Sida 1/12

Take the time to read through this instruction manual.

Familiarity with installation and operation procedures will help you obtain the best performance from your new power amplier.

For your records

Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the

model and serial numbers whenever you call upon your KENWOOD dealer for information or service on the product.

Model XM160-2 Serial number

XM160-2

2-CHANNEL POWER AMPLIFIER DESIGNED AND ENGINEERED TO BE

PLUG AND PLAY FOR 2014-UP HARLEY-DAVIDSON® ROAD GLIDE®,

STREET GLIDE®, OR ULTRA MOTORCYCLES

INSTRUCTION MANUAL

JVCKENWOOD Corporation

US Residents Only

Safety precautions

WARNING

To pr ev ent injur y or fire, ta ke the fo llo wing

precautions:

• Mounting and wiring this product requires skills and

experience. For safety’s sake, leave the mounting and

wiring work to professionals.

• To prevent a short circuit, keep coins, tools, and other

metal objects away from the unit.

• If the unit starts to emit smoke or strange smells,

turn off the power immediately and consult your

KENWOOD dealer.

• Do not touch the unit during use because the surface

of the unit becomes hot and may cause burns if

touched.

CAUTION

To prevent da mage to the ma chine, tak e the

following precautions:

• Be sure the unit is connected to a 12 V DC power

supply with a negative ground connection.

• Do not open the top or bottom covers of the unit.

NOTE

• If you experience problems during installation, consult

your KENWOOD dealer.

• If the unit does not seem to be working right, consult

your KENWOOD dealer.

Protection function

To help protect your bike’s electrical system and battery,

the amp has a built in feature where it will turn itself o if

it sees less than 10.5 volts, whether the bike is running or

not. If you’re listening to your stereo while not riding, this

feature can help protect your battery so the bike can still

start. If you’re riding and the amp shuts o, this could be

showing a potential issue with your charging system. If

this feature is activated and the amp shuts o, it will turn

the amp back on again if the voltage exceeds the 10.5

volt threshold.

To prevent battery rise

When the unit is used in the ACC ON position without

turning the engine ON, it depletes the battery. Use it after

starting the engine.

Speaker selection

• Using speakers with smaller input ratings than the

amplifier ’s output power would result in smoke

generation or equipment failure.

• Use speakers that have an impedance of 2 Ω or greater.

When more than one set of speakers are going to

be used, calculate the combined impedance of the

speakers and then connect suitable speakers to the

amplier.

Contents

Section 1: Installation in Street/Ultra Glide Models....3

Section 2: Installation in Road Glide Models................6

Section 3: Adding a Second XM160-2 to the Bike.......8

Section 4: Final System Adjustments............................10

Warranty Info......................................................................11

The XM160-2 amplier is a Class D design. It should be

understood that ALL Class D ampliers, regardless of brand, cause

a reduction in FM reception. The XM160-2 features a proprietary

circuit design that KENWOOD believes gives the BEST FM reception

available for any Class D Amplier designed for a motorcycle. If

you add a 2nd or 3rd model amplier to your system, reduction

of FM reception is increased and is considered normal.

KENWOOD understands that some riders prefer the cosmetics of

in fairing antennas, however it should be noted that NOTHING

works as well as the factory antenna. If FM is an important part

of your riding experience, we strongly advise against the use of

any in fairing type antenna. Do not use the rod antenna as an antenna

to be mounted inside the fairing.

Section 1 - Single Amplier Installation in Street

Glide / Ultra

Installation procedure

1. Remove the seat and both wires (+ and -) from the battery. Remove the outer fairing/

headlamp assembly and set it aside. Refer to a service manual if you need help with this.

NOTE: Placing a towel on the front fender can help prevent scratches or “dings” from

dropped tools or fasteners, etc.

2. Over the top of the radio, pull up to release each wire harness from the black plate

via the factory “Christmas tree” fasteners. If your bike has factory GPS, the small square

antenna will need to be relocated just behind the voltmeter as shown in Fig 1.1 below.

Figure 1.1 - The white circle shows the new location for GPS Antenna if your bike came

factory equipped with this feature.

3. Remove the four factory T-20 “Torx” screws that go through the top of the black plate

and into the top of the radio.
