Sida 1/5
New EASYMAG
Magnetic Stripe Reader
USB/CDC Interface
Quickstart Manual
TM
ID TECH
10721 Walker Street
Cypress, California 90630
(714) 761-6368
www.idtechproducts.com
80080505-001 Rev. A R04/06 #408
AGENCY APPROVED
Specifi cations for subpart B of part 15 of FCC rule for a Class A
computing device.
LIMITED WARRANTY
ID TECH warrants to the original purchaser for a period of 24 months from
the date of invoice that this product is in good working order and free from
defects in material and workmanship under normal use and service. ID
TECH’s obligation under this warranty is limited to, at its option, replacing,
repairing, or giving credit for any product which has, within the warranty
period, been returned to the factory of origin, transportation charges and
insurance prepaid, and which is, after examination, disclosed to ID TECH’s
satisfaction to be thus defective. The expense of removal and reinstallation of
any item or items of equipment is not included in this warranty. No person,
fi rm, or corporation is authorized to assume for ID TECH any other liabilities
in connection with the sales of any product. In no event shall ID TECH be
liable for any special, incidental or consequential damages to Purchaser or
any third party caused by any defective item of equipment, whether that
defect is warranted against or not. Purchaser’s sole and exclusive remedy for
defective equipment, which does not conform to the requirements of sales, is
to have such equipment replaced or repaired by ID TECH. For limited war-
ranty service during the warranty period, please contact ID TECH to obtain
a Return Material Authorization (RMA) number & instructions for returning
the product.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE.
THERE ARE NO OTHER WARRANTIES OR GUARANTEES, EXPRESS
OR IMPLIED, OTHER THAN THOSE HEREIN STATED. THIS PROD-
UCT IS SOLD AS IS. IN NO EVENT SHALL ID TECH BE LIABLE FOR
CLAIMS BASED UPON BREACH OF EXPRESS OR IMPLIED WAR-
RANTY OF NEGLIGENCE OF ANY OTHER DAMAGES WHETHER DI-
RECT, IMMEDIATE, FORESEEABLE, CONSEQUENTIAL OR SPECIAL
OR FOR ANY EXPENSE INCURRED BY REASON OF THE USE OR
MISUSE, SALE OR FABRICATIONS OF PRODUCTS WHICH DO NOT
CONFORM TO THE TERMS AND CONDITIONS OF THE CONTRACT.
DEFAULT SETTINGS TABLE
The EasyMag reader is shipped from the factory with the following default settings
already programmed:
Magnetic Track Basic Data Format
Track 1: <SS1><T1 Data><ES><CR>*
Track 2: <SS2><T2 Data><ES><CR>*
Track 3: <SS3><T3 Data><ES><CR>*
where: SS1(start sentinel track 1) = %
SS2(start sentinel track 2) = ;
SS3(start sentinel track 3) = ; for ISO, ! for CDL, % for AAMVA
ES(end sentinel all tracks) = ?
Start or End Sentinel: Characters in encoding format which come before the fi rst
data character (start) and after the last data character (end), indicating the beginning
and end, respectively, of data.
Track Separator: A designated character which separates data tracks.
Terminator: A designated character which comes at the end of the last track of data,
to separate card reads.
LRC: Check character, following end sentinel.
CDL: Old California Drivers License format.
CR: Carriage Return.
*Note: The <CR> characters (shown above) between tracks 1 & 2 and 2 & 3
denote the default character for this position, the Track Separator position. The
<CR> characters shown for track 3 denotes the default character for this position,
the Terminator position.
6
©2006 International Technologies & Systems Corporation. The information
contained herein is provided to the user as a convenience. While every effort
has been made to ensure accuracy, ID TECH is not responsible for damages
that might occur because of errors or omissions, including any loss of profi t
or other commercial damage. The specifi cations described herein were cur-
rent at the time of publication, but are subject to change at any time without
prior notice.
ID TECH is a registered trademark of International Technologies & Systems
Corporation. EasyMag and Value through Innovation are trademarks of
International Technologies & Systems Corporation.
Windows is a registered trademark of Microsoft Corporation. The USB (Uni-
versal Serial Bus) Specifi cation is Copyright© 1998 by Compaq Computer
Corporation, Intel Corporation, Microsoft Corporation, NEC Corporation.
RUNNING THE UTILITY
The reader is shipped from the factory with the “default confi guration”
programmed. The default confi guration has the least restrictive settings, thus
making it able to read all data of a standard encoded magnetic stripe card.
See the default settings table for details.
The confi guration software can be downloaded from the ID TECH website.
From the website, download the Confi guration Utility ZIP fi le into a tempo-
rary fi le folder on your local hard drive. Double click the downloaded self
extracting fi le and follow the screen prompts to expand the Zip fi le and run
the SETUP.EXE application.
The install wizard creates two new folders on the C: Drive. The new folder
“IDTECH” and a sub-folder “MagSwipe Confi guration Utility” are created in
the “Program Files” folder.
At the fi nish of the installation process, an “MagSwipe Confi guration Util-
ity” menu is installed in the programs folder of the Start menu. Connect
the reader to the host computer and ensure it is getting power. Point to the
“MagSwipe Confi guration Utility” menu and click on the IDT icon.
The utility will start at the Home Page with a menu on the left border. Point
and click on the menu items as needed. For information on using the utility,
point and click the HELP menu selection.
5
