Wuhan Guide Sensmart Tech Co., Ltd. +86 27 8129 8784www.guideir.com enquiry@guide infrared.com-
The Ideal Nighttime
Hunting Partner
DU Series Digital Day Vision& Night Scope
oHighly Sensitive 1920x1080 Sensor for image acquisition
oFull HD AMOLED Display for image detail
oDay, Low-light and Night modes
o15 hours super long battery life
oMounting on standard 30 mm rings
o10 distinct reticles with 6 color schemes and 10 levels of
brightness
oCompact and lightweight
oEncapsulation IP67
Features
Introduction
DU Day CMOSSeries performanceis higha - Digital & . - xNight Vision Scope designed professional huntingfor The high sensitivity 1920 1080 Sensor
that quality Theoffers outstanding image . full- xcolor HD 1920 1080 AMOLED display the image withguarantees smallest detail meticulous care to
respect users' advanced dual batterywishes The. system provides up hours non use fromto 15 of -stop day to night.
Applications
oNight Hunting
oLaw Enforcement
oSearch & Rescue
oPersonal security
* Product performance is based on testing in a controlled environment. All specifications are subject to the actual product. Guide sensmart reserves the right to change the technical specifications without notice or liability to you.
Product model DU50
Sensor
Type CMOS
Resolution 1920×1080@m
Frame rate 50 Hz
Lens
Objective lens 50mm, F1.2
Field of view 9°×5.2°
FOV m @100m 16×9
Magnification 3.125x~25x
Detection range 600m/ 650yd (850nm); 550m/ 600yd (940nm)
Display
Display type 0.39'' AMOLED 1920x1080
Scene modes Day, Night, Low-light
Eyepiece Exit pupil distance 48 mm; Diopter ±4; Zoom: 14x
Hardware
IR illuminator 850nm/ 940nm (Alternative)
WIFI 2.4G
Interface USB Type-C
Tube diameter Standard 30 mm
System
Recording function Photo/Video
Memory capacity 32 GB
Power
Battery type Single 18650 battery (built-in) and customized battery (external)
Operating time 15 hours
Environmental
Operating temp. -30 °C to 50 °C/ -22°F to +122°F
Shock 800G/1ms semi- IEC60068-2-27sinosoidal
Encapsulation IP67
Physical
Weight(g/ oz) 980/ 34.57
Size(mm/ in) 371×
107×68/ 14.60×4.21×2.68
Standard
Device, Lens cover, Eye mask, 5V2A adapter (US, Britain, Australia and Europe), Customized battery
×2,
Customized battery charger, USB Type-C cable, Micro HDMI cable, Clip
×2, IR illuminator, IR illuminator bracket,
Quick start guide, Warranty card
Optional Customized battery, Laser rangefinder, Bluetooth controller, Dovetail rail
