MR-1010R™
MARINE RADAR
INSTRUCTION MANUAL
i
SUPPLIED ACCESSORIES
SYSTEM COMPONENTS
MODEL NAME DISPLAY UNIT SCANNER UNIT
MR-1010RII 10.4-inch Color LCD EX-2714 (Radome type)
zScanner unit (EX-2714)
Quantity
1. System cable (15 m) ........................................... 1
2. Installation bolts (M10×50) 4 .................................
3. Installation bolts (M10×25) 4 .................................
4. Installation nuts (M10) 4 ........................................
5. Flat washers (M10) 4 .............................................
6. Spring washers (M10) 4 ........................................
z10.4-inch Color LCD display unit
Quantity
1. NMEA connector (PLT-167-P-R) 1 ........................
2. NMEA connector (PLT-168-P-R) 1 .........................
3. Spare fuse (FGB 15 A) 1 .......................................
4. Spare fuse
(FGB 5 A: for over 24 V power supply)
.. 1
5. DC power cable 1 ..................................................
6. 1Mounting bracket ................................................
7. Mounting knob bolts 2 ...........................................
8. Installation bolts (M6×30) 5 ...................................
9. Installation nuts (M6) 5 ..........................................
10. 10Spring washers (M6) ........................................
11. Flat washers (M6) ............................................. 10
12. Instruction manual .............................................. 1
13. EX-2714 template ................................................ 1
14. Display unit template ........................................... 1
ii
Thank you for choosing this Icom product. The
MR-1010RII is designed and built with marine radar
Icom's state of the art technology and craftsmanship.
With proper care, this product should provide you
with years of trouble-free operation.
IMPORTANT
READ ALL INSTRUCTIONS carefully and
completely before using the radar.
SAVE THIS INSTRUCTION MANUAL—
This manual contains important safety and operating
instructions for the MR-1010RII.
FEATURES
The radar is "Made in Japan." It has powerful
transmitting power for long range detection, a
10.4-inch wider view angle color display, simplied
ARPA to detect up to 5 targets, and other advanced
features.
EXPLICIT DEFINITIONS
WORD DEFINITION
R DANGER! Personal death, serious injury or an
explosion may occur.
R WARNING! Personal injury, re hazard, or
electric shock may occur.
CAUTION Equipment damage may occur.
NOTE
Recommended for optimum use. No
risk of personal injury, re or electric
shock.
Icom, Icom Inc. and the Icom logo are registered
trademarks of Icom Incorporated (Japan) in Japan,
the United States, the United Kingdom, Germany,
France, Spain, Russia, Australia, New Zealand, and/
or other countries.
BE CAREFUL!
SART signals may not be detected and
displayed on the screen, depending on the
SEA, RAIN or IR settings.
Make the settings below to detect the
SART signals on the screen.
1. Set the screen range to between 6 NM
and 12 NM with [+/–]. (pp. 1, 7)
2. Set the [GAIN] as high as possible.
(pp. 2, 9)
3. Set [SEA] to minimum. (pp. 2, 9)
4. Set [RAIN] to minimum. (pp. 2, 9)
5. Turn OFF the Interference rejection (IR)
function. (p. 10)
6. Turn OFF the Echo Stretch function. (p. 11)
The MR-1010RII is a supplemental aid to navigation and is not intended to be a substitute for
accurate and current nautical charts.
Icom is not responsible for the destruction, damage
to, or performance of any Icom or non-Icom
equipment, if the malfunction is because of:
• Force majeure, including, but not limited to, res,
earthquakes, storms, oods, lightning, other
natural disasters, disturbances, riots, war, or
radioactive contamination.
• The use of Icom marine radar with any equipment
that is not manufactured or approved by Icom.
