Sida 1/40
B60-5588-10 01 CS ( K, P, E, X, Y ) KW 0410
AUDIO VIDEO SURROUND RECEIVER
VRS-6200
INSTRUCTION MANUAL
KENWOOD CORPORATION
About the supplied remote control
Compared to standard remote controls, the remote control supplied with this receiver has
several operation modes. These modes enable the remote control to control other KENWOOD
DVD players. In order to effectively use the remote control, it is important to read the operating
instructions and obtain a proper understanding of the remote control and how to switch its
operation modes (etc.).
Using the remote control without completely understanding its design and how to switch the
operation modes may result in incorrect operations.
Quick Start Reference
Please read the following pages so that you can enjoy the surround sound at the best
condition.
(These pages give shortcut explanations on how to connect the speaker system to the
receiver, set up the speakers and play a source.)
"Let's play DVD video software" $%
2 EN
Units are designed for operation as follows.
Before applying power
Caution : Read this page carefully to ensure safe operation.
U.S.A. and Canada ........................................... AC 120 V only
Australia ........................................................... AC 240 V only
Europe ............................................................... AC 230 V only
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO
THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE APPLIANCE.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED
TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PROD-
UCT’S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC
SHOCK TO PERSONS.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Safety precautions
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Other countries ............................ AC 110 - 120 / 220 - 240 V
switchable*
* AC voltage selection
The AC voltage selector switches on the rear panel are
set to the voltage that prevails in the area to which the
unit is shipped. Before connecting the power cord to
your AC outlet, make sure that the setting positions of
these switches match your line voltage. If not, they must
be set to your voltage in accordance with the following
direction.
Note: Our warranty does not cover damage caused by
excessive line voltage due to improper setting of the AC
voltage selector switch.
VOLTAGE SELECTOR
AC 110
-
120V
~
AC 220
-
240V
~
Move switch lever to
match your line voltage
with a small screwdriver or
other pointed tool.
AC voltage selector switch
3 EN
Before applying power
How to use this manual
This manual is divided into four sections, Preparations, Operations,
Remote Control, and Additional Information.
Preparations
Shows you how to connect your audio and video components to the
receiver and prepare the surround processor. Since this receiver
works with all your audio and video components, we will guide you in
setting up your system to be as easy as possible.
Operations
Shows you how to operate the various functions available on the
receiver.
Remote Control
Shows you how to operate other components using the remote
control, as well as a detailed explanation of all remote control opera-
tions. Once you have setup the remote control, you’ll be able to
operate both this model and your KENWOOD DVD player using the
remote control supplied with this model.
Additional Information
Shows you additional information such as "In case of difficulty"
(trouble shooting) and "Specifications".
Unpacking
Unpack the unit carefully and make sure that all the accessories
are present.
If any accessories are missing, or if the unit is damaged or fails
to operate, notify your dealer immediately. If the unit was
shipped to you directly, notify your shipper immediately.
Kenwood recommends that you retain the original carton and
packing materials in case you need to move or ship the unit in
the future.
Keep this manual handy for future reference.
AM loop antenna (1)
Remote control unit
(1)
Batteries (R03/AAA)
(2)
FM indoor antenna (1)
(For the U.S.A. and Canada)
FM indoor antenna (1)
(Except for the U.S.A. and
Canada)
Special features
True home theater sound
•
~
ª
This receiver incorporates a wide variety of surround modes to bring you
maximum enjoyment from your video software. Select a surround mode
according to your equipment or the software you are going to play and enjoy!
÷Dolby Digital EX
÷Dolby PRO LOGIC x, Dolby PRO LOGIC II II
÷Dolby Digital
÷DTS-ES
÷DTS NEO:6
÷DTS
÷DSP Mode
ACTIVE EQ
¡
ACTIVE EQ mode will produce a more dynamic sound quality in any
condition. You can enjoy a more impressive sound effect when ACTIVE
EQ is turned on during Dolby Digital and DTS playback.
Remote control
›
In addition to the basic receiver, the remote control supplied with this
receiver can also operate KENWOOD DVD player.
RDS (Radio Data System) tuner (For Europe and Australia)
§
The receiver is equipped with an RDS tuner that provides several
convenient tuning functions: RDS Auto Memory, to automatically preset
up to 40 RDS stations broadcasting different programs; station name
display, to show you the name of the current broadcast station; and PTY
search to let you tune stations by program type.
Channel space switching (Except for the U.S.A.,
Canada, Europe and Australia)
The space between radio channels has been set to the one that prevails
in the area to which the system is shipped. However, if the current
channel space setting does not match the setting in the area where the
system is to be used, for instance when you move from area 1 or area
2 shown in the following table or vice versa, proper reception of AM/FM
broadcasts cannot be expected. In this case, change the channel space
setting in accordance with your area by referring to the following table.
1.
2.
CHANNEL
Space Frequency
Area
U.S.A., Canada and South
American countries
Other countries
FM: 100 kHz
AM: 10 kHz
FM: 50 kHz
AM: 9 kHz
Turn the power OFF by pressing the ON/STANDBY key
before moving the switch level. Move the switch lever to match
your area with a small screwdriver or other pointed tool, then
turn the power ON again.
DE-EMPHASIS
CHANNEL SPEACE
50µs
AM 9kHz
FM 50kHz
75µs
AM 10kHz
FM 100kHz
*AC plug adapter (1)
* Use to adapt the plug on the
power cord to the shape of the
wall outlet. (Accessory only for
regions where use is necessary.)
