Sida 1/10

KTC-V300E

TV TUNER 3 page 2 - 8

INSTRUCTION MANUAL

SYNTONISEUR TV page 10 - 163

MODE D'EMPLOI

TV-TUNER Seite 18 - 243

BEDIENUNGSANLEITUNG

TV-TUNER blz 26 - 323

GEBRUIKSAANWIJZING

SINTONIZZATORE TV pagina 34 - 403

ISTRUZIONI PER L'USO

SINTONIZADOR TV página 42 - 483

MANUAL DE INSTRUCCIONES

SINTONIZADOR TV página 50 - 563

MANUAL DE INSTRUÇÕES

SI DICHIARA CHE:

Il Sintonizzatore TV Kenwood per auto, modello

KTC-V300E

risponde alle prescrizioni dell'art. 2 comma 1 del D.M. 28 agosto

1995, n. 548.

Fatto ad Uithoorn il 21 dicembre 2005

Kenwood Electronics Europe B.V.

Amsterdamseweg 37

1422 AC Uithoorn

The Netherlands

2 | English

Accessories

..........1

(4.0m) ..........1

(5.5m) ..........1

..........6

(3.0m) ..........1

..........2

(M4x8mm) ..........4

(ø4x16mm) ..........4

..........1

■ Securing to audio board

Use screws (Accessory 8 9 and ) to fix TV Tuner onto an audio board or another.

Installation the TV Tuner Unit

Accessory 9

Accessory 8

Accessory 7

English | 3

Installing the Antenna

■ Before installing the antenna

2WARNING

• Mounting and wiring this product requires skills and

experience. For safety's sake, leave the mounting

and wiring work to professionals.

2CAUTION

• Incar antennas have a lower reception sensitivity

than antennas intended for outside mounting. The

picture may not appear or may be disturbed if the

signal in your area is weak.

• The film antennas are designed specially for use in

car.

• Do not attach the film antennas in the following

places:

– A place where the driver’s view is blocked

– A place where safety parts such as an airbag are prevented

from operating normally

– On the surface of a glass such as a rear hatch glass which

is frequently moved.

• The reception sensitivity lowers in the following

places:

– A place where a heat reflection glass or mirror-type glass

film is affixed

– A place where the film antenna of the factory-supplied

radio already exists

– On the window where the heating wire already exists

– On the side of the vehicle (door, front quarter window,

etc.)

– On the rear window

– On a glass (heat reflecting glass, heat insulating glass, etc.)

that blocks radio waves

• Using the cleaner (Accessory 0), remove oil and dirt

from the glass surface to which the film antennas

are to be affixed.

• If the ambient temperature is low, warm the glass

before starting the work.

• Before starting the work, confirm well the places

where the film antennas (Accessory 1 and ) and 2

the cables (Accessory and ) are to be installed. 3 4

Once peeled off, the film antennas and double-stick

tape lose adhesion.

• Do not fold or damage the film antennas.

• Noise generated by the air conditioner or monitor

can cause poor TV reception.

• The film antennas cannot be installed depending on

the vehicle model.

• The reception sensitivity can vary with the

windshield wiper operation depending on the

vehicle model.

• The reception sensitivity can vary depending on the

relationship between the traveling direction of the

vehicle (the pointing direction of the antennas) and

the location of the broadcast station.
