Ibiza Sound MX802 Bruksanvisning
Ibiza Sound
Mixerkonsol
MX802
Läs nedan 📖 manual på svenska för Ibiza Sound MX802 (56 sidor) i kategorin Mixerkonsol. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/56
1
M
MI
IX
XI
IN
NG
G
C
CO
ON
NS
SO
OL
LE
E
MX802 - 3) (15 239
8-CHANNEL MIXER
INSTRUCTION MANUAL
MANUEL D’UTILISATION
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUÇÕES
MANUAL DE INSTRUCCIONES
NAVODILA ZA UPORABO
2
IMPORTANT SAFETY INSTRUCTIONS
1) Read the manual prior to using this unit and keep it for future reference.
2) Adhere to all warnings and instructions marked on the unit and . contained in the manual
3) Don’t place the unit close to water, e.g. in a bathroom, near a wash tub, a swimming pool, etc.
4) T he unit must match carriage and rack recommended by the manufacturer.
Sudden stops, great power and rough surface may cause combination turns over.
5) Keep away from heat sources such as radiator, stove and amplifier etc.
6) Operate the unit only with the rated power supply. Please ask your dealer or local power supply
company if you are not about your sure type of power supply .If the unit is operated with batteries or
other power supplies, please refer to this booklet.
7) Connection to ground or polarization: If t he unit is fitted with a polarized AC plug, there is only one
method . to insert the plug This is a safety characteristic.
8) Do not walk on or squeeze the power cord.
9) Clean this unit with a soft cloth. Prevent water and/or other liquids to enter into the housing.
10) Unplug the power cord if the unit is not used for a long time or during a thunderstorm to prevent
voltage surges to damage the inner circuitry.
11) Prevent objects s and liquid to enter into unit.
12) If one of the following happens, refer to qualified service personnel:
A) Power cord or plug a damaged; or
B) An object or liquid has entered into the unit; or
C) The unit has been exposed to rain ; or
D) do The unit esn’ t work; or
E) The unit has fallen or doesn’t work normally.
13) Repair ---Do not attempt to repair the unit yourself. All repairs must be carried out by a qualified
technician. The user is only allowed to perform manipulations, settings and controls specified in this
manual.
14) Ventilation --- Do not cover the ventilation openings to prevent overheating of the unit. Do not place
the unit on bed, blanket, sofa or similar soft surface. Do not place unit inside a bookcase, a closed
cupboard, etc.
15) Accessories---Not use parts that hare not recommended by the manufacturer in order to avoid
damage.
16) Auxiliary equipment ---Do not place this unit on unstable vehicle, shelf, tripod or table. It will cause
serious harm to child or adult if the unit falls down use the vehicle, shelf, tripod or table. Please
recommended by the manufacturer.
17) Spare parts---If the unit requires tsspare par , use only spares recommended by the manufacturer and
that are in all aspects identical to the original parts. .
18) Safety check---After repairing, repairer must test the unit for security.
GB
3
CHANNEL CONTROL SECTION:
① MIC input jack
Balanced XLR microphone input jacks (1: ground; 2: hot; 3: cold)
② LINE input jacks
Balanced TRS phone jacks (T: hot; R: cold; S: Ground)
You can connect either balanced or unbalanced Jack plugs to this
socket.
③ GAIN control
Adjustment of the input signal level. To get the best balance between
the S/N ratio and the dynamic range, adjust the input signal level so
that the PEAK indicator (10) comes on just as the signal approaches its
maximum level.
④ Equalizer (HIGH, MID & LOW)
This 3-band EQ adjusts the channel’s high, mid and low frequency
bands. The stereo channel has a 2 frequency band: HIGH & LOW. -
Setting the knob to the “▼” position produces a flat frequency
response in the corresponding band. Turning the knob to the right
boosts the corresponding frequency band, while turning to the left
attenuates the band. The following table shows the EQ type, frequency
and maximum cut/boost for each of the three bands.
⑤ AUX Control
These knobs adjust the channel’s signal levels into AUX BUSES.
⑥ EFFECT Control
Adjusts the level of the signal sent from the channel to the EFFECT bus.
Note that the signal level sent to the bus is also affected by the
channel fader.
⑦ controlPAN
The PAN control determines the stereo positioning of the channel
signal on the STEREO L & R buses.
⑧ MUTE Switch
When depressed, this switch mutes the signal of the channel to all outputs.
⑨ MUTE Indicator
Press MUTE switch and the indicator lights up in red.
⑩ PEAK indicator
The peak level of the post –EQ signal is detected and the PEAK indicator light yellow when the level
reaches 3dB below clipping.
⑪ PFL switch
Depress this switch to feed to the channels pre-channel fader signal into the PFL bus, so that you can
monitor the signal from the PHONES jack. To turn PFL feed on, press the switch in so that it lights up.
Band
Type
Frequency
Max. Cut/Boost
HIGH
Shelving
12kHz
± 15dB
MID
Peaking
2.5kHz
LOW
Shelving
80Hz
