Sida 1/20

DDX418

DDX4048BT

DDX318

DDX3048

MONITOR WITH DVD RECEIVER

INSTALLATION MANUAL

MONITEUR AVEC RÉCEPTEUR DVD

MANUEL D'INSTALLATION

MONITOR CON RECEPTOR DVD

MANUAL DE INSTALACIÓN

2 DDX418/DDX4048BT/DDX318/DDX3048

Accessories

..........1

..........1 (2m: 6.5 ft)

..........6

..........1

..........2

7*1

..........1 (3m: 9.8 ft)

*1 DDX418/ DDX4048BT

only.

Installation Procedure

1 To prevent a short circuit, remove the key

from the ignition and disconnect the -

battery.

2 Make the proper input and output wire

connections for each unit.

3 Connect the speaker wires of the wiring

harness.

4 Connect the wiring harness wires in the

following order: ground, battery, ignition.

5 Connect the wiring harness connector to

the unit.

6 Install the unit in your car.

7 Reconnect the - battery.

8 Press the reset button.

9 Perform the Initial Setup. (Refer to the

Instruction Manual.)

2WARNING

• If you connect the ignition wire (red) and the

battery wire (yellow) to the car chassis (ground),

you may cause a short circuit, that in turn may

start a fire. Always connect those wires to the

power source running through the fuse box.

• Do not cut out the fuse from the ignition wire

(red) and the battery wire (yellow). The power

supply must be connected to the wires via the

fuse.

After the Installation

After the installation, perform the Initial Setup

by referring to the instruction manual.

• Mounting and wiring this product requires

skills and experience. For best safety, leave the

mounting and wiring work to professionals.

• Make sure to ground the unit to a negative 12V

DC power supply.

• Do not install the unit in a spot exposed to direct

sunlight or excessive heat or humidity. Also avoid

places with too much dust or the possibility of

water splashing.

• Do not use your own screws. Use only the screws

provided. If you use the wrong screws, you could

damage the unit.

• If the power is not turned ON ("Miswiring

DC Offset Error", "Warning DC Offset Error" is

displayed), the speaker wire may have a short-

circuit or touched the chassis of the vehicle and

the protection function may have been activated.

Therefore, the speaker wire should be checked.

• If your car’s ignition does not have an ACC

position, connect the ignition wires to a power

source that can be turned on and off with the

ignition key. If you connect the ignition wire to

a power source with a constant voltage supply,

such as with battery wires, the battery may be

drained.

• If the console has a lid, make sure to install the

unit so that the faceplate will not hit the lid when

closing and opening.

• If the fuse blows, first make sure the wires aren’t

touching to cause a short circuit, then replace the

old fuse with one with the same rating.

Accessories/ Installation Procedure

English 3

¤ CAUTION

Install this unit in the console of your

vehicle.

Do not touch the metal part of this unit

during and shortly after the use of the

unit. Metal part such as the heat sink and

enclosure become hot.

• Insulate unconnected wires with vinyl tape or

other similar material. To prevent a short circuit,

do not remove the caps on the ends of the

unconnected wires or the terminals.

• Connect the speaker wires correctly to the

terminals to which they correspond. The unit may

be damaged or fail to work if you share the -

wires or ground them to any metal part in the car.

• When only two speakers are being connected

to the system, connect the connectors either to

both the front output terminals or to both the

rear output terminals (do not mix front and rear).

For example, if you connect the connector +

of the left speaker to a front output terminal, do

not connect the connector to a rear output -

terminal.

• After the unit is installed, check whether the brake

lamps, blinkers, wipers, etc. on the car are working

properly.

• Mount the unit so that the mounting angle is 30°

or less.

• Do not press hard on the panel surface when

installing the unit to the vehicle. Otherwise scars,

damage, or failure may result.

• This unit has the cooling fan to decrease the

internal temperature. Do not mount the unit

in a place where the cooling fan of the unit are

blocked. Blocking these openings will inhibit the

cooling of the internal temperature and result in

malfunction.

Cooling fan

DDX418/ DDX4048BT only

• Install the Bluetooth adaptor (KS-UBT1) besides

the place enclosed by the metal.

Bluetooth adaptor (KS-UBT1)
