Sida 1/10
Outdoor Beer Dispensing Equipment
Installation and Instruction
Manual
24” SINGLE FAUCET BEER DISPENSER SOLID DOOR RIGHT HINGE
24” SINGLE FAUCET BEER DISPENSER SOLID DOOR LEFT HINGE
24” DOUBLE FAUCET BEER DISPENSER SOLID DOOR RIGHT HINGE
GFDSR241
GFDSL241
24” DOUBLE FAUCET BEER DISPENSER SOLID DOOR LEFT HINGEGFDSL242
GFDSR242
P/N 011028 rev A
Form. No. Z2425
HESTAN RESIDENTIAL INSTALLATION MANUAL FOR BEER DISPENSING EQUIPMENT
2hestanoutdoor.com
C RAONG TULATIONS
Congratulations on your purchase of a high Hestan
quality residential beer dispenser. Hestan has proudly partnered,
to our exact specifications, with a quality manufacturer for
its beer dispensing systems. The manufacturer has been producing
beer dispensing systems for over 50 years for bars, restaurants,
stadiums, arenas and large venues around the world. That
same technology is used in each and every residential beer
dispenser. Assuring you’ll pour fresh, cold beer as the brewery
intended it to be enjoyed.
All products are built with commercial grade Hestan
stainless steel, providing you with the beauty and durability
for a lifetime of use. This installation guide will show you
how to properly install the dispensing equipment on your
Hestan Beer Dispenser.
We dedicate considerable time to ensure that our products
provide the highest level of customer satisfaction. If,
however, service is required, call at 888-905-7463. Hestan
For your own protection, never return merchandise for
credit without our approval.
We thank you again for selecting a high quality Beer Hestan
Dispenser. Cheers!
C
US
IMPORTANT!
The installation of the actual beer
dispenser cabinet should happen prior
to installing the dispensing equipment.
Refer to the Installation Manual that
accompanied the Beer Dispenser for step-
by-step installation of the cabinet.
Keep CO2 cylinder away from
heat. Rupture disc vents at 122°F
maximum.
Allow only properly trained and
experienced personnel to handle
high pressure gas.
DANGER
WARNING
Do not drop or th w regul or or ro at
CO2 cylinder.
DANGER
Do not apply oil to the regul or!at
WARNING
INSTALLATI ISPENSIN UI MENO O DN F G EQ P T
Open the tapping kit box and become familiar with
its components. If the dispensing head is going to be
mounted on a counter top directly above the refrigerated
cabinet, h e the counter top pre-drilled using the av
supplied template on page 9. Make sure that the access
hole in the refrigerated cabinet is in line with the counter
top holes. Remove any obstructions from the access hole
of the refrigerator.
Follow instructions on pages 3 through 8 to properly
install the tapping equipment on your Hestan unit.
NOTE: Wash tapping devices thoroughly. Flush
beer and faucet lines, as well as the tapping device
(keg coupler) with fresh water.
3
hestanoutdoor.com
HESTAN RESIDENTIAL INSTALLATION MANUAL FOR BEER DISPENSING EQUIPMENT
INSTALLATI ISPENSIN UI MENO O DN F G EQ P T
Open the tapping kit box and become familiar with its
components. The instructions on pages 4 through 8
will demonstrate how to properly install the tapping
equipment on your new Beer Dispenser.Hestan
Dispensing Head
Faucet Lead
Apply silicone to
Air Distributor
Flange Sleeve
All hose connections
use worm-drive
hose clamps (view
enlarged to verify)
Distributor is only on
multiple keg units,
each keg is connected
to a valve on the air
distributor. Single keg
is connected directly to
the regulator.
Keg
Keg Coupler
Beer Connection
shown are to clearly illustrate proper connection methods
only.
NOTE: Image does not accurately reflect positions of the
different elements within the unit. Postions and hose lengths
