Off Grid Solar Inverter
SPF 3500 ES
SPF 5000 ES
Version: 4.0
User Manual
Table Of Contents
Information on this Manual 1...................................................................................................................................................
Validity ...................................................................................................................................................... 1
Scope ......................................................................................................................................................... 1
Target Group ............................................................................................................................................. 1
Safety Instructions 1...................................................................................................................................
Introduction ........................................................................................................................................................................... 2
Features .................................................................................................................................................... 2
Product Overview ...................................................................................................................................... 3
Installation ............................................................................................................................................................................. 4
Unpacking and Inspection ........................................................................................................................ 4
Preparation 4...............................................................................................................................................
Mounting the Unit ..................................................................................................................................... 4
Battery Connection ................................................................................................................................... 5
Lead-acid Battery Connection ................................................................................................................................. 5
Lithium Battery Connection ..................................................................................................................................... 6
A Input/Output Connection C .................................................................................................................... 9
PV Connection ......................................................................................................................................... 10
Communication Connection .................................................................................................................... 11
Dry Contact Signal .................................................................................................................................. 11
Operation ............................................................................................................................................................................ 12
Power ON/OFF ........................................................................................................................................ 12
Operation and Display Panel ................................................................................................................... 12
LCD Display Icons .................................................................................................................................................... 13
LCD Setting ............................................................................................................................................................... 15
Display Information ................................................................................................................................ 20
Operating Mode Description ................................................................................................................... 21
Parallel Installation Guide ................................................................................................................................................... 22
Introduction ............................................................................................................................................ 22
Parallel Board Installation ...................................................................................................................... 22
Parallel Operation in Single Phase .......................................................................................................... 25
Parallel Operation in Three Phase ...........................................................................................................28
PV Connection ......................................................................................................................................... 31
LCD Setting and Display .......................................................................................................................... 31
Fault Reference Code ......................................................................................................................................................... 33
Warning Indicator ................................................................................................................................................................ 34
Battery Equalization ............................................................................................................................................................ 35
Specications ...................................................................................................................................................................... 36
Trouble Shooting . ................................................................................................................................................................ 39
1
Information on this Manual
Validity
This manual is valid for the following devices:
SPF 3500 ES
SPF 5000 ES
Scope
This manual describes the assembly, installation, operation and troubleshooting of this unit. Please read
this manual carefully before installations and operations.
Target Group
This document is intended for qualified persons and end users. Tasks that do not require any particular
qualification can also be performed by end users. Qualified persons must have the following skills:
Knowledge of how an inverter works and is operated
Training in how to deal with the dangers and risks associated with installing and using electrical
devices and installations
Training in the installation and commissioning of electrical devices and installations
Knowledge of the applicable standards and directives
Knowledge of and compliance with this document and all safety information
Safety Instructions
WARNING: This chapter contains important safety and operating instructions.
Read and keep this manual for future reference.
1.
Please be clear which kind of battery system you want, lithium battery system or lead-acid battery system, if
you choose the wrong system, energy storage system . can’t work normally
2.
Before using the unit, read all instructions and cautionary marking on the unit, the batteries and all
appropriate sections of this manual. The company has the right not to quality assurance, if not according to
the instructions of this manual for installation and cause equipment damage.
3.
All the operation and connection please professional electrical or mechanical engineer.
4.
All the electrical installation must comply with the local electrical safety standards.
5.
When install PV modules in the daytime, installer should cover the PV modules by opaque materials,
otherwise it will be dangerous as high terminal voltage of modules in the sunshine.
6.
CAUTION-To reduce risk of injury, charge only deep-cycle lead-acid type rechargeable batteries and
lithium batteries. Other types of batteries may burst, causing personal injury and damage.
7.
Do not disassemble the unit. Take it to a qualified service center when service or repair is required.
Incorrect re-assembly may result in a risk of electric shock or fire.
8.
To reduce risk of electric shock, disconnect all wirings before attempting any maintenance or cleaning.
Turning off the unit will not reduce this risk.
9.
NEVER charge a frozen battery.
10.
For optimum operation of this inverter, please follow required spec to select appropriate cable size. It s very ’
important to correctly operate this inverter.
11.
Be very cautious when working with metal tools on or around batteries. A potential risk exists to drop a tool
to spark or short circuit batteries or other electrical parts and could cause an explosion.
12.
Please strictly follow installation procedure when you want to disconnect AC or DC terminals. Please refer to
INSTALLATION section of this manual for the details.
13.
GROUNDING INSTRUCTIONS -This inverter should be connected to a permanent grounded wiring system.
Be sure to comply with local requirements and regulation to install this inverter.
14.
NEVER cause AC output and DC input short circuited. Do NOT connect to the mains when DC input short
circuits.
15.
Make sure the inverter is completely assembled, before the operation.
