Kenwood KDC-X798 Bruksanvisning

Kenwood mottagare KDC-X798

Läs nedan 📖 manual på svenska för Kenwood KDC-X798 (27 sidor) i kategorin mottagare. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/27
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new CD-receiver.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below.
Refer to the model and serial numbers whenever you call upon your Kenwood dealer for information or service on the product.
Model KDC-X798/ KDC-BT758HD/ KDC-BT710HD Serial number
US Residents Only
Register Online
Register your Kenwood product at www.Kenwoodusa.com
GET0971-001A (KW/K0)© 2013 JVC KENWOOD Corporation
KDC-X798
KDC-BT758HD
KDC-BT710HD
CD-RECEIVER
INSTRUCTION MANUAL
AMPLI-TUNER LECTEUR DE CD
MODE D’EMPLOI
REPRODUCTOR DE DISCOS COMPACTOS RECEPTOR DE FM/AM
MANUAL DE INSTRUCCIONES
7ENGLISH |
HD Radio™ tuner
Search for a station or channel
1 Press B SRC to select HD RADIO.
2 Press repeatedly (or press JBAND *AM– #FM+ / on RC-406)
to select FM1/ FM2/ FM3/ AM.
3 Press (or press on RC-406) to search for S T / S T / (+)
a station or channel.
• Press To change the searching method for :S T / KSEEK
repeatedly.
Automatically search for a station or channel.AUTO1:
Search for a preset station or channel.AUTO2:
Manually search for a station or channel.MANUAL:
• Press and hold one of the number To store a station or channel:
buttons ( to ).1 6
• Press one of the number To select a stored station or channel:
buttons ( to ) (or press one of the number buttons ( to ) on 1 6 1 6
RC-406).
Select an HD Radio multicast channel
Many HD Radio stations offer more than one channel programming.
This service is called multicasting. While receiving HD Radio
multicast channels....
Press to select your desired channel (HD1 to HD8).S T /
“LINKING” appears while linking to a multicast channel.
You can tune in to both conventional and HD Radio broadcasts.
• To find HD Radio stations in your area, visit
<http://www.hdradio.com>.
Direct Access Tuning (using RC-406)
1 Press to enter Direct Access Tuning.DIRECT
2 Press the number buttons to enter a frequency or channel.
3 Press to search for a station or channel.ENT IW
• To cancel, press or .DIRECT
• If no operation is done for 10seconds after step2, Direct Access Tuning is
automatically canceled.
Other settings
1 Press the volume knob to enter
[FUNCTION]
.
2 Turn the volume knob to make a selection (see the following table), then
press the knob.
3 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default:
XX
TUNER SETTING
IF BAND AUTO
: Increases the tuner selectivity to reduce interference noises from adjacent
FM stations. (Stereo effect may be lost.) ;
WIDE
: Subjects to interference noises
from adjacent FM stations, but sound quality will not be degraded and the stereo
effect will remain.
AUTO
MEMORY
YES
:Automatically starts memorizing 6 stations with good reception.;
NO
:Cancels.
(Selectable only if
[NORMAL]
is selected for
[PRESET
TYPE]
.)
( 4)
RECEIVE
MODE
Sets the receive mode of the HD Radio receiver.
AUTO
: Automatically tunes to analog broadcast when there is no digital
broadcast.;
DIGITAL
: Tunes in to digital broadcast only.;
ANALOG
: Tunes in to
analog broadcast only.
TAG MEMORY
Displays the shared tag memory usage of the HD Radio tags and SiriusXM Radio
tags.
00
—
50
: Up to 50 tags can be registered to this unit.
CLOCK
TIME SYNC ON
:Synchronizes the unit’s time to the Radio Broadcast Data System station time.;
OFF
:Cancels.
15ENGLISH |
BLUETOOTH®
Bluetooth mobile phone
To Do this
Receive a call Press or the volume knob or one
of the number buttons ( to ) (or 1 6
press on RC-406).
• All the buttons and display flash
when there is an incoming call.
During a call, the buttons and
display illuminate according to the
settings made for
[DISPLAY]
.
(
20)
• When
[AUTO ANSWER]
is set to the
selected time, the unit answers
incoming call automatically.
(
16)
Reject an incoming
call
Press B SRC (or press on
RC-406).
End a call Press or B SRC (or press on
RC-406).
Switch between
hands-free and
private talk modes
Press during a call.6IW
• Operations may vary according to
the connected Bluetooth device.
Adjust the phone
volume
Turn the volume knob during a
call.
Phone volume:
[00]
to
[35]
(Default:
[15]
)
• This adjustment will not affect the
volume of the other sources.
Switch between two
connected phones
Press repeatedly.
• Not applicable during a call.
Improve the sound quality during a call
While talking on the phone...
1 Press the volume knob to enter
[FUNCTION]
.
2 Turn the volume knob to make a selection (see the following table), then
press the knob.
3 Press and hold to exit.
To return to the previous setting item or hierarchy, press .
Default:
XX
MIC GAIN –20
—+
8
(
0
):The sensitivity of the microphone increases as the number increased.
NR LEVEL –5
—
–20
(
–10
):Adjust the noise reduction level until the least noise is being heard
during a phone conversation.
ECHO CANCEL 1
—
10
(
4
):Adjust the echo cancellation delay time until the least echo is being heard
during a phone conversation.
Text message notification
When the phone receives a text message, the unit rings and “SMS RECEIVED”
appears.
• You cannot read, edit, or send a message through the unit.
• To clear the message, press any button.
Use Voice Recognition
1 Press and hold to activate Voice Recognition.
The connected phone (which has been paired the earliest) is activated. However,
if priority device is connected, pressing and holding activate the priority
device.
( 17, DVC PRIORITY)
2 Speak the name of the contact you want to call or the voice command to
control the phone functions.
• Supported Voice Recognition features vary for each phone. Refer to the instruction
manual of the connected phone for details.
• This unit also supports the intelligent personal assistant function of iPhone.

Produktspecifikationer

Varumärke: Kenwood
Kategori: mottagare
Modell: KDC-X798
