RaidSonic Technology GmbH · Kurt-Fischer-Straße 50 · 22926 Ahrensburg · Germany

Phone +49 4102 468-900 · info@raidsonic.deE-Mail www.icybox.de/en/

Visit us:

IB-DK2252AC

DisplayLink® Notebook DockingStation

with dual video output

Order Number

60797

EAN Code

4250078171331

Notebooks are much more practical than desktop PCs because of their portability - you can’t lug a desktop PC around between your home

and office. However, the limitation of the notebook is the screen size and often a lack of ports. Some notebooks come standard with only one

or two ports, one of which you need for charging. Many people prefer a mouse to the notebook’s trackpad or even a full-size keyboard. The

perfect setup would be a notebook for flexibility on the one hand and more ports on the other. The solution is an ICY BOX

DockingStation that

includes all these ports and to which you can connect your notebook with only one cable.

DisplayLink®

Driver installation required

before first use

www.displaylink.com / downloads

USB interfaces

6x USB 3.0 Type-A

with up to 5 Gbit / s

Multiple Display

LAN Port

RJ 45

Gigabit Ehernet

Supports 2x 4K@60 Hz

Host

Supports

USB Type-A,

USB Type-C®

Headset

3.5 mm combo jack

Plug and Display ™

RaidSonic Technology GmbH · Kurt-Fischer-Straße 50 · 22926 Ahrensburg · Germany

Phone +49 4102 468-900 · info@raidsonic.deE-Mail www.icybox.de/en/

Visit us:

FRONT VIE W VIEWRE AR

2x USB 3.0 Type-A (5 Gbit

4x USB 3.0 Type A (5 Gbit

Gigabit Ethernet

HDMI® 1 or DisplayPort™ 1

(DisplayLink®)

HDMI® 2 or DisplayPort™ 2

(DisplayLink®)

USB Type-B (Host)

Power supply interface

LED for power

Headset jack

SPECIAL FEATURES

The more, the better! Convective heat dissipation With one foot ﬁrmly on the ground

A DockingStation with a variety of

connections is a real added value

for a notebook that, after using the

charging port, may only have one

more port left for further applications.

With the IB-DK2252AC you can, for

example, connect a mouse, a full-si-

ze keyboard, you can connect one

or more larger external displays, con-

nect external hard drives or a printer

via USB ports and also enjoy stable

internet via the Ethernet port.

This DockingStation model is de-

signed for vertical positioning with

the help of a stand. Both enclosure

surfaces have ventilation slots that

allow convective heat dissipation

during operation: The heat genera-

ted during operation is dissipated

at the top, while cooler air is drawn

in from below through the vents and

cools the enclosure, and as a result

the heated air escapes again through

the top vents.

ICY BOX has a wide variety of dock

designs in its portfolio: ﬂat, horizon-

tally lying models, those that are pla-

ced under a notebook in a wedge

shape for ergonomic working or tho-

se that are equipped with a stand like

this IB-DK2252AC. The stand gives

the device a secure hold - even when

plugging in and unplugging cables -

and in this case enables the upright

DockingStation to have effective

cooling qualities!

RaidSonic Technology GmbH · Kurt-Fischer-Straße 50 · 22926 Ahrensburg · Germany

Phone +49 4102 468-900 · info@raidsonic.deE-Mail www.icybox.de/en/

Visit us:

PACKING CONTENT

PRODUCT FEATURES

VIDEO CONNECTION AND DISPLAY OUTPUT MATRIX

SYSTEM REQUIREMENTS

Video matrix design (USB 3.0 DisplayLink®, maximum resolutions)

INPUTS (PLUGIN) DOCK OUTPUT

Number of displays HDMI® or DP 1 HDMI® or DP 2 Display 1 Display 2

Dual video output ✓ ✓ 3840x2160@60 Hz 3840x2160@60 Hz

Single video output ✓3840x2160@60 Hz

✓3840x2160@60 Hz

DP 1 DP 2 5120x2880@60 Hz

Supported Operating Systems Host compatibility

Windows® / macOS® / Chrome OS™ USB 3.0 Type-A / USB Type-C® / Thunderbolt™ 3 Type-C®

Colour Material LED CoolingUASP support Plug & Play Power supply

Black ABS, plastic, metal Yes Yes Power Passive External power supply AC

100-240 V; 50 / 60 Hz;

DC 20 V / 2 A; 40 W

▶1x IB-DK2252AC

▶1x Wall power supply with EU, UK, US adapter

▶1x USB Type-B to Type-A / Type-C® cable

▶1x Manual

HOST CONNECTION ON THE DOCKINGSTATION

Port Position Version & transfer rate Features

1x USB Type-B USB 3.0 (5 Gbit / s)Rear USB data transfer
