Sida 1/58
Ikegami Tsushinki Co., Ltd.
INSTRUCTION MANUAL
MODEL
OUTDOOR USE WARNING
WARNING — TO PREVENT FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSED THIS APPLIANCE TO
RAIN OR MOISTURE.
ICD-48E
B/W CAMERA
Thank you very much for your wise choice of the Ikegami B/W Camera. Please carefully
read this Instruction Manual to keep your camera at full capacity.
Page
1. Handling precautions ............................................................................... E-1
2. General .................................................................................................... E-1
3. Features ................................................................................................... E-1
4. Names of Parts and their functions .......................................................... E-2
5. Setting ...................................................................................................... E-5
5-1. User setting ..................................................................................... E-5
5-2. Setting switches and their functions ................................................ E-5
5-3. User setting menus ......................................................................... E-5
6. Communication Command ...................................................................... E-6
6-1. Communicating conditions .............................................................. E-6
6-2. Command format ............................................................................ E-6
6-3. Communication flow ........................................................................ E-7
6-4. Communication command .............................................................. E-8
6-5. Table of OSD display character codes ............................................ E-9
7. Specifications ........................................................................................... E-10
8. Warranty and after-sale service ............................................................... E-12
9. Appearance View
10. Setup Menu
Contents
Instructions for Disposal of Electric and Electronic
Equipment in Private Household
Disposal of used Electric and Electronic Equipment
(Applicable in the European Union and other European countries
with separate collection systems)
This symbol on the product, or in the related documents in the package,
indicates that this product shall not be treated as normal household waste.
Instead, it should be taken to a proper applicable collection point or depot for
the recycling of electric and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent possible negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The recycling of materials will help to conserve
natural resources.
For more detailed information about recycling of this product, please contact your local city
authority, your household waste disposal service or the place where you purchased the
product.
E-1
1. Handling precautions
(1)Do not open the case of camera and never touch inside, where precision parts are
assembled. A trouble or accident may result.
(2)Do not install the unit where it is exposed to water splash, high humidity and heavy
dust. Internal parts may be damaged.
(3)Be very careful not to drop or shock the camera.
(4)Never touch the CCD surface.
2. General
This is a B/W camera of high sensitivity, high resolution and high picture quality using a
1/2 inch CCD having high sensitivity to near-infrared ray.
It has a high resolution of 560 horizontal lines (CCIR), minimum illumination of 0.01 lux,
and a smear level of -120 dB, and is equipped with such functions as line lock, automatic
electronic shutter, backlight compensation, two-way automatic iris, etc. It is a high utility
video camera for monitoring the outdoor scene and as a night-vision camera in combination
with near-infrared ray projector.
Moreover, since it is endowed with OSD and RS-485 communicating function, a high-
grade monitor system architecture is also possible.
3. Features
(1) Compactness
(2) High sensitivity and high resolution
(3) High sensitivity to near-infrared ray
(4) Reduced smear
(5) Backlight compensation (BLC)
(6) Two-way auto iris function
(7) Line lock
(8) AES (Automatic Electronic Shutter)
(9) Flange focal distance adjustment
(10) RS-485 communicating function
