FREEZER - MODELS
RZA36G.1-RZA36P.1
INSTRUCTIONS FOR INSTALLATION & USE
GETTING STARTED:
To ensure that your freezer runs reliably and efficiently follow these steps.
Choose a location for your
freezer, away from any
heat sources and
allow adequate
ventilation - 30mm
(11/4inch) gap above.
Level the freezer by
adjusting the front feet.
This will stop rocking or
vibration and keep the
door aligned.
Plug in and switch on.
Allow the freezer to cool
before placing food
inside.
The high temperature
light will stay on until the
freezer has cooled down.
All food in the freezer
should be covered.
Move the freezer into
position, using the sides
of the cabinet. Take care
to avoid damaging the
refrigerant circuit pipe
work on the rear.
Before plugging in and
switching on, leave the
freezer in its final
location for at least 15
minutes to allow it to
settle.
Read the rest of these instructions to get the best from your appliance
and remember to fill in your guarantee registration.
Keep this Book in a safe place for quick reference.
STEP 1 STEP 2
STEP 3 STEP 4
STEP 5
SAFETY &
INSTALLATION CONTROLS USEFUL ADVICE
CLEANING &
MAINTENANCE
TROUBLESHOOTING
SERVICE &
GUARANTEE
Your freezer is now
working.
If after 24 hours your
freezer is not operating as
you want, refer to the
TROUBLESHOOTING
section.
STEP 6
For Your Safety
For your safety, read the following advice:
The freezer cooling system contains a small amount of gas which is environmentally
friendly but flammable. To avoid any risk :-
●Install the freezer following the installation instructions and ensure that
ventilation openings are kept clear of obstruction.
●Take care when installing or moving the freezer to avoid damaging the pipes
on the rear.
●If you suspect a leak, do not switch on the freezer, but open the windows and
doors to ventilate the room.
●Do not use any electrical devices inside the freezer, for instance for
defrosting.
●Do not use any mechanical devices for defrosting other than any which may
have been supplied with the freezer as they may cause damage.
●Only use this freezer for storing domestic foodstuffs.
When installing your freezer :-
●Ensure that the mains cable is not trapped underneath or behind the freezer
when you install or move it.
●Do not stack any other appliance on top of this freezer as they may
damage the freezer or become unstable.
When using your freezer :-
●Do not sit or stand on top of your freezer.
●Do not store poisonous, flammable or dangerous substances in your freezer.
●Do not use aerosol sprays for defrosting or cleaning your freezer.
If you sell the freezer, pass on this booklet to the new owner.
2
SAFETY &
INSTALLATION
PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR 5 YEAR PARTS GUARANTEE ON 08448 24 24 24
Installation
Location & Air Circulation
Locate your freezer away from sources of heat e.g.
Cookers, Radiators, Direct Sunlight as extreme
temperature will affect its performance.
Allow a minimum 30mm (11/4inch) between the top of
the freezer and the underside of the worktop.
Providing you follow the recommended ventilation requirements you will :-
●Prolong the life of the freezer.
●Minimise the risk of condensation on the outside of the freezer.
●Minimise the running costs.
●Minimise operating sounds caused by vibration.
3
Minimum space required to open door
The freezer needs a space of 600mm (24 inches) in front to allow the door to
open.
When positioning the freezer next to a unit, a gap of 30mm (1 1/4inch) can be left
at the hinge side of the door to allow the easy removal of furniture. If preferred
the freezer can be positioned so that a gap is not left. This will restrict how far the
door can be opened but the furniture can still be removed (see diagram below).
The door hinge side can be changed to make it easier to open (see ‘Door Reversal’
in the CLEANING & MAINTENANCE section).
SAFETY &
INSTALLATION
TOP VIEW TOP VIEW
less than 30mm
30mm or more
600mm
600mm
30mm (11/4inch)
