INSTALLATION

To install the handles onto the front panel of the repeater,

align the handles with the holes on the front panel, then

secure the handles using the supplied screws.

Please consult your dealer for installing the repeater and

antenna.

MICROPHONE

Connect an optional KMC-30 (E type only), KMC-27A,

KMC-27B, or KMC-9C microphone to theKENWOOD

MIC jack on the front panel.

VHF FM REPEATER/ UHF FM REPEATER

TKR-750/ TKR-850

INSTRUCTION MANUAL

KENWOOD CORPORATION

09 08 07 06 05 04 03 02

NOTICES TO THE USER

UNPACKING AND CHECKING EQUIPMENT

Note:

The following unpacking information is for use by your

KENWOOD

dealer, an authorized

KENWOOD

service facility, or the factory.

Carefully unpack the repeater. We recommend that you

identify the items listed in the following table before

discarding the packing material. If any items are missing

or have been damaged during shipment, file a claim with

the carrier immediately.

FCC WARNING

This equipment generates or uses radio frequency energy. Changes or

modifications to this equipment may cause harmful interference unless

the modifications are expressly approved in the instruction manual. The

user could lose the authority to operate this equipment if an unauthorized

change or modification is made.

◆

GOVERNMENT LAW PROHIBITS THE OPERATION OF

UNLICENSED RADIO TRANSMITTERS WITHIN THE

TERRITORIES UNDER GOVERNMENT CONTROL.

◆

ILLEGAL OPERATION IS PUNISHABLE BY FINE OR

IMPRISONMENT OR BOTH.

◆

REFER SERVICE TO QUALIFIED TECHNICIANS ONLY.

metI rebmuNtraP ytitnauQ

erutxiferawdraH 4X-2048-12J 1

ssalgtnorF 4X-5362-01B 1

retliF 4X-9521-11B 1

noihsuC 4X-1081-31G 4

noihsuC 4X-2081-31G 4

tooF 5X-5740-20J 2

tooF 4X-2940-20J 2

temmorG 5X-2030-95J 2

eldnaH 5X-8140-10K 1

swercS 54-6003-53N 5

drocCD 5X-7243-03E 1

elbacrotcennoC 5X-8223-13E 1

esuF 5X-7351-50F 1

)ylnoepytK(dracytnarraW — 1

launamnoitcurtsnI XX-7231-26B 1

THANK YOU!

We are grateful you purchased this KENWOOD repeater.

We believe this easy-to-program repeater will be highly

effective in your communications system, and will keep

personnel operating at peak efficiency.

KENWOOD incorporates the latest in advanced technol-

ogy into all of our products. As a result, we feel strongly

that you will be pleased with the quality and features of

this product.

FEATURES

• You can easily program channel data using the KPG-66D

software on a PC.

• You can recall 1 of 16 preset channels using either a PF key

or the external control line.

• The firmware can be written to the Flash memory through

an external source.

• QT/DQT signalling can be programmed on each channel. It

simultaneously decodes up to 16 different QT/DQT tones.

• The interface port can be used with external equipment,

such as a repeater controller.

• The repeater has multi-mode capability.

Wide: 30 kHz/ Narrow: 15 kHz (TKR-750; K type only)

Wide: 25 kHz/ Narrow: 12.5 kHz (TKR-750/ TKR-850)

• You can adjust the following functions from a PC:

• Squelch

• RX audio signal output (RA)

• RX detector signal output (RD)

• RX frequency

• RF output power

• Maximum deviation

• TX audio input (TA)

• Signalling deviation (TD)

• DQT balance

• QT deviation

• DQT deviation

• Test tone deviation

• CW ID deviation

• Repeat gain

• TX frequency

PRECAUTIONS

• Do not expose the unit to rain or moisture; to prevent fire or

electric shock.

• Do not open the unit under any circumstances; to avoid risk

of electric shock.

• Do not expose the unit to long periods of direct sunlight, nor

place it close to heating appliances.

• Do not place the unit in excessively dusty and/or humid

areas, nor on unstable surfaces.

• If you detect an abnormal odor or smoke coming from the

unit, disconnect the power from the unit immediately.

Contact your KENWOOD service center or dealer.

REPEATER OPERATION

Note:

Please consult your dealer for programming the repeater.

When power is applied to the unit, the Power indicator

lights:

• Green when using the main DC jack.

• Red when using the Backup terminal.

Rotate the control to adjust the volume.VOLUME

The BUSY indicator lights green while receiving a signal

and the indicator lights red while transmitting.TX

qqqqq Speaker

www CH/STATUS Display

Two, 7-segment digits display the channel number

or status.

eee VOLUME control

Rotate to adjust the volume.

rrrrr DC SOURCE switch

ttttt Power indicator

Lights green when power is applied from the DC

13.6V jack (DC 13.2V jack on E type versions).

Lights red when power is applied from the BACK

UP battery terminal.

yyyyy MIC jack

Connect a microphone to this 8-pin modular jack.

uProgrammable Function keys

Press these keys to activate their programmable

functions.

iiiii BUSY indicator

Lights green while a signal is being received.

oTX indicator

Lights red while transmitting.

■Rear Panel

qTX OUT jack

Connect a TX antenna or a duplexer to this recep-

tacle.

wwwww CONTROL I/O jack

Connect an external programming device or re-

peater controller to this DB-25 interface.

eeeee FUSE

Insert 15 A blade fuses into these fuse holders.

rRX IN jack

Connect a RX antenna or a duplexer to this BNC

receptacle.

ttttt DC 13.6V (K type) / DC 13.2V (E type) jack

Connect a 13.6 V (K type) or 13.2 V (E type) DC

power supply to this jack.

yyyyy BACKUP battery terminal

uuuuu TEST/SPKR jack

Test input/output jack. Connect an external

speaker to this jack.

TRANSCEIVER OPERATION

■Receive

Adjust the volume to your desired level. You may need

to readjust the volume when you receive a message

from your dispatcher or another member in your fleet.

• The BUSY indicator lights green while a signal is

being received.

■Transmit

1Listen to the channel before transmitting, to make

sure it is not being used.

2Press the microphone PTT switch, then speak in

your normal speaking voice.

• FCC regulations require that you identify the

station you are calling as well as your own

station (your assigned call sign).

• The TX indicator lights red while transmitting.

3When you finish speaking, release the PTT switch.

CONTROLS AND FUNCTIONS

■Front Panel

qqq ww

www rr

rrr tt

ttt

yuu

uii

ioo

eee

qqqqq wwwww rrrrr

tttttyyyyyuuuuu

eeeee

* The K type model is

shown in this diagram.
