Sida 1/12
2009
QUICK
REFERENCE
GUIDE
COMPASS
v e h i c l e f e at u r e s
Fuel cap:
LOOSE GAS CAp MESSAGE
• If a “gas cap” message (shown as gASCAP) appears, tighten the gas cap
until a “clicking” sound is heard.
• Press the odometer reset button to turn the message off.
• If the message continues to appear for more than three days after
tightening the gas cap, see your dealer.
Tire pressure MoniToring
sysTeM (TpMs):
• A Tire Pressure Monitoring Light and a “low tire” message will display
in your instrument cluster along with an audible chime if one or more of
your vehicle’s four road tires are signicantly under-inated.
• Check the ination pressure of each tire and inate to the recommended
pressure for your vehicle. The tire pressures recommended for your
vehicle are found on the “Tire and Loading Information” label located on
the driver’s side door opening. The TPMS light should not be used as a
tire pressure gauge when adjusting your tire pressure.
• It is recommended that you check the tire pressure in the morning
when tires are cool; inate each tire to the recommended pressure for
your vehicle. The light will turn off after your vehicle’s tire pressures are
properly inated and the pressure has been recognized. The vehicle may
need to be driven for up to 20 minutes above 15 mph (25 km/h) before the
light will turn off.
• Temperature changes can affect tire pressure, causing the TPMS light
to turn on. Tire pressures will also increase as the vehicle is driven - this
is normal and you should not adjust for this increased pressure.
• Driving on under-inated tires reduces your vehicle’s fuel efciency and
tire tread life. If a spare tire is in use on the vehicle, the TPMS light may
turn on. Refer to your Owner’s Manual.
oil change indicaTor:
MESSAGE
• If an “oil change” message (shown as CHAngE Oil or Oil Change
Required) appears and a single chime sounds, it is time for your next
required oil change.
RESETTING LIGhT AfTER SERvICING
• Turn the ignition switch to the ON/RUN position (do not start engine).
• Fully depress the accelerator pedal three times within 10 seconds.
• Turn the ignition switch to the OFF/LOCK position.
s
Rotate Mode Control Rotate Blower Control Rotate Temp Control
Press Air Recirc.
Button
Press A/C
Button
Press Rear Window
Defroster Button
CLIMATE CONTROLS:
AIR RECIRCuLATION / MAX A/C
• For window defogging, turn the recirculation button off.
• Recirculation is not allowed in defrost, oor, defrost/oor (mix) modes.
• For maximum cooling, rotate the Temperature Control to the MAX
A/C position.
DRIVER SEAT ADJUSTMENT:
fORwARd/REARwARd
• Lift up on the adjusting bar, located at the front of the seat near the oor,
and release at the desired position.
RECLINER
• Lean forward before lifting the lever, located on the outboard side of the
seat, then lean back to desired position and release the handle.
hEIGhT AdjuSTMENT
• Ratchet the front lever, located on the outboard side of the seat,
upward to raise the seat height. Ratchet the lever downward to lower
the seat height.
Forward/Rearward
Height Adjustment
Recliner
Lumbar
