
- Mätutrustning AREXX
- Mätutrustning PCE Instruments
- Mätutrustning CEM
- Mätutrustning SHX
- Mätutrustning Hameg
- Mätutrustning TDE Instruments
- Mätutrustning Joy-it
- Mätutrustning Circutor
- Mätutrustning Wachendorff
- Mätutrustning Klein Tools
- Mätutrustning Duro Pro
- Mätutrustning GMW
- Mätutrustning Janitza
- Mätutrustning Sanwa
- Mätutrustning J.P. Instruments
- Mätutrustning MSW
- Mätutrustning Weidmüller
- Mätutrustning Qubino
- Mätutrustning Lascar Electronics
- Mätutrustning HT Instruments
- Mätutrustning P3 International
- Mätutrustning Beckmann & Egle
- Mätutrustning Seek Thermal
- Mätutrustning INFICON
- Mätutrustning Motrona
- Mätutrustning Tempo
- Mätutrustning Camille Bauer
- Mätutrustning Blebox
- Mätutrustning Seaward
- Mätutrustning HOZO Design
- Mätutrustning Corentium
- Mätutrustning GQ
- Mätutrustning Tektronix
- Mätutrustning Dostmann Electronic
- Mätutrustning Murideo
- Mätutrustning SecuTech
- Mätutrustning NetPeppers
- Mätutrustning SensoProtect
- Mätutrustning Water-i.d.
- Mätutrustning ZKETECH
- Mätutrustning LabNation
- Mätutrustning Electronics International
- Mätutrustning Cliff
- Mätutrustning ClimeMET
- Mätutrustning Fixpoint
- Mätutrustning Kübler
- Mätutrustning AkYtec
- Mätutrustning Stahlwille
- Mätutrustning MASIMO
- Mätutrustning Milesight
- Mätutrustning Enda
- Mätutrustning CSL
- Mätutrustning Ermenrich
- Mätutrustning PICO
- Mätutrustning Siglent
- Mätutrustning Noyafa
- Mätutrustning Stamos
Nyaste Mätutrustning Manualer
26 Oktober 2024
25 Oktober 2024
25 Oktober 2024
24 Oktober 2024
23 Oktober 2024
23 Oktober 2024
23 Oktober 2024
23 Oktober 2024
23 Oktober 2024
23 Oktober 2024
